Summary of Contents for Saris Stack18
- Page 1 Customer Service 800.783.7257 STACK RACK sarisinfrastructure.com INSTALLATION...
- Page 2 Tell Us What You Think sarisinfrastructure.com/feedback Register your product for updates sarisinfrastructure.com/registration...
- Page 3 Most of all, it is easy to assemble and maintain. Please read and understand the following instructions before beginning your installation. Everyone here at Saris wants you to be happy with this product. Please contact us (sales@sarisinfrastructure.com, 800-783-7257) should you need anything.
- Page 4 Figure 1 Figure 1...
- Page 5 Single-Sided Configuration "A" "B" "D" "E" "F" "H" "I" "J" "K" "L" "M" 17" (43.2cm) Handlebar Spacing 4 Bike 27"(68.6cm) 17" (43.2cm) Handlebar Spacing 6 Bike 44"(111.8cm) 17" (43.2cm) Handlebar Spacing 8 Bike 61"(154.9cm) 9” 17" (43.2cm) Handlebar Spacing 10 Bike 78"(198.1cm) (22.9cm) 17"...
- Page 6 18" (45.7cm) Handlebar Spacing 14 Bike 116.5"(295.9cm) 18" (45.7cm) Handlebar Spacing 16 Bike 134.5"(341.6cm) 24" (61.0cm) Handlebar Spacing 4 Bike 33.5"(85.1cm) 24" (61.0cm) Handlebar Spacing 6 Bike 57.5"(146.1cm) 16.5" 96" 24" (61.0cm) Handlebar Spacing 8 Bike 81.5"(207.0cm) (41.9cm) (243.8cm) 24" (61.0cm) Handlebar Spacing 10 Bike 105.5"(268.0cm) 24"...
- Page 7 Handlebar Spacing 17” 19” 17” 1.47” (43.2 cm) (48.3 cm) (43.2cm) (3.7 cm) 18” 19” 18” 1.47” (45.7 cm) (48.3 cm) (45.7 cm) (3.7 cm) 24” 24” 24” 1.47” (61.0cm) (61.0 cm) (61.0cm) (3.7 cm) Handlebar Spacing 17” 19” 17” 1.47”...
-
Page 8: Parts List
Parts List... -
Page 9: Frame Assembly
Frame Assembly Install A (upper cross beam) into F (frame uprights). The beam should overhang the mounting brackets by 5 inches Install A (upper cross beam) into F (frame uprights). (12.7cm). The beam should overhang the mounting brackets by 5 inches (12.7cm). - Page 10 1. Install M (mounting plates) using P (M10 x 30mm car- riage bolts), S (M10 nylock nuts) and W (washers). 2. With all mounting plates installed tighten bolts evenly to 30 ft/lbs (41 Nm) min 3. Install AA (cross beam end plug) in either end of upper cross beam...
- Page 11 • 3/8” drive ratchet • Marker or Pencil • 7/32” hex key Anchor Installation • Level *DO NOT THROW AWAY THE PENTA SOCKET AFTER COMPLETING THE INSTALLATION. YOU WILL NEED IT TO REMOVE THE EQUIPMENT IF THAT IS NECESSARY. DO NOT THROW AWAY THE PENTA SOCKET AFTER COMPLETING THE INSTALLATION. YOU WILL NEED IT TO REMOVE THE QUIPMENT IF THAT IS NECESSARY.
- Page 12 4. Before starting to drill the hole, it is important that eye and ear protection are used. Make sure the hammer drill is in the hammer mode and start drilling your hole. Con- tinue drilling until the tape on the bit or the drill gauge meets the base material- this means that the required depth has been reached.
- Page 13 h the open side up. Tap lightly to get the anchor flush with the base material. ert it into the anchor. Strike the setting tool with the hammer several times until the set tool nsure the anchor is properly set. 6.
- Page 14 1. Once drop in anchors are installed install studs and nuts but leave K (lower cross beam tie down) and B (lower cross beam) loose until lower trays are installed.
- Page 15 Lower Stall Installation 1. Place G (lower stall with riser) and J (lower mounting bracket) into the fi rst bike position working from left to right. 2. Install R (M8 x 16mm carriage bolts) with X (washers) and U (M8 locknuts). Tighten to 8 ft/lbs (11 Nm) 3.
- Page 16 Roller Beam Installation 1. Align E and I (upper mounting tubes) directly above lower stall. The high mount (I) and low mount (E) must correspond with the high and low mounted lower stalls. The fi rst mounting tube bracket should be fl...
- Page 17 Wheel Stop Installation 1. Align C (wheel stop) with holes in mounting tubes on the right side of the mounting tube. Install stop tube using N (3/8 x 4.0” bolt) with W (washer) and T (3/8 lock nut) as shown above. 2.
- Page 18 Upper Stall Installation 1. Slide Z (steel axle) into Y (roller) and evenly space ends. 2. Place D (upper bike stall) onto upper mounting tube. 3. Align lower front mounting holes with roller and axle and install O (3/8 x 3.0” bolt) and V (3/8 thin locknut). 4.
- Page 19 (3) its failure resulted from a defect in material or workmanship and not from normal wear expected in the use of the product; (4) the product or part is delivered, freight prepaid, to Saris Products.
