Please read this owner's manual carefully before operating,
and keep it for reference.
TTW Air Conditioner
OWNER'S MANUAL
GAA07AA-D3RNA2C
GAA09AA-A3RNA2C
GAA09AA-D3RNA2C
GAC09AA-A3RNA2C
GAC09AA-D3RNA2C
GAE09AA-D3RNA2C
GAA12AA-D3RNA2C
GAC12AA-A3RNA2C
GAC12AA-D3RNA2C
GAE12AA-D3RNA2C
MODELS
© Copyright, Sunrise Tradex Corp., 2016
Advertisement
Table of Contents
Related Manuals for Gree GAA07AA-D3RNA2C
Summary of Contents for Gree GAA07AA-D3RNA2C
- Page 1 Please read this owner's manual carefully before operating, and keep it for reference. TTW Air Conditioner OWNER’S MANUAL MODELS GAA07AA-D3RNA2C GAA09AA-A3RNA2C GAA09AA-D3RNA2C GAC09AA-A3RNA2C GAC09AA-D3RNA2C GAE09AA-D3RNA2C GAA12AA-D3RNA2C GAC12AA-A3RNA2C GAC12AA-D3RNA2C GAE12AA-D3RNA2C WWW.GREE.CA St-Mathieu-de-Beloeil (Québec) Canada 1 866 680 GREE © Copyright, Sunrise Tradex Corp., 2016 00747_23/03/2016...
-
Page 2: Table Of Contents
Contents SAFETY PRECAUTIONS ....................1 IMPORTANT NOTE TO THE OWNER ................4 IMPORTANT NOTE TO THE SERVICER ..............4 TRANSPORTATION DAMAGE ..................4 UNPACKING THE UNIT....................4 OPERATING INSTRUCTIONS ..................4 INSTALLATION INSTRUCTIONS ................5 WIRING ........................8 AIR CONDITIONER FEATURES ..................9 AUXILIARY CONTROLS-DIP SWITCHES ..............13 AIR CONDITIONER FEATURES ................14 ADDITIONAL THINGS YOU SHOULD KNOW ............19 WARRANTY ......................20 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental... - Page 3 EXPLANATION OF SYMBOLS Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING WARNING This symbol indicates the possibility of death or serious injury. - Page 5 SAFETY PRECAUTIONS CAUTION When the air filter is to be Ventilate the room well when Do not clean the air conditioner removed, do not touch the metal used together with a stove, etc. with water. parts ofthe unit. It may cause an injury. Water may enter the unit and An oxygen shortage may occur.
- Page 6 SAFETY PRECAUTIONS NOTICE The power supply cord with this air For your safety WARNING conditioner contains a current detection Do not store or use gasoline or other flammable vapors and liquids in device designed to reduce the risk of the vicinity of this or any other appliance. fire.
-
Page 7: Important Note To The Owner
SAFETY PRECAUTIONS IMPORTANT NOTE TO THE OWNER OPERATING INSTRUCTIONS This equipment is to be serviced by professionally trained Check the data specification plate and ensure the proper personnel only. If this equipment is improperly installed, voltage and current rating for the type of power plug on the adjusted or altered by an unqualified person, a safety unit is available. -
Page 8: Installation Instructions
Installation CHASSIS INSTALLATION WARNING 1. Remove front grille. See Figure A. To prevent electrical shock, property damage, personal injury, or death, do not removegroundingprongfromplug. Follow Lift up on all operating instructions. Filter Handle INSTALLATION INSTRUCTIONS To ensure that the unit operates safely and efficiently, it must be installed, operated, and maintained according to these installation and operating instructions and all local codes and ordinances, or, in their absence, with the latest... - Page 9 Installation Locking Plate MOUNTING SCREW GROUND WIRE Figure 3 3. Remove shipping pads inside air conditioner next to compressor. (See Figure B.) Figure C 6. If outlet is on the left side of the unit. route power cord as shown in Figure D Power Remove Cord...
- Page 10 Installation To replace front grille: Grille ExHAUST AIR VENT AIR DIRECTION: Horizontal louvers on the front grille let you control the air direction up and down. Hook the tabs on the front grille even with the tabs on the case and snap into place. Replace the screws and filter.
-
Page 11: Wiring
Installation WIRING Remove the front grille to adjust the vertical louvers side-to-side to direct the air left or right. Before wiring the unit, please review the following warnings and cautions. WARNING To avoid the risk of electrical shock, personal injury or death, do not service this unit without first opening all disconnects and/or removing the unit cord set plug from the wall outlet. -
Page 12: Air Conditioner Features
AIR CONDITIONER FEATURES ELECTRONIC CONTROL OPERATING INSTRUCTION Before you begin, thoroughly familiarize yourself with the control panel and remote as shown below and all its functions. Then follow the symbol for the functions you desire. The unit can be controlled by the touch pad alone or with the remote. LOWERS TEMPERATURE DISPLAYS OR TIME... - Page 13 ELECTRONIC CONTROL OPERATING INSTRUCTIONS NOTICE: • When power is connected (stand by condition), you can operate the air conditioner through the remote controller. • When unit is on, each time you press the button on remote controller, the sending signal icon " "on the display of remote controller will blink once.
- Page 14 ELECTRONIC CONTROL OPERATING INSTRUCTIONS Pressing this button can select fan speed circularly as: AUTO, SPEED 1 NOTES: • Under Auto speed, air conditioner will select proper fan speed automatically according to ambient temperature. • Fan speed can't be adjusted under Dry mode. •...
- Page 15 ELECTRONIC CONTROL OPERATING INSTRUCTIONS Press “+” and “-” buttons simultaneously can turn on or turn off child lock function. When child lock function is started up, LOCK indicator on remote controller is ON. If you operate the remote controller, remote controller won’t send signal. Under OFF status, press “-”...
-
Page 16: Auxiliary Controls-Dip Switches
ELECTRONIC CONTROL OPERATING INSTRUCTIONS The auxiliary dip switch controls are lacated behind the room cabinet-as Filter Reminder Function shown in this figure. Temperature Limitation Function The owner is responsible for checking Fan Cycle/ switches and ensuring they are in the Continuous-Cool desired position. -
Page 17: Air Conditioner Features
ELECTRONIC CONTROL OPERATING INSTRUCTIONS TO TURN ON: YOU WILL SEE: TO THIS: Auto Auto High High Heat Heat PRESS ON/OFF Cool Cool Fan Only Fan Only BUTTON Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed Reset Reset Timer Timer Filter Filter TO CHANGE TEMPERATURE SETTING:... - Page 18 ELECTRONIC CONTROL OPERATING INSTRUCTIONS TO OPERATE ON FAN ONLY: YOU WILL: LIGHT ON DO THIS: Auto Auto High PRESS High Heat Heat Cool Cool MODE BUTTON Fan Only Fan Only Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed CHOOSE FAN ONLY Reset Reset Timer...
- Page 19 ELECTRONIC CONTROL OPERATING INSTRUCTIONS COOLING FEATURE YOU WILL SEE: (ON SOME MODELS): DO THIS: Auto Auto High High Heat Heat Cool PRESS Cool Fan Only Fan Only MODE BUTTON Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed SELECT COOL Reset Reset Timer Timer...
- Page 20 ELECTRONIC CONTROL OPERATING INSTRUCTIONS ELECTRICAL HEATING ONLY FUNCTION 3. If it needs to resume to factory 4. If it is successfully set, you will status, please press POWER and hear two sounds of “didi”, the RESET FILTER buttons for display screen will display “HH” 2 seconds under the power-off and the unit will resume to factory status with the power cord is...
- Page 21 ELECTRONIC CONTROL OPERATING INSTRUCTIONS AIR CONDITIONER FEATURES (CONTINUED) FAULT CODES Auto Auto High High Heat Heat Cool Cool Fan Only Fan Only Mode Mode Temp/Timer Temp/Timer Temp/Timer Temp/Timer Speed Speed Reset Reset Timer Timer Filter Filter If the display reads “F1” If the display reads “F2”...
-
Page 22: Additional Things You Should Know
ELECTRONIC CONTROL OPERATING INSTRUCTIONS ADDITIONAL THINGS YOU SHOULD KNOW Now that you have mastered the operating procedure, here are more features in your control that you should know. • The Remote Control will operate ali the control panel features, follow the same instructions. The "Cool "circuit hasan automatic 3 minute ti me delayed start if the unit is turned off and on quickly. -
Page 23: Warranty
Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
