INNO VIEW 5 Pro User Manual page 34

34
Fiber Axis Align Failed
Fiber is Dirty
"Cleaning Arc time" is too short
Fat Splicing Point
Thin Splicing Point
Axial offset （>0.4um）
The motor is not calibrated
There' s dust or dirt on the fiber
surface
Dust or dirt is on the lens or LEDs
Splice the fibers whose cores are
difficult to find by the way of core
alignment.
Too much [Overlap] setting
The motor is not calibrated.
Inadequate arc power
Pre-fuse power or time is set too
high
Insufficient "Overlap" setting
Prepare the fiber (stripping,
cleaning, and cleaving) again.
Do the "Motor Calibration" maintenance.
Prepare the fiber (stripping,
cleaning, and cleaving) again.
Execute the "Dust Check" . If dust or dirt exists, clean the lens-
es or LEDs
Set the "Cleaning Arc time" to 180ms
Splice the fibers whose cores are difficult to find by MM splice
mode (cladding layer alignment).
Adjust or initialize "Overlap" setting.
Calibrate the arc power with the "Arc Calibration" function.
Calibrate the arc power with the "Arc Calibration" function.
Adjust or initialize "Pre-fuse Power" or "Pre-fuse Time" set-
tings.
Adjust or initialize
"Overlap" setting
