- Page 1 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 USERS GUIDE KM6S LCD...
-
Page 2: Table Of Contents
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Preface Preface................................ - 1 - 1. Appearance and Size........................... - 2 - 1.1 Material and Color.......................... - 2 - 2.Function Summary and Button Definition...................- 3 - 2.1 Function Summary......................... - Page 3 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.14.1 Personalized Password Input................... - 16 - 5.14.2 Battery Indicator Setting....................- 18 - 5.14.3 PAS Parameter Setting...................... - 18 - 5.14.4 Current Limit Setting......................- 19 -...
-
Page 4: Preface
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Preface Dear users, To ensure better performance of your e-bike, please read through the KM6S product introduction carefully before using it. We will use the brief words to inform you of all the details (including hardware installation, setting and normal use of the display) when using our display. -
Page 5: Appearance And Size
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 1. Appearance and Size 1.1 Material and Color KM6S uses white and black PC materials. Under the temperature of -20℃ to 60℃, the housing material can ensure normal use and good mechanical... -
Page 6: Function Summary And Button Definition
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 2.Function Summary and Button Definition 2.1 Function Summary KM6S offers plenty of functions and showing to meet your requirements. The indicated contents are as following: ◆Battery indication... -
Page 7: Normal Display Area
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 2.2 Normal Display Area KM6S normal display area 2.3 Button Definition The display with three buttons, in the following introduction ，... -
Page 8: Installation Instruction
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 4. Installation Instruction Fix the display on the handlebar, adjust the angel. Plug the two connectors from display and controller when off power supply. -
Page 9: Display Interface
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.2 Display Interface After the indicator is turned on, it shows the following interface. Display interface 5.3 Trip/ODO/Trip Time Press MODE to switch between Trip, ODO and Trip time.This function is convenient for users to check the current trip mileage (TRIP), accumulated total mileage (ODO) and current trip time (TRIP TIME). -
Page 10: Real Time Speed/Average Speed/Max Speed
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.4 Real Time Speed/Average Speed/Max Speed After turning on display, it shows real time speed. Hold MODE and DOWN buttons simultaneously for 2 seconds, the average... -
Page 11: Turn On Backlight
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 The walk assist function can only be used when the user pushes the electric vehicle, please do not use it in the riding state. -
Page 12: Battery Indicator
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 PAS level selection interface 5.8 Battery Indicator When the battery voltage is high, the five-segment LCD is on. When the battery is under voltage, the battery frame flashes, indicating that the battery is seriously under voltage and needs to be charged immediately. -
Page 13: Error Code
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Power display interface 5.10 Error Code When the electric vehicle electronic control system fails, the display will automatically display an error code. For the definition of the detailed error code, see Appendix 1. -
Page 14: Trip Clearance Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 display enters the setting state.In the setting interface, shortly press MODE to switch setting items 5.11.1 Trip Clearance Setting TC stands for Trip Clearance, setting parameters can be N/Y. The default N means that the mileage of a single ride is not cleared. -
Page 15: Display Unit (Metric/Imperial)
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Backlight brightness setting interface 5.11.3 Display Unit (Metric/Imperial) Unit represents the display unit. The parameter Metric/Imperial can be set. The factory default is metric. The parameters can be changed by UP/DOWN. -
Page 16: Password Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.12 Password Setting Hold UP and DOWN buttons simultaneously for 2 seconds to enter the general setting state; then hold UP and MODE buttons simultaneously for 2 seconds to enter the power-on password setting state. -
Page 17: Password Modification
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 No password required Password enabled 5.12.2 Password Modification Press MODE to shift and increase/decrease the value by UP/DOWN. After the modification is completed, hold MODE button to save the confirmation and exit the setting state. -
Page 18: Wheel Size Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 input value by UP/DOWN. After the 4-digit password is entered, press MODE button to confirm. If the password is correct, enter the power-on password setting interface, otherwise it will stay in the password input state. -
Page 19: Speed Limit Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Wheel size setting 5.13.2 Speed Limit Setting The default maximum riding speed is 25Km/h. Change this value to set the maximum riding speed of the e-bike. When the electric motor exceeds the set value, the controller will stop supplying power to the motor to protect the rider's safety. - Page 20 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 seconds to enter the personalized parameter setting state. The display prompts “PASSWORD 3”, indicating that you need to enter the permission password. Press MODE button to shift, and increase/decrease the input value by UP/DOWN.
-
Page 21: Battery Indicator Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.14.2 Battery Indicator Setting VOL indicates the battery indicator setting. It is required to input the voltage values of 1 to 5 one by one. Take the first battery value as an example: “1” on the display indicates the first voltage and “31.5”... -
Page 22: Current Limit Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Pas level selection 5.14.3.2 PAS Proportion Setting By setting the PAS proportion, you can adjust the speed of each assist level to meet the needs of different riders. -
Page 23: Pas Sensor Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Change the maximum current value of the controller by UP/DOWN. Hold MODE to confirm and return to the personalized parameter setting interface. The factory default value of the display is 15A. - Page 24 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 PAS sensor direction setting 5.14.5.2 PAS sensor sensitivity setting The display shows SCN, indicating the sensitivity of the PAS sensor. The setting range is 2-9.
-
Page 25: Speed Sensor Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 PAS sensor proportion parameter setting 5.14.6 Speed Sensor Setting SPS indicates the speed sensor setting. It can be set according to the number of magnet heads mounted on the wheel of the e-bike, and the setting range is 1-9. -
Page 26: Throttle Function Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 5.14.7 Throttle Function Setting 5.14.7.1 Throttle Walk Assist Enable Setting HL indicates the throttle’s walk assist function. HL: N means that the throttle does not has this function, and HL: Y means that throttle has this function, that is, when turning the throttle, the display enters the walk assist mode. -
Page 27: System Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Throttle level enable setting 5.14.8 System Setting 5.14.8.1Battery Delay Time Setting DLY represents the battery delay time. The battery delay time 3/6/12s can be selected by UP/DOWN. - Page 28 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Max speed limit setting 5.14.8.3 Button Walk Assist Enable Setting PUS indicates the button walk assist function enable setting. Switch Y/N by UP/DOWN.
-
Page 29: Exit Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Walk assist speed setting 5.14.8.5 Slow Start up Setting SSP indicates the slow start up setting. The adjustable range is 1-4. 4 is the slowest. -
Page 30: Restore Default Setting
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 The display automatically exits the setting state without any operation for 1 minute. 5.15 Restore Default Setting DEF means to restore the default parameters. Hold UP and MODE buttons simultaneously for 2 seconds to enter the Restore Default Parameters interface. -
Page 31: Error Code
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 In the recovery default, the battery indicator, ODO and TRIP are unrecoverable, but the power-on password is in recovery. Data recovery process 6.Error Code... -
Page 32: Preparation Before Power On
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 phone charging function. In any state, disconnect the phone and the charging will automatically terminate. USB charging 8.Preparation before Power On Please read the instruction manual carefully before using the display. -
Page 33: Version
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 2. The warranty: 24 months since the display out of the factory. II. The following conditions are not covered by the warranty: 1. -
Page 34: Appendix1: Password Checklist
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Appendix1: Password Checklist Screen Display Password Description Operation parameter setting 0512 password (Fixed) Default Power-on password (Can be Password modified) 1234... -
Page 35: Appendix 2: Personalized Setting List
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Appendix 2: Personalized Setting List Setting Screen Setting Content Item Display Battery 5 Battery Value Setting Indicator Setting PAS Level Selection... - Page 36 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Battery Delay Time Max Speed Setting Button walk assist enable setting System Setting Walk assist speed setting Slow Start Setting - 33 -...
-
Page 37: Appendix 3: Pas Proportion Default Value
KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 Appendix 3: PAS Proportion Default Value Level Level option 0-3/ 1-3 — — — — — — 0-5/ 1-5 — —... - Page 38 KING-METER TECHNOLOGY CO., LTD No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378 KING-METER - 35 -...
