Dear Customer
Congratulations! You have purchased a pool of superior quality and durability. To achieve the best possible results,
follow the instructions carefully. Failure to follow the installation procedures may result in damage to your pool or
property and void your warranty. We recommend that you make a preliminary study of the instruction booklet to
familiarize yourself with the different parts of your pool. Make sure that you understand each step thoroughly before
you begin assembling.
WARNING: Be sure you have read and understand the "Safety Information" sheets
before you begin your pool installation.
WARNING: For your safety, your pool is not designed for diving and/or jumping head first.
1
Chart 1.1 - Grass removal area (Figure 1.1)
MODEL
DISTANCE (A-B)
10'x16'
1.82m (6' 0")
10'x19'
2.75m (9' 0")
10'x22'
3.65m (12' 0")
12'x18'
1.82m (6' 0")
12'x21'
2.75m (9' 0")
12'x24'
3.65m (12' 0")
15'x24'
2.75m (9' 0")
15'x30'
4.57m (15' 0")
18'x33'
4.57m (15' 0")
When selecting the site for your pool, take into account city by-laws regarding fences and utilities laws pertaining to electrical cables
as well as the landscaping which you are planning once the pool is installed.
Please do not dive. Diving may result in permanent injury or death.
SITE PREPARATION
RADIUS (R)
1.67m (5' 6")
1.67m (5' 6")
1.67m (5' 6")
1.98m (6' 6")
1.98m (6' 6")
1.98m (6' 6")
2.43m (8' )
2.43m (8' )
2.89m (9' 6")
ASSEMBLY INSTRUCTIONS
We wish you a most pleasant and refreshing summer.
WIDTH (D)
TOTAL LENGHT (E)
3.35m (11')
5.18m (17' 0")
3.35m (11')
6.09m (20' 0")
3.35m (11')
7.01m (23' 0")
3.96m (13')
5.79m (19' 0")
3.96m (13')
6.70m (22' 0")
3.96m (13')
7.62m (25' 0")
4.87m (16')
7.62m (25' 0")
4.87m (16')
9.44m (31' 0")
5.79m (19')
10.36m (34' 0")
40309_V2_2021-01-23
OVAL POOLS
WITH SIDE SUPPORTS
MODELE 106-206-186
CORRIDOR (F)
2.08m (6' 10")
2.99m (9' 10")
3.91m (12' 10")
2.08m (6' 10")
2.99m (9' 10")
3.91m (12' 10")
2.99m (9' 10")
4.82m (15' 10")
4.82m (15' 10")
