EMX Industries OWL Instruction Manual

Instruction Manual
The OWL is a vehicle motion and presence sensor that utilizes microwave and infrared technology to
activate automatic doors and industrial gates. The OWL's microwave sensor detects moving vehicles, while
the infrared presence sensor can detect vehicles and pedestrians. The sensor features two relay outputs,
one for vehicle motion detection, and the other for presence detection. The OWL features settings for fine-
tuning the presence detection area, direction detection, hold time, and more.
The OWL-RC remote control is required for programming and servicing the OWL.
Cautions and Warnings
Install the OWL according to instructions from the door operator manufacturer. Comply
with all applicable codes and safety regulations.
When drilling, ensure no damage can be caused in desired mounting location, e.g. hidden
wires, waterlines, etc.
Specifications
Mounting Height
Supply Voltage
Max Current Draw
Operating Temperature
Operating Humidity
Dimensions
Connection
Weight
Environmental Rating
Vertical Directionality
Horizontal Directionality
Operating Frequency
Detection Range
Relay Output
Relay Contact Rating
Relay Hold Time
Adjustable Tilt Angle
EMX Industries, Inc.
OWL_Rev1.0_092220
OWL
™
Microwave Motion & Infrared Presence Sensor
11.5-21.3 ft (3.5-6.5 m)
12-24 VDC/AC
150 mA @ 12 VDC
-4 to 140ºF (-20 to 60ºC)
Below 80%
9" (229 mm) x 5" (127 mm) x 5" (127 mm)
32 ft (10 m) 8 conductor cable directly from sensor
2.87 lbs (1.3 kg)
IP65
16-32º wall or ceiling mount
±10º
Microwave (Vehicle Motion)
24.150 GHz
Depends on sensor height and
housing angle
Max. Range: 23 ft (7 m)
Max. Width: 19.7 ft (6 m)
NO or NC (adjustable)
Max. 48 VDC
Max. 300 mA
Typ. 500 ms
-10 to 25º
Tech Support: 216-518-9889
technical@emxinc.com
Infrared (Presence)
Depends on sensor height and
housing angle
Max. Range: 18 ft (5.5 m)
Max. Width: 26.2 ft (8 m)
NO or NC (adjustable)
Max. 48 VDC
Max. 300 mA
Presence (30 sec to Infinite, adjustable)
