Introduction
6
Modal SKULPTsynth SE is a portable 4-voice 32 oscillator virtual analogue synthesiser.
It features morphable waveforms, state variable filter, a comprehensive modulation matrix, 8
modulation sources, including two audio rate LFOs, a fully featured arpeggiator and a realtime
sequencer.

SPECIFICATION:

• 4 voice – 32 oscillator virtual analogue synthesiser
• 8 oscillators per voice with 2 selectable morphable waveforms
• Mixer stage for osc levels along with FM, PWM, tuning and Ring Modulation options
• Monophonic, Duophonic and Polyphonic modes available
• Multi option Unison / spread to detune the 32 oscillators for a huge sound
• 8 slot modulation matrix with 8 sources and 37 destinations
• 3 x envelope generators for Filter, Amplitude and Modulation
• 2 x audio rate LFOs, one global and one polyphonic
• Realtime sequencer that will record up to 256 notes and up to 4 parameters of animation
• Fully featured arpeggiator with division, direction, octave, bipolar swing and sustain
controls
• Resonant filter that can be morphed from low pass, through band pass, to high pass
• Delay and distortion (waveshaping overdrive, not bitcrushing) effects
• Optional MIDI clock sync for LFOs and Delay
• 128 patch and 64 sequence storage locations
• 16 key touch MIDI keyboard
• Supports MPE-compatible MIDI controllers, allowing you to apply polyphonic control and
expression to individual notes.
• MIDI DIN In and Out – Analogue clock sync In and Out connections
• Class compliant MIDI provided over USB connection to host computer or tablet
• Headphone and line output
• Power by USB or 6 x AA batteries
• Optional software editor available for MacOS, Windows, IOS and Android
• Portable and compact design
• Dimensions: 255mm x 135m x 68mm (10"x5 1/2"x 3")
