System Setting; Time Lock; Time Lock Setting; Remark - INNO VIEW 5 Pro User Manual

8.3 Time Lock

8.3.1 Time Lock setting

① Enter [main menu] - [System Setting] - [System Setting] - [Time Lock]
② Enter device password
③ Available to set up to 6 dates [YY/MM/DD] for Time Lock
④ Press "R" button to reset the date
⑤ Press "o" button to save after setting
⑥ Check save notification on bottom of screen, "Data save done!"
⑦ Device is locked on set dates, enter device password to unlock

8.3.2 Remark

① Passed Time Lock date is deleted
② Not allow to enter "Set Calendar" while Time Lock is working
③ Time Lock uses device password

8.4 System Setting

Parameter
Buzzer
Temperature Unit
Automatic Heating
Dust Check
Pull Test
White LED
Password Lock
Reset
Update Software
Language
Power Save Option
Set Calendar
Change password
Sets the sound volume of the buzzer.
Sets the unit of temperature.
If select [On], when the fiber is placed into heat oven, which will automatically execute heat-
ing.
Check if there is dusk in the imaging area. Set the dust check function, OFF by default, if
select ON, duck check will be performed automaticly when turn on the splicer.
Set the pull test, ON by default, if select OFF, pull test will not be performed. Press RESET
manually for reset.
White LED switch.
Sets to enter system through password.
Restore factory setting.
Splicer software update.
Sets a language to be displayed on the screen.
Sets the time of [Monitor Shut Down], time of [Splicer Shut Down] and LCD brightness.
Sets the system time.
Changes the password to access some menus as [Power on Option] and [Menu Lock].
At the time of shipment from the factory, the password is set as [0000].
If you have forgotten your password after you changed another one, contact the sales agency.
Description
25
