Summary of Contents for Unox Bakerlux Speed.Pro XESW-03HS-EDDN
- Page 2 DoCUMEnts In DIGItaL FoRMat to download the documentation in digital format and the full user manual, log in to UNOX http://infonet.unox.com | http://unox.com. After registering on the portal, you will need to enter some information about your UNOX product: ■...
- Page 3 Dear Installer and Customer This manual contains all the information you need to use, install and maintain this appliance correctly. Please read it carefully before assembling the appliance and store it safely for future reference. If you do not fully understand any of the contents, please contact the manufacturer for further information.
- Page 5 saFEty InFoRMatIon FoR InstaLLInG tHE aPPLIanCE General precautions Read this manual carefully before installing the appli- ■ ance. Store this manual with care for future reference. Failure to comply with the safety regulations, and any ■ installation or maintenance other than those indicated in this manual voids the warranty* and relieves the man- ufacturer of all liability.
- Page 6 The appliance must be transported using means suitable ■ for its weight and size. Please use personal protective equipment (PPE - gloves, safety shoes, etc.). If the appliance is installed on a mobile base or ■ stacked, only use components supplied by the manu- facturer and follow the assembly instructions provided in the packaging.
- Page 7 Warnings for the electrical connections Before installing the appliance, check that the systems ■ are compliant with the installation standards in the specific country and with the specifications indicated on the appliance serial plate. The electrical system is designed according to the IEC ■...
- Page 12 after waiting for the appliance to cool down fully; ■ only if you are in good mental and physical condi- ■ tion, and are wearing suitable personal protective equipment (e.g. heat-resistant rubber gloves, eye protection, dust mask (optional), etc.). Do not clean the appliance with a steam or pres- ■...
- Page 20 PosItIonInG the installation area Install the appliance in areas: ■ dedicated and conforming to the cooking of industrial foods; ■ that are adequately ventilated; ■ that comply with the laws in your country regarding system safety/ safety in the workplace; ■...
- Page 22 Before securing the appliance to a substructure or UNOX stand, always check they are perfectly level using a manual or digital spirit level. If the UNOX stand is not level, adjust the feet as necessary. Take care not to unscrew them completely.
- Page 27 ■ be connected to the mains earth (yellow and green wire); ■ be connected to a thermal differential switch in compliance with the regulations in force (0.03A, type A). ■ Compliance with this requirement is considered to be met if the in- struction concerning disconnection incorporated in the fixed wiring is in accordance with AS/NZS 3000.
- Page 28 How to connect the electrics The appliance leaves the factory with the power cable already fitted on the terminal board; the electrical connection must be made by: ■ A | fitting a power plug (not supplied) of a suitable type and load for the maximum power absorbed by the oven’s phases (data available on the attached “Technical specifications”...
- Page 32 ConneCting staCked applianCes (MaXi.link) The appliances are designed to be connected to accessories such as a prover. The accessories connect to the oven using automatic connectors on the back of the oven. Follow the instructions contained in the accessory and appliance packaging for information on how to fully install and manage them.
- Page 43 CERtIFICatIon EU declaration of conformity for electrical appliances Manufacturer: UNOX S.p.A. Address: Via Majorana, 22 - 35010 Cadoneghe, Padua, Italy Declares, under its own responsibility, that the product SPEED.Pro™ complies with the Machinery Directive 2006/42/EC through standards: EN 60335-1: 2014 + A11:2014...
- Page 45 The manufacturer reserves the right to make changes to improve the appliances and accessories at any time without advance notice. Full or partial reproduction of this manual is forbidden without the consent of the manufacturer. The measurements provided are approximate and not binding. In the event of disputes, this document was originally written in Italian.
