PRO3
3-Series Control System
®
Supplemental Guide
Crestron Electronics, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Crestron 3 Series

Summary of Contents for Crestron 3 Series

  • Page 1 PRO3 3-Series Control System ® Supplemental Guide Crestron Electronics, Inc.
  • Page 2 Crestron Electronics, Inc. in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.

  • Page 3: Table Of Contents

    Contents Introduction Configuration About ........................2 Ethernet Settings..................... 2 LAN ......................2 Control Subnet ................... 5 DNS Servers ....................7 Advanced Settings ..................8 MyCrestron ....................9 Ethernet Diagnostics ................10 Application Settings ....................11 Register and Unregister Programs ............11 Start and Stop Programs .................

  • Page 5: Introduction

    The PRO3’s Nav Pad and LCD display can be used to configure and monitor the PRO3’s operations. Alternatively, Crestron Toolbox™ and the PRO3’s built-in web interface can also be used. For details, refer to the Crestron Toolbox help file and the AV3/PRO3 DO Guide (Doc. 7721) at www.crestron.com/manuals. Configuration Press HOME to display the Main Menu, shown below.

  • Page 6: About

    About Select About to display the About menu. The About menu displays the PRO3’s IP address, hostname, MAC address and firmware details. About Menu About IP Address: 172.30.16.25 Hostname: PRO3-7F28F5E6 MAC Address: 00:10:7e:26:f6:c3 Firmware Version: v1.010.0060 Firmware Details To view firmware details, press up or down on the Nav Pad to highlight Firmware Details, and then press the center button of the Nav Pad.
  • Page 7 LAN Settings Menu LAN Settings Current Settings Static Settings Select Current Settings to view the current settings, or select Static Settings to manually change the settings. Current Settings Selecting Current Settings displays the settings for DHCP operation, hostname, IP address, subnet mask, default router, and domain name. Static Settings Selecting Static Settings allows editing of the DHCP settings, host name, IP address, subnet mask, default router, and domain name.
  • Page 8 Use the up and down buttons on the Nav Pad to browse the list of possible characters. Press and hold the left button on the Nav Pad to delete a character. Press and hold the right button on the Nav Pad to insert a character. Press the center button of the Nav Pad to save the new hostname.

  • Page 9: Control Subnet

    Nav Pad. To cancel the operation and return to the previous screen, press BACK. • Domain shows the domain name crestron.crestron.com. Highlight the default router, and then press the center button of the Nav Pad to change it. Edit Domain Name Screen Edit Domain Name [C]RESTRON.CRESTRON.COM...
  • Page 10 Nav Pad. For details on using routing prefixes, refer to the “IP Considerations Guide for the IT Professional Design Guide”, (Doc. 4579) at www.crestron.com/manuals. NOTE: If the Automatic mode is on, the routing prefix cannot be changed.

  • Page 11: Dns Servers

    4. To save the routing prefix and return to the previous screen, press the center button of the Nav Pad. To cancel the operation and return to the previous screen, press BACK. Port Forwarding Select Port Forwarding to view the list of ports dedicated to the control subnet. Highlight a port, and then press the center button of the Nav Pad to view details about that port in a new screen.

  • Page 12: Advanced Settings

    The PRO3 can use SSL encryption for web services. For details on using SSL, refer to the 3-Series Control System Reference Guide (Doc. 7150) at www.crestron.com/manuals. To enable and configure SSL, press up or down on the Nav Pad to highlight SSL, and then press the center button of the Nav Pad to view the possible settings.

  • Page 13: Mycrestron

    To use the PRO3 with the MyCrestron.com dynamic DNS service, perform the following procedure: 1. Use a PC with Internet Explorer to navigate to http://www.mycrestron.com, and register the system with Crestron . Use the information provided from the ® MyCrestron website to complete the information on the “MyCrestron” screen shown in step 2.

  • Page 14: Ethernet Diagnostics

    Select Ping Def. Router to test the router connection. When the test is completed, the results are shown on the display. To verify external communications, select Ping Crestron.com. When the test is completed, the results are shown on the display.

  • Page 15: Application Settings

    PCs (including any PC using Crestron Toolbox to connect to the processor over Ethernet). NOTE: Changing the CIP Port to something other than 41794 results in disabling access to this setup program from a Web browser. In order to re-enable access, use Crestron Toolbox to connect to the control system, and set the CIP Port back to 41794.

  • Page 16: Ip Table

    IP Table The IP table of a running program can be viewed by pressing up or down on the Nav Pad to highlight IP Table, and then pressing the center button of the Nav Pad. Press BACK to return to the previous screen. NOTE: If a program is not running, its IP table cannot be displayed.

  • Page 17: Relays

    Relays Select Relays to monitor and control the status of the built-in relays. I/O Control - Relays Screen I/O Control - Relays Relay 1, State = Closed Use Left/Right to navigate Use ‘Select’ to toggle relay state Closed relays are indicated in red while open relays are indicated in black. To toggle a relay between the open and closed states, press left or right on the Nav Pad to highlight the desired relay, and then press the center button of the Nav Pad to toggle its state.
  • Page 18 Com Port 1 Monitor Screen Com Port 1 Monitor Tx = Rx = Recording Select = Record/Pause Up/Down = Scroll Data Left = Clear Data Right = Setup Port The monitor displays incoming and outgoing data. Transmitted data is displayed in red and received data is displayed in green.

  • Page 19: Diagnostics

    Diagnostics Select Diagnostics to display the Diagnostics menu. Diagnostics Menu Diagnostics Reset Peak CPU Load Tasks The Diagnostics menu is used to provide information about the control system, connected devices, hardware configuration, and error logs. Press up or down on the Nav Pad to highlight the desired information, and then press the center button of the Nav Pad to display details.

  • Page 20: Screen Setup

    Press up or down on the Nav Pad to highlight Yes or No, and then press the center button of the Nav Pad. Screen Setup Select Screen Setup to adjust the front panel display’s brightness and timeout settings. Screen Setup Menu Screen Setup Brightness Timeout...
  • Page 21 This page is intentionally left blank. PRO3: 3-Series Control System • 17 Supplemental Guide – DOC. 7330D...
  • Page 22 Crestron Electronics, Inc. Supplemental Guide – DOC. 7330D 15 Volvo Drive Rockleigh, NJ 07647 (2033000) Tel: 888.CRESTRON 06.15 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
