The charts in section 8.0 of this document give specific examples of maximum flow rates for particular situations. Friction
losses may vary due to differences in hose construction resulting in flows different than those shown. For situations or
lengths of hose not listed on the chart, approximate flows can be calculated using conventional hydraulics.
DANGER
CAUTION
WARNING
WARNING

4.0 NOZZLE CONTROLS

4.1 FLOW CONTROL

4.1.1 LEVER TYPE FLOW CONTROL

On models that use a lever type valve handle, the nozzle is shut off when the handle is fully forward. The valve handle has
six detent flow positions. These detent positions allow the nozzle operator to regulate the flow of the nozzle depending on
the need or what can be safely and effectively handled. TFT recommends the use of a pistol grip for easier handling. For
additional stress reduction, a hose rope or strap may also be used. This permits more effective use and ease of
advancement, while minimizing strain and fatigue.
