- Page 1 Through-the-Wall Unit Owner's Manual GAA09AA-D6NRNB2D GAA12AA-D6NRNB2D IMPORTANT : Please read this manual carefully before using the appliance and keep it for future reference. © Copyright, GREE Canada, 2024 052024...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. SAFETY GUIDELINES ......................4 2. PRE-INSTALLATION INFORMATION ..................7 3. INSTALLATION ........................10 5. OPERATION ..........................14 6. COMPLEMENTARY INFORMATION ..................19 7. PREVENTATIVE MAINTENANCE ..................20 8. TROUBLESHOOTING ......................21 9. SERVICE ........................... 23 If it is necessary to install, move or service the heat pump, please contact your dealer or local service center first. -
Page 4: Safety Guidelines
SAFETY GUIDELINES SAFETY SYMBOLS DESCRIPTION The following symbols are used throughout this manual to indicate immediate or potential hazards. It is the owner’s responsibility to read and follow all safety information and instructions accompanying these symbols. Failure to heed safety information increases the risk of serious injury or death, property damage and/or product damage. - Page 5 SAFETY GUIDELINES REFRIGERANT SPECIFICATIONS A special refrigerant circulates in the system to achieve the air conditioning operation. The refrigerant used is fluoride R32, which is particularly environmentally friendly. The refrigerant is flammable and odorless. In addition, it can lead to an explosion under certain conditions, but the flammability of the refrigerant is very low.
- Page 6 SAFETY GUIDELINES SAFETY PRECAUTIONS WARNING : ▪ This appliance is not intended for use by per- ▪ Keep away from sources of fire, as well as sons (including children) with reduced phys- flammable and explosive objects. ical, sensory or mental capabilities or lack of ▪...
-
Page 7: Pre-Installation Information
PRE - INSTALLATION INFORMATION OPERATION ENVIRONMENT OPERATING TEMPERATURE RANGE Indoor Side DB/WB (°C / °F) Outdoor Side DB/WB (°C / °F) Maximum Cooling 32.2 / 22.8 (90 / 73) 43.3 / 25.6 (110 / 78) Maximum RC Heating 26.7 / – (80 / –) 23.9 / 18.3 (75 / 65) Maximum Electric Heating 25 / –... - Page 8 PRE - INSTALLATION INFORMATION POWER SUPPLY CORD This air conditioner is equipped with a UL-required power cord. The cord contains state-of-the-art elec- tronics that detect current leaks. If the cord is crushed, the electronics detect the leakage current and the power supply is cut off in a fraction of a second. To test your power supply cord : 1.
- Page 9 PRE - INSTALLATION INFORMATION WARNING : Electrical Information ▪ Make sure the electrical service is adequate for the model you've chosen. This information can be found on the nameplate, located on the side of the housing and behind the grille. ▪...
-
Page 10: Installation
INSTALLATION SLEEVE INSTALLATION FIGURE 2-2 In order to ensure that condensation drains prop- Grille erly inside the unit, the sleeve must be installed correctly : ▪ Level from right to left. ▪ A slight downward incline from the inside to the outside, as shown in Figure 1. - Page 11 INSTALLATION 3. Remove the shipping pads inside the air con- 7. Hook the tabs on the front grille even with the ditioner next to the compressor (see Figure 4). tabs on the case and snap into place. Replace the screws and filter. FIGURE 4 FIGURE 7 Grille...
- Page 12 INSTALLATION AIR VENT CONTROL FIGURE 8 The air vent control is located behind the front Locating hole Locating hole grille, on the right-hand side of the air vent. When set to “CLOSED”, only the air inside the room is circulated and conditioned. When set to “OPEN”, part of the indoor air is exhausted to the outside.
- Page 13 WIRING Before wiring the unit, please read the warnings and instructions in this manual. WARNING : ▪ To avoid risk of electric shock, injury or death, do not service this unit without first opening all discon- nections and/or disconnecting the unit’s cord plug from the wall socket. ▪...
-
Page 14: Operation
OPERATION CONTROL PANEL OPERATION Before you start, please familiarize yourself with the control panel and remote control and all their functions. The unit can be controlled by the touchpad alone or by remote control. Display screen HEAT Fan speed indicators Operating mode indicators... - Page 15 OPERATION TIMER Button Allows you to set a timer. NOTE 1 : To set a switch-off timer, the unit must be in the ON position. NOTE 2 : To set a switch-on timer, the unit must be in the OFF position. To set the timer, press or hold the + or –...
- Page 16 REMOTE CONTROL OPERATION NOTE : Make sure there are no obstructions between the receiver and the remote control ; do not drop or throw the remote control ; do not allow liquids to enter the remote control and do not place the remote control in direct sunlight or in a very hot place.
- Page 17 BATTERY REPLACEMENT TIMER Button (continuation) The time will increase or decrease by 0.5 hours 1. Press slightly on the tab of the battery cover with each press of these buttons. Holding either on the back of the remote control to remove it. button for a prolonged period (over 2 seconds) 2.
- Page 18 OPERATION AUXILIARY CONTROLS - DIP SWITCHES ▪ Auxiliary DIP switch controls are located behind the unit cabinet, as shown in the illustration below. ▪ The owner is responsible for checking the switches and ensuring that they are in the desired position. Filter cleaning reminder Temperature limitation Cyclic or continuous fan operation in cooling mode...
-
Page 19: Complementary Information
COMPLEMENTARY INFORMATION Now that you’ve mastered the operating procedure, here are some other features you need to know about. ▪ The cooling circuit features a 3-minute automatic start-up delay if the unit is switched off and on quickly. This prevents overheating of the compressor and possible tripping of the circuit breaker. The fan continues to run during this period. -
Page 20: Preventative Maintenance
Special training in addition to the usual refrigeration repair procedures is required when equipment containing FLAMMABLE REFRIGERANTS is involved. ELECTRICAL DIAGRAM Electrical diagrams are subject to change without notice. Please refer to the one on the unit. GAA09AA-D6NRNB2D / GAA12AA-D6NRNB2D... -
Page 21: Troubleshooting
TROUBLESHOOTING COMMON ISSUES If your appliance appears defective, please check the possible explanations for your situation in the table below, it may be that a simple solution can help solve the problem. If the problem persists, please call our Service Center at 1 800 686-2175 for assistance. SITUATION POSSIBLE CAUSES SOLUTIONS... - Page 22 TROUBLESHOOTING NOTE : If the circuit-breaker trips or the fuse blows repeatedly, call in a qualified electrician. MALFUNCTION CODES If any of the following malfunction codes appear on the display screen of the unit, please call Customer Service at 1 800 686-2175 for assistance. CODE DESCRIPTION Indoor ambient temperature sensor open or short-circuited.
-
Page 23: Service
SERVICE GUIDE SPECIAL SAFETY PRECAUTIONS FOR FLAMMABLE REFRIGERANTS Aptitude requirement for service technician (repairs ▪ Ensure that the leak detection equipment being should be done only be specialists). used is suitable for use with flammable refriger- ants, i.e. non-sparking, adequately sealed or in- a. - Page 24 SERVICE GUIDE – The ventilation machinery and outlets are oper- original specification, damage to seals, incorrect fitting of glands, etc. ating adequately and are not obstructed; ▪ Ensure that apparatus is mounted securely. – If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the ▪...
- Page 25 SERVICE GUIDE (detection equipment shall be calibrated in a re- ▪ This process shall be repeated until no refrigerant is within the system. When the final OFN charge frigerant-free area). is used, the system shall be vented down to atmo- –...
- Page 26 SERVICE GUIDE and being used correctly; possible, cooled before recovery occurs. – The recovery process is supervised at all ▪ The recovery equipment shall be in good work- ing order with a set of instructions concerning the times by a competent person; equipment that is at hand and shall be suitable for –...
