Ascon tecnologic Y39 Operating Instructions Manual

Y39 - Y39S
DIGITAL ELECTRONIC
REFRIGERATION UNITS
CONTROLLER
OPERATING INSTRUCTIONS
20/04 - code: ISTR_M_Y39-_E_04_--
Ascon Tecnologic S.r.l.
Viale Indipendenza 56, 27029 Vigevano (PV) - ITALY
Tel.: +39 0381 69871 - Fax: +39 0381 698730
Sito: http:\\www.ascontecnologic.com
e-mail: info@ascontecnologic.com
PREFACE
m
This manual contains the information necessary for
the product to be installed correctly and also instruc-
tions for its maintenance and use; we therefore recom-
mend that the utmost attention is paid to the following
instructions and to save it.
This document is the exclusive property of Ascon Tecnologic
S.r.l. which forbids any reproduction and divulgation, even
partially, of the document, unless expressly authorized.
Ascon Tecnologic S.r.l. reserves the right to make any formal
or functional changes at any moment and without any notice.
Ascon Tecnologic S.r.l. and its legal representatives do not
assume any responsibility for any damage to people, things
or animals deriving from violation, wrong or improper use or
in any case not in compliance with the instrument features.
m
Whenever a failure or a malfunction of the device
may cause dangerous situations for persons, thing
or animals, please remember that the plant has to be
equipped with additional electromechanical devices
which will guarantee safety.
Ascon Tecnologic - Y39 Line - Operating Instructions - Pag. 1
Index
1 Instrument description ............................................. 1
1.1 General description ......................................................... 1
1.2 Front Panel Description ................................................... 2
2 Programming ............................................................. 2
2.1 Fast Set Point programming ............................................ 2
2.2 Standard mode parameters programming ...................... 2
2.3 Parameter Protection Using a Password ........................ 2
2.4 Customized mode parameters programming
(parameters programming level) ..................................... 3
2.5 Reset Parameters to Default Value ................................. 3
2.6 Keyboard lock function .................................................... 3
3 Usage Warnings ........................................................ 4
3.1 Admitted usage ............................................................... 4
4 Installation warnings ................................................. 4
4.1 Mechanical mounting ...................................................... 4
4.2 Dimensions [mm] ............................................................ 4
4.3 Electrical connections ..................................................... 5
5 Functions ................................................................... 5
5.1 ON/STAND-BY Function ................................................. 5
5.2 Measure and display configuration ................................. 5
5.3 Digital Input Configuration ............................................... 6
5.4 Outputs and buzzer configuration ................................... 6
5.5 Active Set Point selection ................................................ 7
5.6 Temperature control ........................................................ 7
5.7 Compressor Protection Function and Delay at Power-ON ... 7
5.8 Defrost Control ................................................................ 8
5.9 Evaporator Fans Control ................................................. 9
5.10 Alarm Functions .............................................................. 10
5.11 Function of keys
6 Accessories ............................................................... 11
7 Programmable parameters table .............................. 12
6.3 RS 485 Serial Interface by TLCNV ................................. 12
8 Problems and Maintenance ...................................... 15
8.1 Error messages ............................................................... 15
8.2 Other messages .............................................................. 15
8.3 Cleaning .......................................................................... 15
8.4 Disposal .......................................................................... 15
9 Warranty and Repairs ............................................... 15
10 Technical Data ........................................................... 15
10.1 Electrical Data ................................................................. 15
10.2 Mechanical Data ............................................................. 15
10.3 Functional Features ........................................................ 16
11 How to order .............................................................. 16
1

INSTRUMENT DESCRIPTION

1.1

General Description

Y39 is a digital controller with microprocessor that is typically
used in cooling applications that have temperature control
with ON/OFF control and defrosting control at intervals
time or at reaching temperature by stopping compressor or
by means of electrical heating or hot gas/reverse cycle.
The instrument has up to 3 relay outputs, up to 3 inputs for
PTC or NTC temperature probes and a digital input (alterna-
tive to a temperature input), in addition can be equipped with
an internal buzzer that is the sound system for alarms.
The 3 outputs can be can all be configured for controlling the
compressor or the temperature control device, the defrosting
device, the evaporation fan or, alternatively any of the previ-
ous functions, using an auxiliary device or an alarm.
The 3 inputs for temperature probes can be used to measure
the control temperature, the evaporator temperature, prod-
ucts or aux temperature, while the digital input alternative to
evaporator or Aux temperature input can be programmed
to carry out various functions such as door opened signal,
defrosting commands, selecting a different set of temperature
and /Aux ................................ 11
