- Page 1 Digital I/O Module DIOM01.1 / DIOM0a.1 Firmware Version: V1.0.0 (Loader) V1.0.0 (Loader) V1.0.0 (System) V1.0.0 (System) TRANSLATION OF THE ORIGINAL GERMAN MANUAL 10/2015 Manual MA 1271-A003 EN...
- Page 2 We appreciate suggestions and criticisms for further improvement. Email address: doku@phytron.de Questions about the use of the product described in the manual that you cannot find answered here, please contact your representative of phytron (http://www.phytron.eu/) in your local agencies. MA 1271-A003 EN...
-
Page 3: Legal Instructions
1 Legal Instructions This manual: Read this manual very carefully before mounting, installing and operating the device and if necessary further manuals related to this product. Please pay special attention to instructions that are marked as follows: DANGER –... - Page 4 Manual DIOM01 / DIOM0a Observe the following safety instructions! Qualified personnel WARNING – Serious injury possible! Serious personal injury or serious damage to the machine and drives could be caused by insufficiently trained personnel! Without proper training and qualifications damage to devices and injury might result! - Design, installation and operation of systems may only be performed by qualified and trained personnel.
- Page 5 Safety Instructions Further Manual This manual is in addition to the following main manual: “phyMOTION Modular Multi-axis Controller for Stepper Motors” - First, read the main manual and then continue with this manual. Intended use: The phyMOTION is designed for operating in a drive system.
-
Page 6: Table Of Contents
Manual DIOM01 / DIOM0a 2 Contents 1 Legal Instructions ....................3 2 Contents ........................6 3 DIOM01/DIOM0a Module Overview ................. 7 4 Technical Data ......................8 4.1 Declaration of Conformity ..................8 4.2 Mechanical Data ....................9 4.3 Features ......................10 4.4 Functional Description .................. -
Page 7: Diom01/Diom0A Module Overview
3 DIOM01/DIOM0a Module Overview DIOM stands for “Digital Input Output Module“ and is set for the application of the modular stepper motor control unit phyMOTION . The DIOM01/DIOM0a module is activated by the main controller module (MCM01) and has 8 digital, electrically isolated inputs and outputs. -
Page 8: Technical Data
Manual DIOM01 4 Technical Data 4.1 Declaration of Conformity MA 1271-A003 EN... -
Page 9: Mechanical Data
4.2 Mechanical Data Dimension 100 x 100 mm without front panel Weight 56 g without and 79 g with front panel Mounting Plug-in module into the modular stepper motor controller phyMOTION Mounting position Vertical MA 1271-A003 EN... -
Page 10: Features
Manual DIOM01 4.3 Features Features Main controller Modular controller phyMOTION Power supply - 24 V internal via central entry point from the POWM01 or POWM02 module - Or 24V external directly to the DIOM01/DIOM0a module - 5 V internal Current consumption - 2 A for the complete DIOM01/DIOM0a module if it is supplied via the central entry point for the POWM01 or (max.) - Page 11 DIOM01/DIOM0a module. The external power supply must always be higher than the internal power supply. Rear bus connection Proprietary phytron bus Communication and Programming Programming Via phytron’s programming environment phyLOGIC ToolBox Communication Master slave communication from the MCM01 to the DIOM01/DIOM0a MA 1271-A003 EN...
-
Page 12: Functional Description
Manual DIOM01 4.4 Functional Description Digital inputs and outputs: • 8 digital inputs 24 V • 8 digital outputs 24 – 30 V , at 1 A max., 2 A max. per module. Up to 4 A per module is possible with a direct power supply. •... -
Page 13: Installation
5 Installation 5.1 Mechanical Installation of the DIOM01/DIOM0a Modules phytron always delivers the phyMOTION completely assembled in order to make sure you can start with the installation and the wiring right way. Further Manual Detailed information on this subject is in a supporting manual: “phyMOTION... - Page 14 Manual DIOM01 WARNING – Serious injury from electric shock! During electrical installation cables, connectors, etc. can be live. Before starting wiring, make sure that none of the power supplies are connected to the primary side of the mains supply. Isolate the power supplies from the mains or remove the appropriate fuses.
-
Page 15: Electrical Installation
5.2 Electrical Installation Ensure sufficient bending radius of the cables during installation. Do not lay the cables in tension or bend them. We recommend labelling the mating connectors to prevent interchanging the connectors. If all the connections are made, the last step is to plug in the power supply to the mains. -
Page 16: Pin Assignment
Manual DIOM01 5.2.2 Pin Assignment Here is the pin assignment of the DIOM01/DIOM0a Fig. 2: Pin assignment For wiring please use the above defined mating connectors. MA 1271-A003 EN... -
Page 17: Input Wiring
5.2.3 Input Wiring Switching threshold DIOM01 DIOM0a 2,4 V 11 V Fig. 3: Input wiring 5.2.4 Output Wiring Fig. 4: Output wiring CAUTION – Possible damage! Damage of the module because of incorrect connection. - Do not swap the 8 pin connector for the 8 inputs with the 8 pin connector for the outputs. -
Page 18: Commissioning
Manual DIOM01 6 Commissioning Please read the manual for basic commissioning information of the DIOM01/DIOM0a module : Further manual Detailed information on this subject is in a supporting manual: “phyMOTION Modular Multi-axis Controller for Stepper Motors” The programming environment phyLOGIC ToolBox is explained in the following manual: Further manual Detailed information on this subject is in a supporting manual::... -
Page 19: Diagnostics By The Leds
6.1 Diagnostics by the LEDs The LEDs indicate the status and error of the DIOM01/DIOM0a module by colours and blinking: Fig. 5: Status-LEDs Status LEDs I/O LEDs top left top right No power supply connected I/Os not active Output... -
Page 20: Parameterising Of The Modules
Manual DIOM01 6.2 Parameterising of the Modules No parameterisation for the DIOM01/DIOM0a module is necessary. MA 1271-A003 EN... -
Page 21: Service
- If you want to use the phyMOTION™ after removing a module, the gap has to be sealed with a blanking plate before power supply is reconnected and switched on. - To send a module to phytron use ESD packaging only. MA 1271-A003 EN... -
Page 22: Warranty, Disclaimer And Registered Trademarks
8 Warranty, Disclaimer and registered trademarks Disclaimer phytron GmbH has verified the contents of the manual to match with the hardware and software. However, errors and omissions are exempt and phytron GmbH assumes no responsibility for complete compliance. The information contained in this publication is reviewed regularly and any necessary corrections are included in subsequent editions. -
Page 23: Index
9 Index MCM01 7, 14 Bus 12 Output wiring 18 Commissioning 19 Communication 12 Pin assignment 17 Controller 11 Power consumption 11 Copyright 2 Power supply 11 Counter module 8, 13 Progamming environment 12 Current consumption 11 Programming 19...
