Skytech RC-AA-PROGR Instruction Manual

IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
This remote control system was developed to provide a safe, reliable, and user-friendly remote control system for gas
heating appliances or other compatible appliances. The system can be operated manually from the transmitter.
When you start up the remote, if a low battery signal appears or if the LCD screen
does not illuminate when you touch it, check battery position and if the batteries are
fully charged
.
TRANSMITTER BUTTONS
1. [MODE] - Switches the appliance on/thermo/off.
2. [PROG] - Turns on and off the program function.
3. [SET] - Used in different functions to confirm settings.
RC-AA-PROGR Remote Control Thermostat
INSTRUCTION MANUAL
NOT ATTEMPT TO INSTALL OR OPERATE
The receiver wires must be connected to the thermostat leads on your appliance.
Refer to your appliance manual for proper wiring instructions.
The transmitter operates on 4 AAA 1.5V batteries
that are included. Install the batteries
supplied with the unit into the battery
compartment. It is recommended that
ALKALINE batteries always be used for this
product. Be sure the batteries are
installed with the (+) and (-) ends facing the
correct direction.
1. BATTERY ICON - Battery power is low. See SETUP STEP 2.
2. ROOM - Indicates CURRENT room temperature.
3. SET - Indicates desired SET room temperature for THERMO operation. See
PROGRAM STEP 1.
4. FAHRENHEIT/CELSIUS - Indicates Fahrenheit/Celsius. See SETUP STEP 5.
5. FLAME- Indicates appliance is ON.
6. MODE – Indicates operation mode of system. See SETUP STEP 6.
7. UP and DOWN touchscreen icons – These are used to adjust the Time, Set
temperature, and Program functions.
8. TIME and PROGRAM TIME – Indicates current time or program time setting
when editing program settings.
9. LOCK - Child lock out. See SETUP STEP 3.
10. PROGRAM ON/OFF – Indicates when Program 1 (P1) is on or off, and
indicates when Program 2 (P2) is on or off. See PROGRAM STEP 4.
11. DAY of WEEK - Indicates current day of week, or program segment when
editing program settings.
