Pin Configuration

Audio Output Connectors

There are two TA-5M connectors on the back of the RX-4.

Analog Out of TA5

AES Digital Out of TA5

The TA-5 connectors can also be used to output AES digital audio. Each TA5 will output a stereo pair on pins
1, 2 and 3 with pin 1 being ground.
IMPORTANT: While sending digital audio, it is necessary that the unit on the other end (recorder, mixer, etc.)
have digital inputs with sample rate convertors, as there is no way to synchronize the output data with the
recorder's digital input.
Power
Connector (Hirose-4 Connector)
Pin 1 – Ground ( - )
Pin 2 – Not Connected
Pin 3 – Not Connected
Pin 4 – DC ( + )
TA5 Out on
QRX
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
TA5 out on
QRX
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
XLR into Camera or
Mixer
PIN 1 XLRs
on both
PIN 2 - Left
PIN 3 - Left
PIN 2 - Right
PIN 3 - Right
XLR into Camera or
Mixer
PIN 1
PIN 2
PIN 3
No Connection
No Connection
