Producer™ III and IIIN
c.
If the disc is not centered front to back on the print pad, align the
alignment screw until the gap between the raised edge of the disc retainer and the disc is correct.
Everest: 0.063" gap at the front
Disc Retainer
7.
Raise the
lift arm out of the way of the printer tray.
8.
Press the
printer button. The printer tray closes.
disc release button. The gripper releases the disc.
9.
Press the
Tip:
Place your hand under the disc to catch it.
10.
Close the
front door. The autoloader is ready for use.
3
Prism: Disc hangs over the front edge of the print pad by
Gap
printer front to back by turning the front to back
0.010" – 0.015"
Print Pad
Gap
2000538_C
