Super heat recovery multi, indoor/outdoor unit, 1-way / 2-way / 4-way air discharge cassette type, floor standing cabinet type, for commercial use (220 pages)
CONTENTS PRECAUTION FOR SAFETY ................6 NEW REFRIGERANT (R410A) ............... 11 1. CONSTRUCTION VIEWS (EXTERNAL VIEWS) ........13 2. WIRING DIAGRAM ................... 14 3. PARTS RATING..................15 4. REFRIGERANTING CYCLE DIAGRAM ........... 16 5. CONTROL OUTLINE ................17 6. CONFIGURATION OF CONTROL CIRCUIT ..........23 7.
Page 3
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus Qualified installer thoroughly acquainted with the knowledge related to this work.
Page 4
Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
Page 5
Warning Indications on the Air Conditioner Unit [Confirmation of warning label on the main unit] Confirm that labels are indicated on the specified positions If removing the label during parts replace, stick it as the original. Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD...
Precautions for Safety The manufacturer shall not assume any liability for the damage caused by not observing the description of this manual. DANGER Before carrying out the installation, maintenance, repair or removal work, be sure to set the circuit breaker for both the indoor and outdoor units to the OFF position. Otherwise, electric shocks may result.
Page 7
WARNING Before starting to repair the air conditioner, read carefully through the Service Manual, and repair the air conditioner by following its instructions. Only qualified service person (∗1) is allowed to repair the air conditioner. Repair of the air conditioner by unqualified person may give rise to a fire, electric shocks, injury, water leaks and/or other problems.
Page 8
When any of the electrical parts are to be replaced, ensure that the replacement parts satisfy the specifications given in the Service Manual (or use the parts contained on the parts list in the Service Manual). Use of any parts which do not satisfy the required specifications may give rise to electric shocks, Use specified smoking and/ or a fire.
Page 9
When the refrigerant gas leaks during work, execute ventilation. If the refrigerant gas touches to a fire, poisonous gas generates. A case of leakage of the refrigerant and the closed room full with gas is dangerous because a shortage Ventilation of oxygen occurs.
Page 10
Only a qualified installer (∗1) or qualified service person (*1) is allowed to install the air conditioner. If the air conditioner is installed by an unqualified individual, a fire, electric shocks, injury, water leakage, noise and/or vibration may result. Before starting to install the air conditioner, read carefully through the Installation Manual, and follow its instructions to install the air conditioner.
• New Refrigerant (R410A) This air conditioner adopts a new HFC type refrigerant (R410A) which does not deplete the ozone layer. 1. Safety Caution Concerned to New Refrigerant The pressure of R410A is high 1.6 times of that of the former refrigerant (R22). Accompanied with change of refrigerant, the refrigerating oil has been also changed.
Page 12
4. Tools (1) Required Tools for R410A Mixing of different types of oil may cause a trouble such as generation of sludge, clogging of capillary, etc. Accordingly, the tools to be used are classified into the following three types. 1) Tools exclusive for R410A (Those which cannot be used for conventional refrigerant (R22)) 2) Tools exclusive for R410A, but can be also used for conventional refrigerant (R22) 3) Tools commonly used for R410A and for conventional refrigerant (R22) The table below shows the tools exclusive for R410A and their interchangeability.
3. PARTS RATING 3-1. Parts Rating Parts Name Type Specications Fan motor (for indoor) Output (Rated) 30W, DC340V ICF-340-30-6 4 phase, DC12V Louver motor 24BYJ48A-080 16.4"(418mm) Thermo. Sensor (TA sensor) 10kΩ at 25°C Ø4, 19.7"(500mm) Heat exchanger sensor (TC1 sensor) 10kΩ...
4. REFRIGERANTING CYCLE DIAGRAM Liquid side Gas side Strainer Capillary tube Air heat exchanger at indoor side Pulse Motor Valve (PMV) Distributor Sensor (TCJ) Sensor (TC2) Sensor (TC1) Sensor Fan motor (TA) Functional part name Functional outline Pulse Motor Valve (Connector CN82 (6P): Blue) 1) Controls super heat in cooling operation 2) Controls under cool in heating operation...
5. CONTROL OUTLINE 5-1. Indoor Unit Control Specifications Item Outline of specifications Remarks Power supply (1) Distinction of outdoor unit • Judgment of outdoor unit is reset. When the power supply is reset, the outdoor units are • Exchange of cooling-only distinguished, and control is exchanged according to the unit distinctive results.
Page 18
Item Outline of specifications Remarks (1) In heating operation, the upper limit of the fan tap is set by Prevention of one with higher temperature of TC2 sensor and TCJ cold air sensor. discharge • In D and E zones, priority •...
Page 19
Item Outline of specifications Remarks Cooling oil While the outdoor unit is recovering cooling oil (refrigerant), the • Recovery operation (refrigerant) indoor units perform the following control tasks: normally takes place recovery control [common for operational (cooling thermo ON/thermo OFF/FAN), roughly every 2 hours.
Page 20
Item Outline of specifications Remarks Filter sign display (1) The operation time of the indoor fan is integrated and (None in wireless type) stored in memory, and the filter exchange signal is sent to the remote controller to display on the remote ∗...
Page 21
Item Outline of specifications Remarks Hi POWER When you press the Hi POWER button during cooling, operation heating or A operation, the air conditioner will start the (Wireless remote following operation. control specific • Cooling operation operations) Performs the cooling operation at 2.0F°(1°C) lower than the setting temperature.
Page 22
Item Outline of specifications Remarks PRESET operation To operate the air conditioner with the setting memorized. (Wireless remote control specific (1) Press the PRESET button. The setting memorized operation) will be indicated and the air conditioner operates with regards to the setting. •...
6. CONFIGURATION OF CONTROL CIRCUIT 6-1. Indoor Controller block diagram (MCC-1696) 6-1-1. Connection of wired remote controller Wired header remote controller (Up to 2 link) Schedule timer (weekly timer mode) Display Display LCD Function setup LCD driver Key switch Display LED Function setup Key switch DC5V...
Page 24
6-1-2. Connection of Wireless Remote Controller Central control remote controller (Sold separately) Follower unit Indoor unit #1 Header unit Indoor control P.C. board (MCC-1696) Central control communication circuit DC20V Remote controller communication circuit DC12V EEPROM Receiver and Display P.C. board DC5V TA sensor (WP-033)
Page 26
Wall-Type P.C. Board Optional Switch/Connector Specifications Connector Function Specifications Remarks OFF: No terminator resistor, Setup at shipment OFF: No terminator resistor. Terminator resistor Bit 1 ON: Terminator resistor provided Only 1 unit is ON during central control by custom only. provided/Not provided SW01 OFF: Remote controller A...
Page 27
6-3. Functions at test run Cooling/Heating test run check The test run for cooling/heating can be performed from either indoor remote controller or outdoor interface P.C. board. 1. Start/Finish operation of test run Test run from indoor remote controller Wired remote controller: Refer to the below item of “Test run” of the wired remote controller. Wireless remote controller: Refer to the next page item of “Test run”...
Page 28
In case of wireless remote controller REQUIREMENT 1. For the operation procedure, be sure to follow the matter. 2. Finish the forced cooling operation in a short time because it applies excessive strength to the air condi- tioner. 3. A test operation of forced heating is unavailable. Perform a test operation by heating operation using the switches of the remote controller.
Page 29
Check function for operation of indoor unit (Functions at indoor unit side) This function is provided to check the operation of the indoor unit singly without communication with the remote controller or the outdoor unit. This function can be used regardless of operation or stop of the system. However, if using this function for a long time, a trouble of the equipment may be caused.
7. APPLIED CONTROL 7-1. Setup of Selecting Function in Indoor Unit (Be Sure to Execute Setup by a Wired Remote Controller) <Procedure> Execute the setup operation while the unit stops. TEMP. ON / OFF TIMER SET MODE TIME SAVE VENT FILTER RESET TEST...
Page 31
Table: Function selecting item numbers (DN) (Items necessary to perform the applied control at the local site are described.) CODE No. Item Description At shipment [DN] Filter display delay timer 0000 : None 0002 : 2500H 0001 : 150H 0002 : 2500H 0003 : 5000H 0004 : 10000H Dirty state of filter...
Page 32
CODE No. Item Description At shipment [DN] Timer setup 0000 : Available (Operable) 0000 : Available (Wired remote controller) 0001 : Unavailable (Operation prohibited) Change unit +0.9°F(0.5°C) or 0000 : +0.9°F(0.5°C) 0001 : 1.8°F(1.0°C) 0000 : +0.9°F(0.5°C) +1.8°F(1.0°C) on remote Region 0000 : Japan model 0001 : North America...
Page 33
7-2. Applied Control in Indoor Unit Remote location ON/OFF control box (TCB-IFCB-4UL) [Wiring and setup] • Use the exclusive connector for connection with the indoor control P.C. board. • In a group control, the system can operate when connecting with any indoor unit (Control P.C. board) in the group.
Page 34
Ventilating fan control from wired remote controller [Function] • The start/stop operation can be operated from the wired remote controller when air to air heat exchanger or ventilating fan is installed in the system. • The fan can be operated even if the indoor unit is not operating. •...
Page 35
Leaving-ON prevention control (with Wired remote controller) [Function] • This function controls the indoor units individually. It is connected with cable to the control P.C. board of the indoor unit. • In a group control, it is connected with cable to the indoor unit (Control P.C. board), and the CODE No. is set to the connected indoor unit.
Page 36
Address setup (Manual setting from Wired remote controller) In case that addresses of the indoor units will be determined prior to piping work after wiring work (Example of 2-lines cabling) (Real line: Cabling, Broken line: Refrigerant pipe) • Set an indoor unit per a remote controller. •...
Page 37
Confirmation of indoor unit No. position 1. To know the indoor unit addresses though position of the indoor unit is recognized • In case of individual operation (Wired remote controller : indoor unit = 1 : 1) (Follow to the procedure during operation) <Procedure>...
Page 38
Function selection setup <Procedure> Perform setting while the air conditioner stops. Push buttons simultaneously for 4 seconds or more. TEST The first displayed unit No. is the header indoor unit address in the group control. In this time, fan and louver of the selected indoor unit operate. UNIT LOUVER Every pushing button (button at left side), the indoor unit No.
Page 39
How to check all the unit No. from an arbitrary wired remote controller <Procedure> Carry out this procedure during stop of system. The indoor unit No. and the position in the identical refrigerant piping can be checked. An outdoor unit is selected, the identical refrigerant piping and the indoor unit No. are displayed one after the other, and then its fan and louver are on.
Page 40
How to change all indoor addresses from an arbitrary wired remote controller (It is possible when setting has finished by automatic addresses.) Contents: The indoor unit addresses in each identical refrigerant piping line can be changed from an arbitrary wired remote controller. Enter in address check/change mode and then change the address.
Page 41
Function to clear error 1. Clearing method from remote controller How to clear error of outdoor unit In the unit of refrigerant line connected by indoor unit of the remote controller to be operated, the error of the outdoor unit currently detected is cleared. (Error of the indoor unit is not cleared.) The service monitor function of the remote controller is utilized.
Page 42
Monitoring function of remote controller switch When using the remote controller (Model Name: RBC-AMT32UL), the following monitoring function can be utilized. Calling of display <Contents> The temperature of each sensor of the remote controller, indoor unit and outdoor unit and the operating status can be checked by calling the service monitor mode from the remote controller.
Page 43
< Based on the SMMS-e > CODE No. Data name Display format Unit Remote control display example Room temperature (Use to control) ×1 °C [0027] = 27 °C Room temperature (Remote control) ×1 °C Indoor suction air temperature (TA) ×1 °F Indoor coil temperature (TCJ) ×1...
8. TROUBLESHOOTING 8-1. Troubleshooting Summary 1. Before troubleshooting 1) Applied models S-MMS Multi type models Indoor unit : MMX-APXXX, Outdoor unit : MMY-MAPXXXXT8X, MMY-MAPXXXHT7X Super Heat Recovery Multi type models Indoor unit : MMX-APXXX, Outdoor unit : MMY-MAPXXXFT8X Mini-S-MMS Multi type models Indoor unit : MMX-APXXX, Outdoor unit : MCY-MAPXXXHT, MCY-MAPXXXHT2X...
Page 51
8-3. Troubleshooting by Check Display on Wired Remote Controller In case of wired remote controller (RBC-AMT32UL) 1. Confirmation and check When an error occurred on the air conditioner, the check code and the indoor unit No. are displayed on the display section of the remote controller.
Page 52
In case of central remote controller (TCB-SC642TLE2) ZONE ZONE GROUP CODE 1234 TEST UNIT No. SET DATA SETTING R.C. GROUP SELECT ZONE 1. Confirmation and check When a trouble occurred on the air conditioner, the check code and the indoor unit No. are displayed on the display section of the remote controller.
Page 53
Indoor unit display part (Receiving unit) (Wireless type) When specifying the check code, check 7-segment display on the center unit. For the check code which is not displayed on the outdoor 7-segment, confirm it in Section “8-2 How to Check / Check code display list (Indoor unit)”. : Goes off, : Goes on, : Flash (0.5 second)
Installation Manual SMMS High-Wall Type 9. INSTALLATION MANUAL Please read this Installation Manual carefully before installing the Air Conditioner. • This Manual describes the installation method of the indoor unit. • For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit. ADOPTION OF NEW REFRIGERANT This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional refrigerant R22 in order to prevent destruction of the ozone layer.
Page 69
The qualified service person is a person who installs, repairs, maintains, relocates and removes the air conditioners made by Toshiba Carrier Corporation. He or she has been trained to install, repair, maintain, relocate and remove the air conditioners made by Toshiba Carrier Corporation...
Page 70
Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below. Failure to wear the proper protective gear is dangerous because you will be more susceptible to injury, burns, electric shocks and other injuries.
Page 71
Warning indications on the air conditioner unit Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote electric power supplies Disconnect all remote electric power supplies before servicing. before servicing. WARNING WARNING Moving parts. Moving parts. Do not operate unit with grille Do not operate unit with grille removed.
PRECAUTIONS FOR SAFETY • Ensure that all Local, National and International regulations are satisfied. • Read this “PRECAUTIONS FOR SAFETY” carefully before Installation. • The precautions described below include the important items regarding safety. Observe them without fail. • After the installation work, perform a trial operation (test run) to check for any problem.
Page 73
• Do not climb onto or place objects on top of the outdoor unit. You may fall or the objects may fall off of the outdoor unit and result in injury. • When work is performed at heights, use a ladder which complies with the ISO 14122 standard, and follow the procedure in the ladder’s instructions.
Page 74
topple over or give rise to noise, vibration, water leakage or other trouble. • Carry out the specied installation work to guard against the possibility of high winds and earthquake. If the air conditioner is not installed appropriately, a unit may topple over or fall down, causing an accident. •...
Page 75
• Install a circuit breaker that meets the specifications in the installation manual and the stipulations in the local regulations and laws. • Install the circuit breaker where it can be easily accessed by the agent. • When installing the circuit breaker outdoors, install one which is designed to be used outdoors.
Page 76
Relocation • Only a qualified installer(*1) or qualified service person(*1) is allowed to relocate the air conditioner. It is dangerous for the air conditioner to be relocated by an unqualified individual since a fire, electric shocks, injury, water leakage, noise and/or vibration may result. •...
ACCESSORY PARTS Part name Q’ty Shape Usage Installation Manual This manual (Hand over to customers) (Hand over to customers) Owner’s Manual Installation plate Wireless remote controller Battery Remote controller holder Mounting screw Ø0.16“ (4 mm) × 1.0” (25 mm) Flat head wood screw Ø1/8“...
SELECTION OF INSTALLATION PLACE WARNING • Install the air conditioner at enough strong place to withstand the weight of the unit. If the strength is not enough, the unit may fall down resulting in injury. CAUTION • Do not install the air conditioner in a location subject to a risk of exposure to a combustible gas.
Page 79
Installation diagram of Indoor and outdoor units For the rear left and left piping Before installing the wireless remote controller Hook Wall 1. Remove the battery cover. Installation 2. Insert 2 new batteries plate (R03 [AAA] type) following the (+) and (−) Insert the cushion between the positions.
Wireless remote controller • A place where there are no obstacles such as a curtain that may block the signal from the indoor unit. • Do not install the remote controller in a place exposed to direct sunlight or close to a heating source, such as a stove.
Page 81
Changing MOUNT-COUNT ● Step to remove the MOUNT-CONDUIT 1) The MOUNT-CONDUIT can be removed by removing the screw securing the MOUNT-CONDUIT and them pulling out the MOUNT-CONDUIT. Remove the screw 1 part. 2) Remove the MOUNT-CONDUIT by direction backside of unit. 3) Remove the EDGE-SADDLE take off from MOUNT-CONDUIT.
CUTTING A HOLE AND MOUNTING INSTALLATION PLATE Cutting a hole When the installation plate is directly mounted on the wall In case of installing the refrigerant pipes from the rear: 1. Securely fit the installation plate onto the 1. Decide the hole position for piping at wall by screwing it in the upper and lower 7.1"...
PIPING AND DRAIN HOSE INSTALLATION Piping and drain hose forming * Since dewing results in a machine trouble, make sure to insulate both connecting pipes. (Use polyethylene foam as insulating material.) Rear right Rear left Bottom left Left Bottom right Right 1.
Page 84
How to remove the drains cap Clip the drain cap by needle-nose pliers and pull out. How to fix the drains cap 1) Insert hexagonal wrench (dia. 0.6" (4 mm)) in a centre head. 2) Firmly insert drains cap. Do not apply lubricating oil (refrigerant machine oil) when inserting the drain cap.
Page 85
In case of bottom right or bottom left piping • After scribing slits of the front panel with a knife or a marking-off pin, cut them with a pair of nippers or an equivalent tool. Slit Left-hand connection with piping Bend the connecting pipe so that it is laid within 1.7"...
INDOOR UNIT FIXING DRAINAGE 1. Run the drain hose sloped downwards. 1. Pass the pipe through the hole in the wall, and hook the indoor unit on the installation NOTE plate at the upper hooks. • Hole should be made at a slight downward 2.
REFRIGERANT PIPING Permissible Piping Length and Refrigerant Piping Height Difference 1. Use copper pipe with 0.03" (0.8 mm) or more thickness. (In case pipe size is dia. They vary according to the outdoor unit. 5/8" (15.9 mm),with 0.04" (1.0 mm) or more.) For details, refer to the Installation Manual attached 2.
Page 88
Tightening connection Heat insulation Heat insulation for the pipes should be done CAUTION separately for the liquid side and gas side. Because both of the liquid and gas side pipes • Do not apply excessive torque. Otherwise, the become a low temperature during cooling nut may crack depending on the conditions.
ELECTRICAL CONNECTION WARNING Power supply wire and control wires specifications 1. Use predefined wire and connect them Power supply wire and control wires are locally certainly. Keep the connecting terminal procured. freefrom external force. For the power supply specifications, follow to the Improper wire connection or clamping may table below.
Page 90
Up to 164'1" (50 m) Ground 1 × AWG12 or thicker Electric characteristics Voltage Range (V) MOCP Model Power Supply MMK-AP0157HPUL 0.38 MMK-AP0187HPUL 208/230V-1-60Hz 0.41 MMK-AP0247HPUL 0.60 Control wire Control wiring between indoor units, and outdoor unit (Up to 3280'10ʺ (1000 m)) AWG16...
Page 91
NOTE An outdoor unit connected with control wiring between indoor and outdoor units wire becomes automatically the header unit. Wiring example Outdoor Power supply Outdoor Power supply Circuit breaker Circuit breaker Header outdoor unit Follower outdoor unit Ground Ground U1 U2 U3 U4 U5 U6 L1 L2 L3 N L1 L2 L3 N U1 U2 U3 U4 U5 U6...
Page 92
Wiring Connection Power supply terminal block How to connect the power supply wiring Terminal block for communication/remote and control wiring controller wiring The power supply wire and the control wire can be Screw connected without removing the front panel. REQUIREMENT Terminal cover Earth screw Connect the power supply wire after connecting...
Page 93
Wiring connection for flow selector unit How to connect the wiring of flow selector unit Connect the power supply wire and the communication wire supplied with the flow selector unit to the indoor unit. 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you.
APPLICABLE CONTROLS A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Changing of settings of for REQUIREMENT applicable controls • When you use this air conditioner for the first time, it takes approx. 5 minutes until the remote Basic procedure for changing settings controller becomes available after power-on.
Page 95
Change of lighting time of filter Procedure sign Each time you push button, indoor unit numbers in the control group change cyclically. According to the installation condition, the lighting Select the indoor unit you want to change settings time of the filter sign (Notification of filter cleaning) for.
Page 96
Adjustment of air direction 1. Using the remote controller switch, change the up/down air direction by moving the horizontal louver. 2. Adjust the right/left air direction by bending the vertical grille inside of the air outlet port with hands. REQUIREMENT Do not touch the horizontal louver directly with hands;...
TEST RUN A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Before test run In case of wired remote controller • Before turning on the power supply, carry out the following procedure.
Page 98
In case of wireless remote controller (Forced test operation is performed in a different way.) REQUIREMENT • For the operation procedure, be sure to follow the Owner’s Manual. • Finish the forced cooling operation in a short time because it applies excessive strength to the air conditioner.
TROUBLESHOOTING A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Confirmation and check Procedure Every pushing of “TEMP.” button used to When a trouble occurred in the air conditioner, the set temperature, the trouble history stored in check code and the indoor UNIT No.
Page 100
Check method On the remote controller (Wired remote controller, Central control remote controller) and the interface P.C. board of the outdoor unit (I/F), a check display LCD (Remote controller) or 7-segment display (on the outdoor interface P.C. board) to display the operation is provided. Therefore the operation status can be known.
Page 101
Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display 01: Outdoor unit of other line connected Other line connected during automatic 02: Indoor unit of other line address connected...
Page 103
Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display #0: Element short circuit #E: Vdc voltage trouble #1: Position detection circuit trouble #2: Input current sensor trouble #3: Motor lock trouble #C: Sensor temperature trouble...
Page 104
WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit NOTE 2 The standards for minimum room volume are as The room in which the air conditioner is to be follows. installed requires a design that in the event of (1) No partition (shaded portion) refrigerant gas leaking out, its concentration will not exceed a set limit.
Page 105
CONFIRMATION OF INDOOR UNIT SETUP Prior to delivery to the customer, check the address and setup of the indoor unit, which has been installed in this time and fill the check sheet (Table below). Data of four units can be entered in this check sheet. Copy this sheet according to the No.
10. HOW TO REPLACE THE MAIN PARTS WARNING • Since high voltages pass through the electrical parts, turn off the power without fail before proceeding with the repairs. Electric shocks may occur if the power plug is not disconnected. • After the repairs have been completed (after the front panel and cabinet have been installed), perform a test run, and check for smoking, unusual sounds and other abnormalities.
Page 107
Part name Procedures Remarks Air filters 1) Follow to the procedure in the item 1 . Air filters 2) Remove the left and the right air filters from the front panel. Front panel 1) Stop operation of the air conditioner and turn Front panel off its main power supply.
Page 108
Procedures Part name Remarks Electric part 1) Follow the procedure item 3 . box assembly 2) Remove screw holding the electric part cover. 3) Take off the clamp base mounting screw and then remove the clamp base assembly. 4) Take off fixing screws (2 pcs) of PMV cover, and then remove PMV cover.
Page 109
Part name Procedures Remarks Fan motor 1) Follow the procedure item 3 and 4 . Cross flow fan 2) Loosen the set screw of the cross flow fan. Cross flow fan Body back 3.5 mm Fan motor Set screw Vertical louver Hexagon screw driver 3) Remove 2 fixing screws of the motor band.
Page 110
Part name Procedures Remarks Drain pan 1) Follow the procedure item assembly 2) Remove screw holding the electric part cover. 3) Disconnect the louver motor connector (5P) from P.C. board assembly. 4) Disconnect the cord motor of Louver VT (5P) from the Louver VT (L/R) connector.
Page 111
Part name Procedures Remarks Vertical louver 1) Follow the procedure item 3 and 8 . Vertical louver assembly 2) Remove 2 fixing screws from the base Screw vertical louver then remove the vertical louver assembly from the body back. Screw Cover motor VT 1) Follow the procedure item 3 , 8 and 9 .
Page 112
Part name Procedures Remarks Cross flow fan Body back 3.5 mm Set screw Fan motor - Holding the set screw, install the cross flow fan so that flat area on shaft of the fan motor comes to the mounting hole of the set screw.
11. Replacement of P.C. Board for Indoor Unit Servicing <Models> MMK-AP****HPUL Series <Note : when replacing the P.C. board for indoor unit servicing> The nonvolatile memory (hereafter called EEPROM, IC503) on the indoor unit P.C. board before replacement includes the model specific type information and capacity codes as the factory-set value and the important setting data which have been automatically or manually set when the indoor unit is installed, such as system/indoor/group addresses, high ceiling select setting, etc.
Page 114
TEST Step 3 After writing down all setting data, press button to return to the normal stop status. (It takes approx. 1 min until the remote control operation is available again.) CODE No.required at least The CODE No. for the Indoor unit type and Indoor unit capacity Contents are required to set the rotation number setting of the fan.
Page 115
UNIT LOUVER Step 2 button is pressed, the indoor unit Nos. in the group control operation are displayed in Every time when the order. (The settings stored in the EEPROM of the P.C. board for indoor unit servicing are the factory-set values.) Specify the indoor unit No.with its P.C.
Page 116
Table 1.Setting data(CODE No. table(example)) Factory-set value Item Setting data Filter display delay timer 0002 : 2500H Dirty state of filter 0000 : Standard Central control address 00Un/0099 : Unfixed Specific indoor unit priority 0000 : No priority Heating suction temperature shift Automatic mode 0001 : No automatic Cooling only...
12. EXPLODED VIEWS AND PARTS LIST Indoor Unit (For TCJ, TC2) (For TC1) ASM-ACCE Location Part Location Part Description Description 43T00822 FRONT PANEL ASSY 43T49045 PIPE, SHIELD 43T00752 CAP SCREW ASSEMBLY 43T49043 HOLDER, PIPE 43T09591 GRILLE OF AIR INLET ASSY 43T82008 PLATE, INSTALLATION 43T80351...
Page 118
Indoor Unit (Part-E) MCC-1696 SW02 CN60 CN213 CN61 SW01 CN50 CN32 CN81 Location Part Location Part Description Description 43T6W850 PC BOARD ASSY 43T60548 ASM-HOUSING(PW) 43T60448 TERMINAL 43T60546 ASM-HOSING(BUS) 43T60435 SERV-TERMINAL 43T60545 ASM-HOUSING(REM) 43T50392 SENSOR,THERMOSTAT 43T60539 ASM-HOUSING(MOV) 43T50410 TC-SENSOR 43T6V932 PC BOARD ASSY 43T50414 TC-SENSOR 43T63356...
Page 119
WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit Important The room in which the air conditioner is to be installed requires a design that in the event of refrigerant gas NOTE 2 : leaking out, its concentration will not exceed a set limit. The standards for minimum room volume are as follows.
