Franklin 30129X Quick Manual

The net has been designed with red tabs to identify the top
corners and blue tabs to identify the bottom front corners.
Follow the numbered sequence to attach the net.
Net Assembly Instructions
1. Using 4 self-stick closure straps, 2 for each corner on the
top bar, tie the top right and top left corners, identi ed by the
two RED tabs.
2. Using 4 self-stick closure straps, 2 for each corner on the
lower front bar, tie the lower right and lower left corners
identi ed by the two BLUE tabs.
3. Stretch the net and using 4 self-stick closure straps tie 2 each to the
back bottom corners.
4. Fill in the top front section with 8 self-stick straps.
5. Fill in the two side sections with 6 self-stick straps.
6. Fill in the bottom back section with 8 self-stick straps.
NOTE: Adjust the self-stick straps by moving the straps left or
right as necessary to prevent large gaps.
NOTE: Following goal assembly, 6 ground stakes will help secure
the goal. Two are recommended placed over each side/base tubes,
right side and left side near the front. Two are recommended placed
over the back/base tubes.
Franklin Sports Inc.
Stoughton, MA 02072
Made in China
For replacement parts call:
1-781-341-5178 or 1-800-225-8649
OR visit www.franklinsports.com
NO. 30129X
FOLDING SOCCER GOAL
SIZE: 6ft High x 12ft Wide
(1.83m x 3.65m)
BEFORE ASSEMBLY:
Work on a smooth, at surface.
Lay out all components so they are in easy reach.
Read assembly instructions completely to familiarize
yourself with the components before you begin assembly.
This goal is designed to provide many hours of
enjoyment if properly assembled and used only
for the purpose intended.
Adult supervision is recommended when the goal
is used by children.
