Introduction
This document describes the procedure for
upgrading the PXW-Z750 to the latest version.
First save the upgrade data to an SD card, and
then use the menu to perform the upgrade.
For details on using menus, refer to the operating
instructions manual.
Upgrade Procedure
Upgrade the version using the following
procedure.
1
Check the current version "Checking the
Current Version".
2
Upgrade the camcorder to the latest version
"Upgrading the Camcorder to the Latest
Version".
3
Upgrade the network function to the latest
version "Upgrading the Network Function to
the Latest Version".
© 2020 Sony Corporation
Getting Started
Notes on Performing Upgrade
• For details about obtaining the upgrade files,
contact your Sony dealer.
• Be sure to use the AC adaptor (AC-DN10/DN10A
or AC-DN2B) when performing the upgrade. If a
battery is attached at the same time, upgrading
is still supported if the AC power supply is
interrupted.
• Disconnect connected devices (such as USB
wireless LAN module (IFU-WLM3), SDI, HDMI,
microphone, viewfinder, and lens) and eject any
media in the SxS memory card slots before
upgrading.
• Upgrading of the camcorder and network
function are not possible if the streaming
function is enabled. First, disable the streaming
function by setting the following menu settings
to Off.
– Maintenance >Streaming >Setting
– Maintenance >Network Client Mode >Setting
• Check the operation of the camcorder before
using the camcorder after upgrading.
For details about using the camcorder, refer to the
operating instructions manual.
About the Required SD Cards
Prepare an SD card for each step shown in the
following table, and use each card only in the
corresponding procedure.
Current version
SD card slot
All versions
UTILITY SD card
slot
All versions
PROXY SD card
slot
Notes
• For details about supported SD cards, refer to
the operating instructions manual.
• Always use SD cards that are formatted using
the format function of the camcorder.
• When copying an upgrade file to an SD card,
copy the file directly to the card without creating
any folders.
Do not copy multiple files (with .bin file name
extension) to the same SD card.
PXW-Z750
SD card
Camcorder
upgrade SD card
Network function
upgrade SD card
5-021-420-11 (1)
Advertisement
Related Manuals for Sony PXW-Z750
Summary of Contents for Sony PXW-Z750
- Page 1 Getting Started This document describes the procedure for Notes on Performing Upgrade upgrading the PXW-Z750 to the latest version. First save the upgrade data to an SD card, and • For details about obtaining the upgrade files, then use the menu to perform the upgrade.
- Page 2 Upgrading Select [Execute] twice. The upgrade begins, the REC indicator flashes, and a message appears. Version Upgrade Checking the Current Version Elapsed Time xx:xx:xx Executing... xx% Use the following procedure to check the current (xx:xx:xx elapsed time format, xx% progress version.
- Page 3 (.bin file name extension) extracted Note in step 2 to the root directory of the SD card. If the upgrade is still unsuccessful after attempting to resolve the error, contact your Sony Note dealer. Do not save any files other than the upgrade file above on the SD card.
- Page 4 If the upgrade was interrupted If an error occurs with the version upgrade file, the following message appears. Version Upgrade NG: Cannot Read Power Off Copy the correct file to the SD card, restart the camcorder, and then try upgrading again. If the upgrade failed If the upgrade fails, the following message appears.
