Appendix II
Error Message List
An error message may appear on the screen when using a splicer, the solution precisely as shown in the list below. If it is not
possible to eliminate the problem, maybe some faults occur in the fusion splicer. Consult your sales agency.
Error Message
Left Fiber Place Error
The fiber end-face is placed on the
electrode centerline, or beyond it.
Right Fiber Place Error
The fiber is not set correctly at the
Press Motor Distance Over bottom of the V-groove. The fiber is
Limit not located in the Camera' s field of
view.
Press Motor Error Motor might be damaged.
Search Fiber End face The fiber is not set correctly at the
Failed bottom of the V-groove.
Arc Failure Arc Discharge did not occur.
Align Motor Distance Over The fiber is not set correctly at the
Limit bottom of the V-groove.
The fiber is not set correctly at the
Search Fiber Clad Failed
bottom of the V-groove.
There' s dust or dirt on the fiber
Fiber Clad Gap Wrong
surface
There' s dust or dirt on the fiber
surface
Unknown Fiber Type Mismatch Fibers
Non-standard optical fibers
The fiber is not located in the Cam-
Fiber Clad Over Limit
era' s field of view.
Focus Motor Home posi- The fusion splicer is hit by force
tion Erro during splicing operation.
Too much [Overlap] setting
Fiber End face Gap Wrong
The motor is not calibrated
The fiber is not set correctly at the
bottom of the V-groove.
There' s dust or dirt on the fiber
Motor Distance Over Limit
surface
There' s dust or dirt on the fiber
surface
The fibers on the two sides are not
Fiber Mismatch
the same
Bad fiber end-face
Cleave Angle Over Limit
[Cleave Limit] is set too low.
[Offset Limit] is set too low.
Core Angle Over Limit
Dust or dirt is on the V-groove or the
clamp chip.
Cause
Press the "R" button, and set the fiber end-face between the
electrode centerline and the V-groove edge.
Press the "R" button; re-position the fiber again to seat it cor-
rectly at the bottom of the V-groove.
Consult your nearest sales agency.
Press the "R" button; re-position the fiber again to seat it cor-
rectly at the bottom of the V-groove.
Assure the electrodes are in proper position; Replace the elec-
trodes.
Press the "R" button , re-position the fiber again to seat it
correctly at the bottom of the V-groove.
Press the "R" button , re-position the fiber again to seat it
correctly at the bottom of the V-groove.
Prepare the fiber (stripping, cleaning, and cleaving) again.
Prepare the fiber (stripping,cleaning, and cleaving) again.
Use an appropriate splice mode other than AUTO splice mode
to re -splice.
AUTO splice mode can only identify the standard fibers such
as SM, MM, NZ.
Adjust the fiber position and do "motor calibration" for
maintenance.
Carry out "motor calibration" for maintenance. If the prob-
lem still can' t be solved, contact with agency.
Adjust or initialize [Overlap] setting.
Do [Motor Calibration] maintenance.
Press the "R" button , re-position the fiber again to seat it
correctly at the bottom of the V-groove.
Prepare the fiber (stripping,
Cleaning and cleaving) again.
Execute the [Dust Check] after cleaning the lenses and mirrors.
It may result in large splice loss if you continue to splice,
Please use the proper splice mode corresponding to the fibers.
Prepare the fiber (stripping, cleaning, and cleaving) again.，
Check the condition of the fiber cleaver. If the blade is worn,
rotate the blade to a new position.
Increase the "Cleave Limit" to an adequate limit. (standard
value: 3.0°）
Increase the "Core Angle Limit" to an adequate limit.
(standard value: 1.0°） .
Clean the V-groove or the clamp chip, prepare and reposition
the fiber again.
Solution
