Swegon CASA
in combination with ground source heat pump
Installation, operation and maintenance instructions
for design engineers, installation engineers and service personnel
Products
For 250 mm duct; SDHW 250F
• CASA W2504F air heater/cooler, fully insulated
• SET connection unit
• Temperature sensor, cable length 3 m
• Wall / ceiling mounting bracket
• Coarse filter
General Description
Outdoor air duct mounted heating / cooling unit.
In the winter the unit heats the air taken in and ensures
that the ventilation unit operates with the greatest effi-
ciency even in extreme cold.
In the summer, the medium in the ground circuit is used
to cool the building.
NOTE! The manual's original language is English.
SDHWM_d_EN–m
(LVI nro. 7906808)
®
Air heater/cooler
Accessories
• Condensate hose: 502130
Planning
Take into account the duct battery's capacity for the
established airflows when sizing the depth of the ground
source heating well (see Technical data). Take the pressure
loss caused by the duct battery into consideration when
sizing the airflows.
The duct battery must always be mounted horizontally,
so that condensate which is formed is led to a drain as
planned.
Reserve at least 500 mm servicing space at the sides of the
unit.
