- Page 1 ITEM NO.：A101012202 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com 1-(866)-578-6569 Country of Origin: China Production Number: xxxxxxxxxx...
-
Page 2: Safety Information
2 / 22 Safety Information More than two people are required for this assembly. This unit is heavy! Do not assemble this DANGER: item alone. Some parts may contain sharp edges. Wear protective gloves. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of WARNING: While this gazebo is manufactured to personal injury and damage to equipment. -
Page 3: Pre-Assembly
3 / 22 Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. - Page 4 4 / 22 Pre-Assembly (continued) PACKAGE CONTENTS Country of Origin: China...
- Page 5 5 / 22 Pre-Assembly (continued) Part Part Number Description Quantity P000200461 Post 1 P000200460 Post 2 P006300077 Cross panel P000400897 Long cross beam P000400898 Short cross beam P005700661 Long mosquito netting bar 1 P005700662 Long mosquito netting bar 2 P005700663 Short mosquito netting bar 1 P005700664 Short mosquito netting bar 2...
- Page 6 6 / 22 Assembly Assembling the Cross Panels Connect 2 sets of Cross Panels (B1) with the long cross beams (B2) using screws (DD). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 7 7 / 22 Assembly Assembling the Cross Panels Connect another 2 sets of Cross Panels (B1) with the short cross beam (B3) using screws (DD). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 8 8 / 22 Assembly Assembling Mosquito Netting Bars Connect the Long mosquito netting bar 1 (C1) with Long mosquito netting bar 2 (C2). Connect the Short mosquito netting bar 1 (C3) with Short mosquito netting bar 2 (C4) . NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 9 9 / 22 Assembly Attaching the Mosquito Netting Bars Attach the assembled Long Mosquito Bars (C1&C2) to the Cross Beam (B1) using bolts (AA). Attach the Short Mosquito Bar (C3&C4) in the same way . NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 10 10 / 22 Assembly Assemble the Post 1 and Post 2 Screw the Post 2 (A2) on Post 1 (A1). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 11 11 / 22 Assembly Attaching the Crossbeams Attach the Post 1 (A1) to the assembled Cross Beams (B1&B1) using bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 12 12 / 22 Assembly Attaching the Crossbeams Attach the Post 1 (A1) to the assembled Cross Beams (B1&B1) using bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 13 13 / 22 Assembly Assembling the Oblique Tubes Connect the Upper oblique tube (D1), Middle oblique tube (D2) and Bottom oblique tube (D3) using the spring button on the parts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. D2 D3 Country of Origin: China...
- Page 14 14 / 22 Assembly Assembling the Middle Tubes Connect the Bottom long middle tube (E2) and Upper long middle tube (E1) using the spring button on the parts. Connect the Bottom short middle tube (F2) and Upper short middle tube (F1) using the spring button on the parts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 15 15 / 22 Assembly Attaching the Oblique Tube and Hook Inset the Upper oblique tubes (D1) to the Big roof connector (G), then Screw the Hook (K) to the Big roof connector (G). Insert the Bottom oblique tube (D3) to the Post 1 (A1). NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 16 16 / 22 Assembly Attaching the Middle Tubes Insert the assembled Long middle tube (E1) to the Big roof connector (G), insert the Bottom long middle tube (E2) to the Short cross beam (B3). Insert the assembled Short middle tube (F1) to the Big roof connector (G), insert the Bottom short middle tube (F2) to the Long cross beam ...
- Page 17 17 / 22 Assembly Assembling the Small Roof Deeply inert the Small roof oblique tube (I) to the Small roof connector (H) to the end (Fig.1), put the small canopy on the small roof and align the corners (Fig.2). Screw the Top decoration (J) on the roof (Fig.3)，pull the Small roof oblique tube (I) back to fit the holl. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 18 18 / 22 Assembly Attaching the Small Roof Put the big canopy (M) on the assembled big roof (D1), connect the assembled small roof (I) with the big roof (D1) using the spring button on the parts before spread the big canopy (M). NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 19 19 / 22 Assembly Spreading the Big Canopy Spread the Big canopy (M), and first aligning the 4 corners to the Oblique Tubes (D3). Then aligning the big canopy to the middle tube (E1&E2). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 20 20 / 22 Assembly Attaching the Curtain and Netting Hang the Mosquito Netting (N) on the Mosquito Netting Bar (C1, C2, C3, C4) using Plastic Ring (CC). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
- Page 21 21 / 22 Assembly Securing the Gazebo Secure the assembled gazebo to the lawn with the Stakes (BB). It is recommended for anchoring on wood or concreate surface for more stability using setscrew (Purchased separately) NOTE: To avoid destroying the finish, do not put the parts on the ground directly. Country of Origin: China...
-
Page 22: Limited Manufacturer's Warranty
Periodically check and ensure that all bolts are well‐tighten during use. Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of months from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
