INSTALLATION GUIDE
NI PS-15/16/17 Panel Mount
Brackets
Bracket and Mounting Dimensions
This document provides the installation procedure for the
NI PS-15/16/17 Panel Mount Brackets. Use accessory 199432-01 to
mount NI PS-15/16/17 power supplies without using a DIN-Rail.
This section provides dimensions for the brackets and the finished
assemblies when the brackets are attached to the power supply. Table 1
provides a summary of the dimensions when the panel mount brackets
are mounted to a specific power supply, and Figure 1 provides a visual
representation for quick reference. The Unit column lists the available
power supplies. The A column provides width dimensions for each power
supply. The B column provides the distance between the center of a bracket
to the outside edge of the specified power supply when properly installed.
The C column provides the distance between the center of each bracket
when installed properly onto a specified power supply.
Advertisement
Table of Contents
Related Manuals for National Instruments NI PS-15
Summary of Contents for National Instruments NI PS-15
- Page 1 NI PS-15/16/17 Panel Mount Brackets This document provides the installation procedure for the NI PS-15/16/17 Panel Mount Brackets. Use accessory 199432-01 to mount NI PS-15/16/17 power supplies without using a DIN-Rail. Bracket and Mounting Dimensions This section provides dimensions for the brackets and the finished assemblies when the brackets are attached to the power supply.
- Page 2 Table 1. All measurements are in millimeters. + + - - OUTPUT INPUT N L PE Figure 1. Assembly Dimension Variables NI PS-15/16/17 Panel Mount Brackets Installation Guide ni.com...
- Page 3 Detach the two aluminium brackets by removing the four screws with a Torx 10 screwdriver, as shown in Figure 3. © National Instruments Corporation NI PS-15/16/17 Panel Mount Brackets Installation Guide...
- Page 4 Detach the plastic slider, as shown in Figure 4. Figure 4. Removing the Plastic Slider Do not over-tighten the screws. The recommended tightening torque is Caution 0.6 Nm/5.3 lb. in. NI PS-15/16/17 Panel Mount Brackets Installation Guide ni.com...
- Page 5 Figure 5. Mounting the Steel Brackets Figure 6 provides a view of the assembly as it should appear when complete. Figure 6. Power Supply with Panel Mount Brackets Installed © National Instruments Corporation NI PS-15/16/17 Panel Mount Brackets Installation Guide...
- Page 6 Where to Go for Support The National Instruments Web site is your complete resource for technical support. At you have access to everything from ni.com/support troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers.
- Page 7 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your...
