MIDI
Arp / Seq Out
Enables / disables MIDI note output from the arpeggiator and sequencer. If this setting is
enabled and the arpeggiator is active then the internal keyboard notes will not be transmitted
to MIDI-out. Please note that MIDI-in notes that are being arpeggiated will also be transmitted
to MIDI-out if this setting is enabled, which may cause MIDI loop / echo issues in complex
MIDI setups.
This can be set from the panel by holding the ARP button whilst powering on the device and
using touch pads 1-8 to turn off this setting or touch pads 9-16 to turn on this setting.
Polychaining
Polychaing is available for up to 4 SKULPTsynth SE or SKULPTsynthesiser units together for up
to 16 voices of polyphony:
• Connect desired master din out to first drone din in.
• Connect additional drones (Maximum 3 drones per master, 4 in total) in the same way,
din out -> din in.
• Power on drone SKULPTsynth SE or SKULPTsynthesiser.
• Power on master SKULPTsynth SE or SKULPTsynthesiser holding down the VOICE button
and select the number of drones on the Touch Pads.
• Release VOICE button. An LED animation should run accross all SKULPT units and will
disable the drone's front panel. The VOICE LEDs will be lit and the drone number flashing
on the touch pads.
36
MIDI CC Implemention Chart
Function CC
Seq Load 0
Modulation Wheel 1
Glide 5
Headphone Volume 7
Voice Mode 9 0 - 42 = Mono; 43 - 85 = Duo; 86 - 127 = Poly;
Expression Pedal 11
Distortion 12
Delay 13
No Sync: 0 - 250 milliseconds / Sync: 8 steps, Longest delay time
Delay Time 14
Delay Feedback 15
Osc1 Wave 16 0 - 21 Sine / 22-42 Tri / 43-63 Saw / 64-127 PWM duty 50% - 5%
0 - 21 Sine / 22-42 Tri / 43-63 Saw / 64-85 Square / 86-127 White
Osc2 Wave 17
Osc Mix 18
FM Amount 19
0 - 63 Unison / 64 - 70 Major / 71 - 77 Minor / 78 - 84 Major 6th /
Spread 20 85 - 91 Sus 4th / 92 - 98 5ths / 99 - 105 5th + Oct / 106 - 112 Oct
+ 1 + 2/ 113 - 119 Oct + 1 -1 / 119 - 127 Oct -1 -2
Chord Mode 21
FEG Attack 22
FEG Decay 23
FEG Sustain 24
FEG Release 25
AEG Attack 26
AEG Decay 27
AEG Sustain 28
AEG Release 29
Osc2 Course
30
Detune
Values
0 - 63
"
0 - 2.5 seconds, exponential
Silence - full volume
"
Dry - Wet
Dry - Wet
possible divided down
0% - 90%
Noise
Osc1 - Osc2
0 - Full
0 - 63 = OFF / 64 - 127 = ON
0 - 4 Seconds
0 - 4 Seconds
0 - 1
0 - 4 Seconds
0 - 4 Seconds
0 - 4 Seconds
0 - 1
0 - 4 Seconds
+/- 4 Octaves
