Summary of Contents for Unox Cheftop Mind.Maps XAVC-0511-EPR
- Page 3 SAFETY REGULATIONS SAFETY REGULATIONS FOR INSTALLATION AND MAINTENANCE ...... 4 FORWARD ..........................4 SUPPLIED DOCUMENTS .......................4 REGISTRATION ........................5 EXPLANATION OF PICTOGRAMS ..................5 SAFETY INSTRUCTIONS ....................6 INSTALLATION INSTALLATION CODES AND STANDARDS ..............12 DELIVERY AND INSPECTION ................... 12 HANDLING ..........................
- Page 7 WARNING UNOX accepts responsibility any situation resulting from work carried out in an unprofessional manner, or from the incorrect interpretation or application of regulations. GENERAL INSTALLATION WARNING Incorrect installation or any modifications made to the appliance may damage property or result in injury or even death.
- Page 8 flammable ingredients (alcohol-based foods) in the oven. These substances may burst into flames and, therefore, constitute a fi re and explosion hazard. Explosions may cause the door to open suddenly or even violently. WARNING Fire risk! When using the appliance for the first time, make sure there are no instruction manuals, plastic bags, or accessories inside the oven.
- Page 9 WARNING Burn risk! Take extra care to avoid drips or spills when removing trays containing hot liquids. WARNING Burn risk! The maintenance operations of the unit must be carried out by qualified and trained personnel only when the appliance is empty and disconnected from power supply and water connections.
- Page 10 INSPECTION AND MAINTENANCE WARNING Injury risk! When loading and unloading the tray rack trolley, apply the wheel lock brake. WARNING Injury risk! Tray rack trolleys may tip over when wheeled along uneven surfaces or when crossing the threshold of a door. WARNING Electrocution and burn risk! To reduce the risk of fire and/or electric shock do not remove the service panels.
- Page 11 WARNING Injury risk! Before any maintenance work is performed, the appliance must be disconnected from the electrical supply. Apply a lock out tag to the electrical supply connection. WARNING Injury risk! All parts not supplied by UNOX must be pre-approved before installation.
- Page 12 National Fire Pro- must be retained for inspection. tection Association, Batterymarch UNOX does not assume liability for Park, Quincy, MA 02269. loss or damage of the appliance - 3.Vapor Removal from Cooking during shipping and/or delivery.
- Page 16 TECHNICAL DATA Trays Dimensions Weight* Oven model** N° Trays type [inches - mm] [lbs - Kg] XAVC-0511-EPR 29” x 30” x 26” 750x773x675 154 lbs - 70 kg 17/32 7/16 9/16 XAVC-0511-MPR 29” x 30” x 26” 750x773x676 154 lbs - 70 kg 17/32 7/16...
- Page 25 Three-Phase Cable Attached to a Terminal Board Select the proper cable. Open the lower part of the back panel. Route the power supply cable through the cable clamp. Remove the screws holding the control panel components. Connect the wires to the correct terminals.
- Page 32 Unox, Inc.’s designee and are properly used as set forth in Unox, Inc.’s specifi cations and instructions of use, be in material compliance with Unox, Inc.’s documentation and literature, and (b)
