VOLUTE PUMP
Models SJS/SJ4S
Instruction Manual
Do not operate，service or inspect this pump untill you have
read and understood this manual．
Keep this manual in a safe place where it can be consulted
at any time．
To：All mechanical Contracter
Make sure to supply copies of this manual to the customer's
operator maintenance and inspection personnel．
Advertisement
Table of Contents
Related Manuals for Teral SJS
Summary of Contents for Teral SJS
- Page 1 VOLUTE PUMP Models SJS/SJ4S Instruction Manual Do not operate，service or inspect this pump untill you have read and understood this manual． Keep this manual in a safe place where it can be consulted at any time． To：All mechanical Contracter Make sure to supply copies of this manual to the customer's...
- Page 2 Limit of Liability １．Warranty period is for period of 18 months after date of the bill of lading or 12 months after installation whichever earlier． ２．During warranty period，equipment sold is warranted to the Buyer to be free from defective material and workmanship．If Buyer notifies Seller in writing of any claimed defect in the equipment and if，after appropriate reasonable opportunity to inspect and remedy any defect by Seller，the equipment is found not be in conformity with this warranty，the Seller will，...
-
Page 3: Table Of Contents
Purpose of this Manual The purpose of this manual is to provide the detailed information that the user needs to know in order to correctly operate，service and inspect the volute pump． This manual is intended for persons experienced in the operation of volute pumps，or for persons who have received instruction from such experienced persons．Wiring and electrical work must be performed by qualified persons only. -
Page 4: １．Safety
１．Safety １.１ Warnings The Warnings used in this manual are graded into 4 types，according to the degree of danger（or seriousness of potential accident）that they signify． DANGER indicates the highest degree of danger，followed by WARNING and CAUTION， in that order． There are also NOTES，which draw attention to important information． Be sure to know the degree of danger signified by the various types of warning，and follow all the instructions that they give．... -
Page 5: Safety Instruction For Installation，Maintenance And Inspection
１.２.２ Safety instructions for installation，maintenance and inspection （1）Installation，maintenance and inspection of the pump should be performed by personnel who have been trained in its operation and use． Electrical wiring work should be performed only by suitably qualified personnel or electricians． （2）Backup pump have to be prepared if the occupation is very important and possible cause heavy trouble when suspension of water supply. -
Page 6: Structure And Overview Of The Pump
２．Structure and overview of the pump ２.１ Names of parts ① Casing The piping is connected to the casing． The impeller，which giving pressure to the pumped water by its rotation，is housed inside the casing． ② Motor ③ Common bed ④ Bearing case The sealed ball bearing is housed in it．... -
Page 7: Specifications
Do not use the pump in conditions out of its specification ranges． If the pump is used out of these ranges，electric shock，fire，or breakdown could result． Specifications Applicable models Model SJS Model SJ4S ※１ Pump Qualities Fresh water or special medium... -
Page 8: Befor Using The Pump
３．Installation ３.１ Before using the pump When receiving pump，check the following： If any defects，contact agent． Before unpacking，make sure that the pump is the right side up． Especially if packing is wooden crate，beware of nails， or you could hurt yourself． （1）Are all descriptions on name plate as ordered？ （2）Has any damage occurred during transportation？... -
Page 9: Installation Procedure
３.３ Installation procedure （1）Provide a foundation of ample area and depth to bear the weight of the pump and its operating load． （2）Provide holes in the foundation in accordance with the drawings，or else using the pump itself to determine the hole positions prior the pump is installed． Anchor bolt and anchor bolt hole dimensions （3）Make sure that the surface of the concrete foundation is level，and protect it thoroughly until the pump is installed．... - Page 10 （6）Place level gauge on the surface of the flange，and check that the flange is perfectly horizontal．If it is not，use the metal wedges to adjust it． （7）Confirmation of shaft alignment． The shafts is aligned before shipment．However，if the shafts may become offset during transport，re-align it at site．...
-
Page 11: Cautions For Piping Work
３.４ Cautions for piping work （1）Make the suction piping as short as possible，with as less bends as possible． （2）Provide pipe supports for the piping，so that the weight of the piping is not imposed on the pump. The weight of the piping must not be imposed on the pump．If it is，the alignment will become offset，resulting in damage to the equipment，vibration or noise．... - Page 12 (12) Cautions for double Mechanical seal. • Prepare another pump for flushing liquid circulation, as flushing from the outside is needed for a sealing surface by double mechanical seal specification. • Refer to materials list for the structure of a double mechanical seal. •...
- Page 13 ３.５ Instructions for wiring work Use good quality wiring equipment for wiring． Wire the pump safely，in comply with the local requlations or codes． The pump must be wired by a qualified electrician or other suitably qualified person． It is illegal，and very dangerous，for unqualified people to perform wiring work.
-
Page 14: Preparation For Operation
４．Preparation for operation ４.１ Checks prior to test operation ４.１.１ Electrical system checks （1）Check that the wiring has been connected correctly． （2）Check that terminal connections have been secured． （3）Check that grounding has been carried out properly． （4）Check that the setting of the overload protection device is the motor's rated current．... -
Page 15: Test Operation
Test operation ・Fix a coupling cover back befare operating the pump．Hands could get caught up in the coupling． ・Be sure to fix terminal box cover of motor． There is danger of electric shock． Before operate a pump, flushing the inside of pipe. Any foreign substance in pump may cause damage on shaft seal or rotation slide part. - Page 16 （3） Gradually open the sluice valve on the discharge side， until the specified discharge pressure is reached． （4）Check for abnormal pressure，current，noise or vibration． （5）Close the discharge sluice valve，and stop the pump． Speed (min Standard data in bearing part Keep the cocks of the pressure gauge，compound gauge and other instruments closed at all times，except when they are being used for checking．...
-
Page 17: Maintenance And Inspection
5．Maintenance and inspection Before inspecting the pump，always turn off its main power supply． Otherwise the pump could suddenly start up in auto operation， exposing personnel to great danger. ５.１ Cautions for maintenance and inspection （1）When carrying out daily inspection，carefully observe the following instructions． ①... -
Page 18: Mechanical Seal
（2）If the pump is out of use for prolonged periods，observe the following instructions： ① In the wintertime，there is danger that the pump interior may freeze，so be sure to drain all the water from the pump，or else provide thermal insulation． ② If there is a stand by pump， run it from time to time to keep it in good operating condition． ③... -
Page 19: Gland Packing
５．４ About gland packing （１） Adjust the leakage of gland packing as below. Avoid to adjust it in the beginning of driving a pump. But loosen the nut of packing if gland packing housing is unusual heat, or be to few amount of leakage. After driving a pump for 30 minutes, if the leakage amount is too much, fasten the packing nut slowly as watching the generation of hear. -
Page 20: Periodic Inspection Table
５.５ Periodic inspection table Replacement or repair of parts should be performed by personnel from a specialist company or by a service agent approved by the manufacturer． Incorrect replacement or repair can cause beakdown or malfunction. Inspection Part for inspect- Consumable items What to inspect Method... -
Page 21: Troubleshooting
６．Troubleshooting If some trouble occurs in the pump，investigate the cause very thoroughly．If parts need to be repaired or replaced，have the repair or replacement performed by a specialist company or a service agent appointed by the manufacturer. Fault Causes Action Power supply fuse blown Replace with correct fuse Disconnected or broken wires Repair or replace... - Page 22 Fault Causes Action Bearings damaged Pump must be disassembled and Grease needs replacing inspected，so contact Bearings overheated specialist company Shaft is bent Pump poorly installed / shafts Re-align correctly poorly aligned Impeller clogged with foreign matter，causing imbalance Pump must be disassembled and Bearings worn or damaged inspected，so contact Shaft is bent...
- Page 24 Head Office 230, Moriwake, Miyuki-cho, Fukuyama-city, Hiroshima, 720-0003, Japan Tel.+81-84-955-1111 Fax.+81-84-955-5777 www.teral.net 2016 06 TP‑246‑01...
