- Page 1 ITEM NO.： A101012300 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com Country of Origin: China Production Number: xxxxxxxxxx...
- Page 2 2 / 7 Parts List Description Label Part# Image Post P00020058701 Long screen P000400886 Short screen P000400887 Mid beam P000501164 connector Hook P005800001 Slanting beam P000601329 upper bar Slanting beam P000601331 lower bar Middle beam P000601330 Big top P000501163 connector...
- Page 3 3 / 7 Hardware Pack 1 Label Description Part# Image M6X20 Bolt H100010047 32PCS M6 flat washer H050030001 8 PCS M6X25 bolt H100010086 16 PCS M6 nut H040010004 8 PCS M6X35 bolt H100010069 40 PCS Φ6*230 floor stake H070010001 8 PCS...
- Page 4 4 / 7 Fig .1：Put stake cover (M1) Fig.2-1 ：Attach short screen Fig.2-2: Attach middle beam through Post(A1) and lift up (C1) to long screen(B1). lower connector(D3) to long stake cover, then attach stake screen(B1) and short screen(C1), slate (L) to bottom of post (A1) by using bolt(AA).
- Page 5 5 / 7 Fig.7 ：Insert slanting Fig.8：By using bolt(EE),washer Fig. 6 ：Insert the inclined beam beam(F1) into big top (BB),nut(DD), attach slanting down tube (F2) into the inclined connector(H1). beam lower bar(F2) to post beam (F1) and snap the spring buckle on the inclined beam down (A1).
- Page 6 6 / 7 Fig.16 ：Fix big canopy four Fig.15：Fix middle canlpy Fig.14：Fix small canopy four corner(P1) to adjustable four corner (Q1) to big corner(R1) to big top slanting adjust lower bar（F2） ，then adjust big tube(I),then top slanting beam upper bar （ F1 ） ,then adjust length till canopy tight. top end tube till canopy tight. ...
- Page 7 If necessary, wash with a mild solution of soap and water; rinse thoroughly and dry completely. Periodically check and ensure that all bolts are well‐tighten during use Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 1 year from the date of purchase, provided the item was factory‐sealed at the time of purchase and is maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within this warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of purchase; however, transportation and ...
