Rubbermaid Home Products
Wooster, OH 44691
www.rubbermaid.com
1-888-895-2110
Please check that you have all parts before
beginning and follow the instructions carefully.
Attach Drawer Glide cabinet members (M & N) to Island
1
Sides with Euro Screw (Q) into positions as shown. Make
sure that Drawer Glide marked CR is on the right and the
one marked CL is on the left.
Q
Hole 27
Hole 23
Hole 17
Hole 9
Square Island Kit
3H7400WHT/3H7400MAPLE/3H7400CHERRY
Description
SIDE PANEL
CENTER DIVIDER
TOP FIXED SHELF
BOTTOM FIXED SHELF
KICKPLATE
CAM LOCK
CAM BOLT
5" DRAWER FRONT
10" DRAWER FRONT
DRAWER BOTTOM
10" DRAWER BACK
5" DRAWER BACK
10" DRAWER GLIDE SET
5" DRAWER GLIDE SET
HANDLE WITH SCREWS
COVER CAP WITH RUBBERMAID LOGO
SCREW, EURO 6MM DIA X 13MM LG
EXPANDING DOWEL, (L)
EXPANDING DOWEL, (R)
SCREW, #6 X 3/8" PHILLIPS PAN HEAD
PLASTIC DOOR BUMPER
KICKPLATE BRACKET AND PLINTH CATCH
SCREW, #6 X 1/2" PHILLIPS PAN HEAD
Hole 27
Hole 23
Hole 17
Hole 9
Insert Cam Bolts (G) into Fixed Shelf positions
2
on Island Sides as shown.
Top
Hole
Hole 4
Assembly Letter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
G
Top
Hole
Hole 4
QTY
2
1
2
2
2
20
20
4
4
8
4
4
4
4
8
16
32
8
8
32
16
4
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Square Island Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rubbermaid Square Island Kit

  • Page 1 10" DRAWER BACK 5" DRAWER BACK 10" DRAWER GLIDE SET 5" DRAWER GLIDE SET HANDLE WITH SCREWS COVER CAP WITH RUBBERMAID LOGO SCREW, EURO 6MM DIA X 13MM LG EXPANDING DOWEL, (L) EXPANDING DOWEL, (R) SCREW, #6 X 3/8" PHILLIPS PAN HEAD...
  • Page 2 Insert Cam Locks (F) into Divider Panel. Assemble Divider Panel to Cam Bolts on Island Sides. Note: To lock into place, Cam Locks only require 20 lbs of force and a counterclockwise turn of 180 degrees. Excessive force or over tightening may result in improper assembly or damage to Cam Lock.
  • Page 3 K&L M&N H&I Slide Drawer Back (K&L) onto Drawer Insert L-left and R-right Expanding Place Drawer Bottom (J) onto Drawer Side Bottom at rear of Drawer Sides. Align Dowels (R&S) into Drawer Front Panels (M&N). holes on Drawer Back with Drawer (H&I).
