  • Page 1 Cerberus PACE, Novigo, Cerberus PACE Compact, Novigo Core Loop isolator (100V) PCA2005-A1 Technical Manual A6V11571319_en--_b Smart Infrastructure 2020-12-30...
  • Page 2 All rights created by patent grant or registration of a utility model or design patent are reserved. Issued by: Siemens Switzerland Ltd. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug Tel. +41 58 724-2424 www.siemens.com/buildingtechnologies Edition: 2020-12-30 Document ID: A6V11571319_en--_b © Siemens Switzerland Ltd, 2020 2 | 34 A6V11571319_en--_b...
  • Page 3: Table Of Contents

    Table of contents About this document ................5 Applicable documents ................. 8 Revision history ..................10 Safety .......................11 Safety notes ....................11 Safety regulations for the method of operation ...........12 Standards and directives complied with............14 Release notes....................14 Cyber security disclaimer ................15 Structure and function ................16 Description ....................16 Planning ....................17 Loop audio matrices ..................17...
  • Page 4 Fig. 4: Loop without loudspeakers at loop isolators and with loudspeakers between the loop isolators ....................18 Fig. 5: Equipment view, loop isolator (100 V) PCA2005-A1 ........20 Fig. 6: Pin assignments for loop and loudspeakers..........21 Fig. 7: Loop audio matrix, loop circuitry ..............21 Fig.
  • Page 5: About This Document

    About this document Applicable documents 1 About this document Retention and availability NOTICE Missing information Damage due to misuse ● This document must be available in a usable format throughout the entire life cycle of the product. Keep the document for reference and ensure that it can be accessed by target groups.
  • Page 6 About this document Applicable documents Target groups The information in this document is intended for the following target groups: Target group Activity Qualification ● ● System owner According to EN 50110-1, 'This person can be the owner, 'nominated person with the overall employer, proprietor or a delegated responsibility to ensure the safe person.'...
  • Page 7 About this document Applicable documents Document identification The document ID is structured as follows: ID code Examples ID_languageCOUNTRY_ modification index A6V10215123_deDE_a -- = multilingual or international A6V10215123_en--_a A6V10315123_----_a Date format The date format in the document corresponds to the recommendation of international standard ISO 8601 (format YYYY-MM-DD).
  • Page 8: Applicable Documents

    A6V10430515 A6V11467204 Operating terminals A6V10430526 A6V11467198 Call stations A6V10430544 A6V11467200 Power supply and batteries A6V10430553 A6V11467207 Accessories and options A6V10430563 A6V11467211 Environmental declaration Environmental declaration A6V11948779 A6V11948779 EU declaration of conformity (CE) For PCA2005-A1 A6V12101771 A6V12101771 8 | 34 A6V11571319_en--_b...
  • Page 9 Cerberus PACE/Novigo – environmental A6V11948779 A6V11948779 declaration Cerberus PACE Compact/Novigo Core – A6V12161830 A6V12161830 environmental declaration Download center Related documents such as environmental declarations, CE declarations, etc., can be downloaded at the following Internet address: http://siemens.com/bt/download A6V11571319_en--_b 9 | 34...
  • Page 10: Revision History

    About this document Revision history 1.2 Revision history The reference document's version applies to all languages into which the reference document is translated. The first edition of a language version or a country variant may, for example, be version 'd' instead of 'a' if the reference document is already this version. The table below shows this document's revision history: Version Edition date...
  • Page 11: Safety

    Safety Safety notes 2 Safety 2.1 Safety notes Comply with the following safety notes to protect life, limb, and property. The safety notes in the document include the following elements: ● Symbol for hazard ● Signal word ● Type and source of hazard ●...
  • Page 12: Safety Regulations For The Method Of Operation

    2.2 Safety regulations for the method of operation National standards, regulations and legislation Siemens products are developed and produced in compliance with the relevant European and international safety standards. Should additional national or local safety standards or legislation concerning the planning, mounting, installation,...
  • Page 13 Modifications to the system design and the products Modifications to the system and to individual products may lead to faults, malfunctioning and safety risks. Written confirmation must be obtained from Siemens and the corresponding safety bodies for modifications or additions. Modules and spare parts ●...
  • Page 14: Standards And Directives Complied With

    Personal injury or damage to property caused by poor maintenance or lack of maintenance 2.3 Standards and directives complied with A list of the standards and directives complied with is available from your Siemens contact. 2.4 Release notes Limitations to the configuration or use of devices in a voice alarm system with a particular firmware version are possible.
  • Page 15: Cyber Security Disclaimer

    Siemens’ portfolio undergoes continuous development to make it more secure. Siemens strongly recommends that updates are applied as soon as they are available and that the latest versions are used. Use of versions that are no longer supported, and failure to apply the latest updates may increase your exposure to cyber threats.
  • Page 16: Structure And Function

    3 Structure and function 3.1 Description The Loop isolator (100V) PCA2005-A1 is used in voice-alarm evacuation systems with a loop topology. The Loop isolator (100V) monitors the speaker line from its loudspeaker connection to the speaker for short-circuit and open lines. The matrix monitors the loop for short-circuit, open lines and ground fault.
  • Page 17: Planning

    Planning Loop audio matrices 4 Planning 4.1 Loop audio matrices The 'Loop isolator (100V)' can be connected to the following audio matrices: ● PC2003-A1, Cerberus PACE, Novigo, 'Digital audio matrix (4/4/16)' ● PC1001-A2, Novigo, 'Voice alarm panel Core 400' ● PC1002-A2, Novigo, 'Voice alarm panel Core 1000' ●...
  • Page 18: Fig. 3: Loop With Loudspeakers At Loop Isolators And Loudspeakers Between The Loop Isolators

    Planning Topologies Fig. 3: Loop with loudspeakers at loop isolators and loudspeakers between the loop isolators Loop without loudspeakers at loop isolators and with loudspeakers between the loop isolators It is also possible to use the loop isolators without loudspeakers at the Loop isolator (100V) itself.
  • Page 19: Notes

    ● Set up two separated loops in one room/building, connecting to one cabinet respectively 4.4 Details for ordering Type Designation Order number PCA2005-A1 Loop isolator (100V) Cerberus PACE: S54451-B53-A1 Novigo: OFB:NOVIGO_2160 PCA2013-A1 Spelsberg i 16-L Li Box Cerberus PACE: S54451-B54-A1...
  • Page 20: Product Data

    Views 5 Product data 5.1 Views Fig. 5: Equipment view, loop isolator (100 V) PCA2005-A1 Fastening tabs for relieving strain on loudspeaker lines Fastening tab for relieving strain on the LED connection cable Connection terminals for '+OUT-' loudspeaker line output...
  • Page 21: Pin Assignments

    Product data Pin assignments 5.2 Pin assignments 5.2.1 Pin assignment, line and loudspeakers Fig. 6: Pin assignments for loop and loudspeakers External loudspeakers Audio matrix supports loop isolators (see Loop audio matrices Loop [➙ 17]) audio matrix PCA2005 Loop isolator (100V) Connection terminals for '+OUT-' loudspeaker line output Connection terminals for '+SP-' loudspeaker Connection terminals for '+IN-' loudspeaker line input...
  • Page 22: Connection Diagram, External Led Indicator

    Product data Operation modes It is not permitted to cross over between different loop connections. Wiring must run from the 'Start' loop connection to the 'End' loop connection of the very same loop. 5.2.2 Connection diagram, external LED indicator An external LED can be mounted to display the status of the loop isolator. ●...
  • Page 23: Indicators

    Product data Indicators 5.4 Indicators The LED indicator on the printed circuit board shows the status of the Loop isolator (100V). An external LED has the same function. Behaviour Timing Pause Meaning information 1x flash 10 Hz Pilot tone-interval Normal Pilot tone was detected SIL-switch 6 [2] = ON Constant blinking...
  • Page 24: Technical Data

    Product data Technical data 5.5 Technical data Loop isolator (100V) PCA2005-A1 Supply Operating voltage AC 16…100 V Operating power 75 mW nominal 150 mW in startup Line separating function Pilot tone frequency ● Normal mode 20 kHz with configured On/Off-time ●...
  • Page 25 Product data Technical data PCA2005-A1 Technical data for loop, amplifier and loop audio matrix Maximum number of speaker loops: Per amplifier channel Loop audio matrix (see Loop audio matrices [➙ 17]) Loop audio matrix (configured as 'Priority only') (see Loop audio matrices [➙...
  • Page 26 Product data Technical data PCA2005-A1 Ambient conditions Operating temperature -10…+55 °C Storage temperature -20…+70 °C Operation in humid environments 10...90 % rel. (without moisture condensation) Storage in humid environments 5...90 % rel. (without moisture condensation) Dimensions and weights W x H x D mm...
  • Page 27: Mounting, Installation

    Mounting, installation Technical data 6 Mounting, installation The Loop isolator (100V) is used in a voice alarm and announcement system and is able to isolate short-circuits on loudspeaker lines. The PCA2013 Spelsberg i 16-L Li Box must be used to protect the Loop isolator (100V) from environmental influences and dangerous electrical voltages.
  • Page 28: Mounting In The Housing

    Mounting, installation Mounting in the housing 6.1 Mounting in the housing B – front view A – view from above C – housing mounting D – PCB view E – cable tie view Installation in the Spelsberg i 16-L Li Box PCA2013 housing 1.
  • Page 29: Wiring

    Mounting, installation Wiring 6.2 Wiring WARNING Voltages of up to AC 100 V at the component terminals Contact with live parts can lead to electric shock and may be fatal! ● De-energize all lines before performing any installation or maintenance work. ●...
  • Page 30 Mounting, installation Wiring NOTICE Incorrect polarity and contact stability Defective module or open line. Take note of the positive and negative terminals when connecting to the Loop isolator (100V). Only connect one wire to each terminal. 4. Use cable ties to secure the cables to the Loop isolator (100V). 5.
  • Page 31: Configuration

    Configuration Adjustment elements 7 Configuration The Loop isolator (100V) can only be configured in terms of hardware using the SIL switch. You will find more information on the system configuration in document A6V10429097 / A6V11474760. 7.1 Adjustment elements SIL switch SW1 is used to activate or deactivate various software functions. Changed switch settings are only updated after a reboot of the loop isolator.
  • Page 32: Commissioning And Maintenance

    Commissioning and maintenance Adjustment elements 8 Commissioning and maintenance WARNING Voltages of up to AC 100 V at the component terminals Contact with live parts can lead to electric shock and may be fatal! ● De-energize all lines before performing any installation or maintenance work. ●...
  • Page 33: Function Test

    Commissioning and maintenance Function test 8.1 Function test Loop isolator (100V) ● Carry out the function test at the specified intervals in accordance with the local requirements and standards. ● Perform the function test on site at the same time as the system acceptance test ●...
  • Page 34 Issued by Siemens Switzerland Ltd Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies © Siemens Switzerland Ltd, 2020 Technical specifications and availability subject to change without notice. A6V11571319_en--_b...
