SWA-54 & SWA-60 Semi-Automatic Stretch Wrap Machines

Receiving instructions:

After delivery, remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete description

of it on the bill of lading. If the product is undamaged, discard the packaging.

NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Replacement Parts and Technical Assistance:

For answers to questions not addressed in these instructions and to order replacement parts,

labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The

department can also be contacted online at http://www.vestilmfg.com/parts_info.htm.

Specifications..................................................................................................................................

Signal Words...................................................................................................................................

Hazards of Improper Use....................................................................................................................

Introduction.....................................................................................................................................

Installation..................................................................................................................................

Carriage / Stretch Wrap Holder Assembly (SWH)....................................................................................

Chain Tensioning Procedure..............................................................................................................

Using the Wrapping Machine..........................................................................................................

Delta Motor Speed Controller (DMSC).................................................................................................

Parameter Settings (DMSC)..............................................................................................................

SWA-54 Exploded View & Bill of Materials...........................................................................................

SWA-60 Exploded View & Bill of Materials...........................................................................................

Carriage Subassembly Exploded View & Bill of Materials........................................................................

Manual Counterbalanced Mast Subassembly Exploded View & Bill of Materials..........................................

Turntable Electrical Circuit Diagram....................................................................................................

Powered Mast Electrical Circuit Diagram..............................................................................................

Record of Normal Condition..............................................................................................................

Inspections & Maintenance...............................................................................................................

Labeling Diagram............................................................................................................................

Troubleshooting.............................................................................................................................

Limited Warranty.............................................................................................................................

Table of Contents

Rev. 4/23/2019

Vestil Manufacturing Co.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586

Fax: (260) 665-1339

Instruction Manual

TABLE OF CONTENTS

SWA-54 MANUAL

Toll Free (800) 348-0868

Web:

www.vestilmfg.com

Page 1 of 17

4 - 5

Need help?

Do you have a question about the SWA-54 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vestil SWA-54

Page 1 Toll Free (800) 348-0868 Fax: (260) 665-1339 Web: www.vestilmfg.com SWA-54 & SWA-60 Semi-Automatic Stretch Wrap Machines Instruction Manual Receiving instructions: After delivery, remove the packaging from the product. Inspect the product closely to determine whether it sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading.
Page 2 SWA-54 MANUAL Specifications Thank you for purchasing a semi-automatic stretch wrap machine made by Vestil Manufacturing Company (“Vestil”). Our wrapping machines are designed to be dependable and incorporate numerous safety-enhancing features. All persons who use or maintain this product must familiarize themselves with the instructions provided in this manual before beginning their duties.
Page 3 To reduce the likelihood of injury: • DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil. Unapproved modifications automatically void the Limited Warranty and might make the product unsafe to use.
Page 4 A. Lift truck or hoist: Equipment to unload the machine from the freight truck and to set it in place at the installation site. B. Concrete surface: The surface must be smooth, level, adequately strong to support the machine (SWA-54 = 1,371 lb.; SWA-60 = 1,444 lb.) and a full capacity load (5,000 lb.).
Page 5 Tube retainer (top) 20-110-002 Bearing, ball, in., shield 68061 in. retainer ring 20-113-022 Spacer, lock 20-113-003 in. fiber washer SRF-18 20in. plastic wrap Not included. The carriage accepts10”-20” rolls. Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 5 of 17...
Page 6 All personnel who use (operate and/or maintain) this machine must understand and apply these instructions. Standard SWA-54 & SWA-60 wrapping machines are suitable for moderate duty, i.e. intermittent cycling with loads up to 5,000 pounds (2,273kg). This machine should only be used indoors in industrial or commercial settings to wrap palletized loads of non-hazardous material.
Page 7 "u 12." Press "UP" or "DOWN" key to scroll through different parameters. Press "UP" or "DOWN" key momentarily will change parameter settings in single-unit increments. Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 7 of 17...
Page 8 7-01 Motor No-load Current d 75 Affects the drive's motor slip compensation. 7-02 Torque Compensation d 10 Controls the motor's maximum start-up torque. Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 8 of 17...
Page 9 11109 16x1 ” ”-18x ” thread cutting 32415 20-016-114 Bracket, clamp, formed screw, type F, zinc Flat washer, low carbon, USS, 33008 20-516-014 Weldment, post bracket z-plated ” Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 9 of 17...
Page 10 Hex bolt, gr. A, zinc finish, ”- 33008 11109 z-plated ” 16x1 ” 20-145-013 Key 20-016-114 Bracket, clamp, formed Lock nut, gr. 2, zinc finish, ”- 37024 20-516-014 Weldment, post bracket Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 10 of 17...
Page 11 20-113-003 in. fiber washer 20-014-005 Frame, tube retainer, (top) 68061 in. retainer ring 20-014-006 Tube, retainer, (bottom) 20-111-002 Bearing, 7R16 20-014-116 Frame, rod, wrap retainer 20-113-022 Spacer, lock Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 11 of 17...
Page 12 Electric Circuit Diagram for Powered Mast to a driven ground rod [Only models with “-PMO” upgrade] (see National Electrical Code for details driven grounding electrodes). Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 12 of 17...
Page 13 Table of Contents Rev. 4/23/2019 SWA-54 MANUAL Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 13 of 17...
Page 14 12. Overall condition: The machine should be clean, square and rigid, and free of rust and corrosion. Periodically clean the surfaces to remove dirt and debris. Do not use the machine if the base is excessively rusted or corroded. Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 14 of 17...
Page 15 Powered mast models: A and B also applied to junction box at base of mast. A (Label 221) B (Label 325) C (Label 287) D (Label 204) E (Label 220) Table of Contents Copyright 2018 Vestil Manufacturing Corp. Page 15 of 17...
Page 16 Check the display on the Delta motor d) Motor controller fault or speed controller for a fault code. If a fault defective motor controller code is displayed, contact Vestil Manufacturing (phone number on cover of this manual). e) Chain is broken or slipping e) If fan of drive motor spins but table does not rotate, release the foot pedal;...
Page 17 Warrantee (you) for warranty service. Who may request service? Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or from an authorized distributor AND Vestil has been fully paid.
