OPERATION
CONTROL PANEL
Power Switch:
Main power supply to this oven
Cook Timer:
Turn knob to set cooking time. A
buzzer will sound when pre-set time is
up. Turn the knob to OFF to disable the
buzzer. The timer is just a reminder and
is independent of the oven control.
Power Indicator:
Illuminates when the power is
switched to ON position.
HI/LOW Fan Speed:
Use to choose fan speed (HI or LOW)
for cooking.
LIGHTING, RELIGHTING, AND SHUTDOWN INSTRUCTIONS
To light the oven, just switch the power switch at the top left corner of the control panel to the "ON" position.
(The oven is equipped with a direct hot surface ignition system. There is no pilot to light.)
If the burners fail to ignite within four seconds, the oven will automatically shut off the gas. Wait five minutes to
allow the gas that was released to dissipate and try to light the burners again. If the burners still fail to ignite
after three such attempts, the oven will stop trying, even though the power switch is in the "ON" position. To
continue to attempt to light the burners, turn the power switch "OFF" and then "ON" again.
To shut down the oven, switch the power switch to the "OFF" position. For a complete shutdown, also open the
control panel and turn the manual shut-off valve to the "OFF" position.
OPERATING
Turn the power switch to the "ON" position and set the cooking temperature. Choose the desired fan speed (HI
or LOW) using the Fan Speed switch. Switch the Fan Mode switch to COOK. The fan will run continuously when
the oven doors are closed (the fan works independently of the gas system). If this switch is turned to COOL, the
only difference is that the fan will continue to rotate when the oven doors are open. Set the cooking tempera-
ture by turning the Cook Temperature Control until the indicator mark on the knob is pointed to desired
cooking temperature. The HEAT ON indicator will be on when the burners are on and will remain on while the
oven is heated.
Fan Mode:
In COOK mode, the fan runs
continuously unless the door is open.
In COOL mode, the fan runs
continuously even if the doors are
open. This is to cool down the unit
with the door open.
HEAT-ON Indicator:
The HEAT-ON indicator will be on
when the burners are working
xCook Temperature Control:
Turn the knob to desired temperature.
When the pre-set temperature is
reached, the HEAT ON indicator will be
off. The indicator would cycle on-off
Oven Interior Light Switch:`
The light is controlled independently.
