Task Force Tips TRANSFORMER Instructions For Safe Operation And Maintenance page 7

PARTS LIST
INDEX
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
©Copyright Task Force Tips, Inc. 2013-2014
DESCRIPTION
PIERCING NOZZLE STRIKING CAP
O-RING-125
O-RING-012
PIERCING NOZZLE STRIKING PLUG
BELLEVILLE WASHER
7/16-14 NYLOCK HEX NUT
3 PORT JUNCTION BLOCK
LABEL: BRAND
19" EXTENSION TUBE
40" EXTENSION TUBE
12" EXTENSION TUBE
GRIP MOUNT
GRIP SPACER
PISTOL GRIP - BLACK
WASHER
3/8-16 X 1 SOCKET HEAD SCREW
FLOW PATTERN EXTENSION SECTION
PIERCING POINT
NAME LABEL: TRANSFORMER PIERCING NOZZLE
LABEL: ROTARY VALVE OFF - RED
LABEL: ROTARY VALVE ON - BLUE
FOLLOWER
3/8-24 X 3/8 DOG POINT
LABEL: ROTARY VALVE - BLUE
O-RING-130
VALVE BODY
CAP
O-RING-135
SEAT
VALVE
INLET ADAPTER
3/16" SS BALL (34) PER RACE
PORT PLUG
O-RING-134
GASKET GRABBER
COUPLING 1.5"
GASKET - 1.5" HOSE COUPLING
STORAGE BAG
MATE
NOZZLE BASE
HEX PORT PLUG
NOGGIN
SPINNER
* - CONSULT FACTORY FOR SPECIAL THREADS
QTY. PART
1 PA161
9 VO-125
1 VO-012
1 PA162
2 VM4903
1 VT43-14LNT
1 PA150
3 PA206
2 PA110
1 PA170
1 PA230
1 PA250
1 HM693-F
1 HM692-BLK
1 VM4901
1 VT37-16SH1.0
1 PA120
1 PA141
2 PA205
1 PA227
1 PA226
2 U251
2 H515
1 PA228
2 VO-130
1 PA221
1 PA224
1 VO-135
1 PA223
1 PA222
1 PA225
68 V2120
2 B770
2 VO-134
1 G606
2 G690*
2 V3130
1 PA200
1 PA264
1 PA261
1 PA265
3 PA262
3 PA263
7
