6.3 Delete Heat Mode
⚠ Note:
The gray modes (20mm, 30mm) are the system preset initial heat modes which cannot be deleted
Heat Mode Parameters
Parameter
Template
Name
Note
Heater temperature
Heater time
Preheat temperature
Set sleeve type. List of all heat modes are displayed. Selected mode will be copied to a us-
er-programmable area.
Title for a heat mode.
Title of the heat mode displayed in the upper right corner of the monitor during splicing or
heating process. Max number of characters used is 5.
Sets heating temperature.
Sets heating time from the beginning to the heating completed.
Sets preheat temperature of the heater.
② Select the parameters to be edited.
① Select [Heater Mode] menu.
② Select [Delete Heat Mode].
③ Select the heat mode to be deleted
Description
