Fujitsu UTY-VKSX Installation Manual
  1. Manuals
  2. Brands
  3. Fujitsu Manuals
  4. Media Converter
  5. UTY-VKSX
  6. Installation manual
Fujitsu UTY-VKSX Installation Manual

Fujitsu UTY-VKSX Installation Manual

Knx convertor for indoor unit
Hide thumbs

Advertisement

Quick Links

Download this manual
UTY-VKSX
INSTALLATION MANUAL
KNX CONVERTOR FOR INDOOR UNIT
For authorized service personnel only.
INSTALLATIONSANLEITUNG
KNX-KONVERTER FÜR INNENGERÄT
Nur für autorisiertes Fachpersonal.
MANUEL D'INSTALLATION
CONVERTISSEUR KNX POUR UNITÉ INTÉRIEURE
Pour le personnel agréé uniquement.
MANUAL DE INSTALACIÓN
CONVERTIDOR KNX PARA LA UNIDAD INTERIOR
Únicamente para personal de servicio autorizado.
MANUALE DI INSTALLAZIONE
CONVERTITORE KNX PER UNITÀ INTERNE
A uso esclusivo del personale tecnico autorizzato.
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
ΜΕΤΑΤΡΟΠΕΑΣ KNX ΓΙΑ ΕΣΩΤΕΡΙΚΉ ΜΟΝΆΔΑ
Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό.
MANUAL DE INSTALAÇÃO
CONVERSOR KNX PARA UNIDADE INTERIOR
Apenas para técnicos autorizados.
РУКОВОДСТВО ПО УСТАНОВКЕ
КОНВЕРТОР KNX ДЛЯ ВНУТРЕННЕГО МОДУЛЯ
Только для авторизованного обслуживающего персонала.
MONTAJ KILAVUZU
İÇ ÜNITE IÇIN KNX DÖNÜŞTÜRÜCÜ
Yalnızca yetkili servis personeli için.
仅针对授权的专业维修人员。
安装说明书
安装说明书
室内机用 KNX 信号转换器
[Original instructions]
PART NO. 9374707171-02
