GE 262E1 Manual page 2

Main Solenoid
Contacts
A
Motor
Armature
Run/Tow
Switch
Key Switch
PC/Run Switch
Main Solenoid Coil
For
Rev
Foot Pedal
Reverse
Alarm
Diagram shows the back (wire) side of Connector
49-Tomberlin Emerge (262E1_262TB1_403TB1) Install Sheet-370 Rev 02 11/29/18
48V Battery Pack
+
262E1, 262TB1,
B+
403E1, 403TB1
A1
A1
Controller
A2
A2
P1
(B+ from Run/Tow Switch)
P6
(Key Switch In)
P2
(B+ from Run/Tow Switch)
P11
(Main Solenoid Out)
P17
(Main Solenoid Out) 403E1/TB1 model
P4
(Forward In)
P5
(Reverse In)
P3
(Pedal Switch In)
P10
(Backup Alarm Out)
-
B-
F1
F2
P15
(Speed Sensor Supply Out)
P14
(Speed Sensor In)
P16
(Speed Sensor Return Out)
(Pot Wiper In)
F1
Motor
Field
F2
Speed
Sensor
B+
Sense
0-5V
Circuit
OR
PCB
B-
P7
Option #1 (Obsolete)
Tomberlin Converter
OR PCB w/E-Z-GO ITS
B+
0-5V
Circuit
TOMBERLIN ITS
B-
Option #2 (Current)
Tomberlin p/n: 1007918 & 1008284
Sheet 2 of 4
E-Z-GO
ITS
Sense
