Modal SKULPTsynth SE User Manual page 14

Modulation
Parameter LFO1 LFO2 MOD-EG
Cutoff X
Reso
Morph
FEG Amount X
FEG Attack X
FEG Decay X
FEG Sustain X
FEG Release X
AEG Amount X
AEG Attack X
AEG Decay X
AEG Sustain X
AEG Release X
MEG Amount X
MEG Attack X
MEG Decay X
MEG Sustain X
MEG Release X
Distortion
Delay X X
Time X X
Feedback X X
Spread
Glide X
Scaling
LFO1 and LFO2 are scaled such that if they are assigned with maximum depth and the
modulated parameter is at its centre value, the full parameter range will be modulated.
All other modulation sources are scaled such that if they are assigned with maximum positive
depth and the modulated parameter is at 0, the full parameter range will be modulated.
26
NOTE VELO AFTT MODW CC
X X
X X
X X
Modulation
On SKULPTsynth SE each modulation source has its own dedicated assign button on the
front panel. Assign buttons can be latched so you don't have to hold them while assigning
modulation destinations or accessing shift functions! Slots can also be easily muted or cleared
by enetering the MOD SLOTS mode.
• MEG: Similar to the Assign button, this button allows us to assign which parameters the
Mod-EG affects in the matrix. After pressing simply begin twist the knob that you would
like the Mod-EG to modulate you will see touch pads 8 and 9 illuminated showing their
is no modulation as you continue to twist the LEDs will illuminate to show you depth.
Modulation is bipolar so twisting left achieves negative amounts and twisting right
achieves positive amounts.
• Note: This button allows you to assign a bipolar amount of keytracking modulation to
a selected destination: at positive values, the higher the note you press, the higher the
modulation value.
• Velo: This button allows you to assign a bipolar amount of velocity modulation to a
selected destination: at positive values, the harder / faster the note you press, the higher
the modulation value on the selected destination.
• Modw: When holding the SHIFT key this button allows you to assign a bipolar amount of
mod wheel modulation to a selected destination
Tip: Assign an LFO to control Tune. Reduce the depth of the LFO and assign the Modw to
the depth (+or-) adjust rate to taste for that classic mod wheel vibrato!
• Aftt: When holding the SHIFT key this button allows you to assign a bipolar amount of
monophonic aftertouch modulation to a selected destination.
• Ext: When holding the SHIFT key this button allows you to assign a bipolar amount of
External Expression (MIDI CC 11) to a selected destination
• Mod Slots: When holding the SHIFT key this button allows you to observe and edit
the modulations used within a patch using the 16 touch pads. Pads 1-8 represent each
modulation slot, they can be enabled or disabled. Pads 9-16 will clear the corresponding
slot 1-8 when held down for a certain time.
Modulation LEDs
• Entering an assign mode while on the mod edit page will flash all slots currently assigned
from that source.
• When assigning a modulation and adjusting the assignment depth, the led for the
modulation slot is flashed.
• If you try to enter an invalid or duplicate modulation the 16 touch pad LEDs will all flash
together.
