NET ASSEMBLY
RED TAB
2
11
8
9
6
4
BLUE TAB
NOTE
The net has been designed with red tabs to identify the top corners and blue tabs to identify the
bottom corners. Follow the numbered sequence to attach the net, part 9, using self stick straps,
part 11.
Using the self-stick closure strips, tie the top corners first which are identified by the two red tabs.
Refer to 1 & 2.
Using the self-stick closure strips, tie the front bottom corners which are identified by the two
blue tabs. Refer to 3 & 4.
Stretch the net and using the self-stick closure strips, tie the back bottom corners. Refer to 5 & 6.
Fill in the top front section 7 with 4 self-stick strips,
Fill in each of the two side sections 8 with 3 self-stick strips,
Fill in each of the two base sections 9 with 3 self-stick strips,
Fill in the bottom back section 10 with 4 self-stick strips.
Fill in each of the two reinforcement sections 11 with 3 self-stick strips.
NOTE: Following goal assembly 6 ground stakes, part 10, will secure goal.
Refer to net assembly above for recommended locations
YOU ARE NOW READY TO PLAY!
