- Page 1 ProtoMat 93s (June 95) Manual English version LPKF Laser & Electronics AG All rights reserved PM93s-E(.DOC) LPKF Laser & Electronics AG Osteriede 7 30827 Garbsen / Germany Tel.: ++49-5131-7095-0 Fax: ++49-5131-7095-90...
- Page 2 LPKF ProtoMat 93s Manual LPKF ProtoMat is a registered trademark of LPKF Laser & Electronics AG. MS-DOS and Windows are registered trademarks of Microsoft Corporation. HP-GL is registered trademark of the Hewlett Packard Corporation. All other trademarks registered for the corresponding owners.
-
Page 3: Table Of Contents
6.2 Pen holder (optional) ................. 32 6.3 Materials used for machining ............. 33 7 Milling and drilling with the LPKF ProtoMat 93s ..........34 7.1 Securing the PCB on the machine bed..........34 7.2 The mechanical working depth limiter..........35 7.3 Functional elements on the mill/drill head.......... - Page 4 8.7 Fuses, commuting the device voltage..........53 8.8 Inventory of available tools ..............56 8.9 Spare parts for the LPKF ProtoMat 93s..........58 8.10 Concluding remarks ................. 59 9 Index........................ 60 10 Declaration of conformity for LPKF ProtoMat 93s ......... 62...
-
Page 5: Introduction
LPKF ProtoMat 93s Manual 1 Introduction The LPKF ProtoMat 93s mill/drill unit is a circuit board plotter which can be used to produce prototype PCBs and gravure films, and for engraving aluminum or plastic. Familiarity with the BoardMaster driver program of the LPKF ProtoMat 93s is essential for operation of the machine. -
Page 6: General Information
General Information 2.1 Scope of supply 1. 1 LPKF ProtoMat 93s machine unit with integrated electronics 2. 1 null modem cable (LPKF ProtoMat 93s control unit-computer), AT-Adapter 9/25-pol 3. 1 set of accessories (Drafting Tape, Allen wrenches, alignment pins, tweezers, brush, 7 mm wrench, 2 red two-pin strips) 4. -
Page 7: Safety Precautions
LPKF ProtoMat 93s Manual 2.3 Safety precautions • In order to be able to guarantee the safe operation of the system the user must have read this manual and especially the safety precautions printed in bold types! • Never reach into the machine while it is running! •... -
Page 8: Installation
3. Set up the circuit board plotter so that the connecting cables to the electronic unit can move freely. 4. Connect the LPKF ProtoMat 93s to the computer with the null modem cable supplied with the system (COM1 or COM2). - Page 9 LPKF ProtoMat 93s Manual Transport safety devices of the LPKF ProtoMat 93s Description of the transport safety devices 1. Safety device 1 Attaching the machine safely to the transport support 2. Safety device 2 Securing the X-axis 3. Safety device 3 Securing the Y-axis 4.
-
Page 10: Machine Orientation
LPKF ProtoMat 93s Manual 2.6 Machine orientation LPKF ProtoMat 93s: the x-axis is the longer direction of movement CAUTION! Keep fingers and any other items out the area of movement! Description of the main machine positions: 1. PAUSE position. The machine will move to this point to load or turn the material to be machined. -
Page 11: Lpkf Protomat 93S Displays And Connections
LPKF ProtoMat 93s Manual 2.7 LPKF ProtoMat 93s displays and connections Front LPKF ProtoMat 93s POWER LPKF ProtoMat 93s Description of the front panel: 1. Operating display of the integrated machine control SMCU 2. X motor 3. High-speed spindle motor... - Page 12 LPKF ProtoMat 93s Manual Rear view of LPKF ProtoMat 93s Description of the rear panel: 1. Vacuum connection 2. Output Serial interface (9-pole) for controlling optional equipment 3. Input Serial interface (25-pole) for connection to PC serial port 4. X motor connection 5.
-
Page 13: Use Of Boardmaster
All LPKF circuit board plotters are driven via an asynchronous interface (RS232C). In the case of the LPKF ProtoMat 93s, it is operated at 9600 baud, 1 stop bit, 8 data bits, no parity and hardware handshake. The serial interface of the computer... -
Page 14: Switch-On Instructions For High-Speed Spindles
LPKF ProtoMat 93s Manual If for some reason it should be necessary to switch the machine off and on again, then change to the Machine/Settings window of the BoardMaster program and click on OK. Thus all necessary initialization parameters like speed ranges, dwell times positions and so on are again transmitted to the machine. -
Page 15: After Switching On
LPKF ProtoMat 93s Manual During set-up take note that the bearings of the high-speed spindle have to be run in first after a longer period of standstill (several months) or after transport. During initial set-up the spindle should run at 10 000 rpm for several hours. -
Page 16: Home-Position And Two-Pin System
LPKF ProtoMat 93s Manual 3.6 HOME-Position and two-pin system The HOME position must be on the machine's X axis (two-pin system) to guarantee alignment of a double sided board. The data for the bottom side of a PCB is mirrored around the X axis and therefore the board must also be rotated around the X axis to maintain registration. -
Page 17: Programming The Home Position In Boardmaster
The home position needs to be programmed on new equipment and when the system has been moved. The HOME position of the LPKF ProtoMat 93s must be precisely on the mirror (X) axis (the two-pin system with the red plastic slides) for machining double-sided PCBs. -
Page 18: Making A New Two-Pin System
LPKF ProtoMat 93s Manual Front stripe of the two-pin system 1. reference pin, may be covered by two-pin stripe (5) 2. front alignment pin 3. HOME position, min. 10 mm distance to the alignment pin 4. mirror axis 5. two-pin stripe 6. - Page 19 LPKF ProtoMat 93s Manual To make a new two-pin system, proceed as follows: 1. First press both two-pin strips into the machine groove, with the front two-pin strip pushed against the reference pin to the front of the groove. The distance between the two two-pin strips should be about the size of the base material in the X axis.
-
Page 20: Checking And Correcting The Home Position
This can be done directly by changing the home position in Machine Settings.. dialog box. 10. After making a correction, the movement should be repeated as a check. The LPKF ProtoMat 93s operating displays POWER (green): control operating display. This only comes on when the... -
Page 21: Computer-Controlled Functions Of The Lpkf Protomat 93S
The second interface (SERIAL 2) is an OUTPUT and is provided for future applications. The LPKF ProtoMat 93s control unit's SERIAL 1 is connected to a serial interface on the computer with the RS232 cable supplied. The RS232 cable (null modem) for the LPKF ProtoMat 93s circuit board plotter is... -
Page 22: The Lpkf Protomat 93S Commands
LPKF ProtoMat 93s Manual 5.2 The LPKF ProtoMat 93s Commands 5.2.1 Command structure The SMCU (Signal Processor Control Unit) control unit of the machine interprets the HP-GL commands described below and converts them into set reactions. The resolution of the machine is 0.0079375mm. This is a different resolution than that of standard HP-GL-plotters. - Page 23 LPKF ProtoMat 93s Manual EA (x,y){;} Edge rectangle absolute Draws a rectangle defined by two corner points lying diagonally to each other. The first corner point is determined by the current position and the second by the absolute coordinate (x,y).
-
Page 24: Special Commands
LPKF ProtoMat 93s Manual PD {;} Pen down Lowers the tool. PR (x1,y1{,...xn,yn}){;} Plot relative Draws a line from the current position to the relative coordinates listed one after the other. The commands PU and PD can be given between the pairs of coordinates as parameters. - Page 25 LPKF ProtoMat 93s Manual !CT (n){;} Command counter Switches between echo mode (n=1) and non-echo mode (n=0). In echo mode, the machine acknowledges every correctly completed command with the message "C<cr>". !EM (n){;} External motor Switches the mill/drill motor on (n=1) or off (n=0).
- Page 26 LPKF ProtoMat 93s Manual !ON (a){;} Output nominal position The control unit sends the nominal position (target position) of the motor axis addressed with parameter a. The following addresses are attributed to the motor axes: 0 = X,Y,Z axis 1 = X axis...
- Page 27 LPKF ProtoMat 93s Manual !TR (x,y,z){;} Plot three-D relative Carries out a physical movement from the current position to the relative coordinate (x,y,z). !TS (t){;} Time to stabilize Sets a stabilization time t=[ms] between the individual commands. !TW (t){;} Time to wait The following command is only carried out after a wait t=[ms].
-
Page 28: Special Command For The High-Speed Spindle
LPKF ProtoMat 93s Manual 5.2.4 Special command for the high-speed spindle Before communicating with the high-speed spindle, send the command for opening the SERIAL2 (!OC;), then the serial interface SERIAL2“ must be closed again (!CC;) !RM (r){;} Revolutions Motor, r=0...60. -
Page 29: Producing A Pcb With Boardmaster
LPKF ProtoMat 93s Manual 5.3 Producing a PCB with BoardMaster The job to be carried out must already be loaded or prepared in BoardMaster. For example, the data from the CircuitCAM tutorial can be used. A further requirement is that the HOME position was programmed precisely as described above. - Page 30 LPKF ProtoMat 93s Manual 19. When the drill phase is complete, mill phase MillingCompSide is selected after any through-plating. 20. The milling depth should now be set. To do this, click 1Unimill in the tool combo box. The head travels to the tool change position. Insert the universal milling cutter and, with the arrow keys, move over the base material, but not over the project, in BoardMaster.
-
Page 31: Tools And Accessories
Tools and accessories 6.1 Tools The tools for the LPKF ProtoMat 93s come in two different lengths. Tools used to machine the material surface (milling and engraving) are 30 mm long for 3 mm collets or 1.42 inch long for 1/8 inch collets, and tools used for drilling or contour milling are 32 mm long for 3 mm collets or 1.5 inch long for 1/8 inch collets. -
Page 32: Pen Holder (Optional)
LPKF ProtoMat 93s Manual Attention! Execute a tool change only in defined positions! The tools must always be inserted in the tool fixture as far as they will go. Otherwise the working depth will be incorrect. In certain circumstances, this can even result in damage to the machine base plate. -
Page 33: Materials Used For Machining
3. Set the working depth limiter so that the ink pen just comes in contact with the paper. 6.3 Materials used for machining In general all base materials supplied by LPKF can be used for machining. You are free to machine all other materials at your own risk. Take into consideration the notes of the manufacturers. -
Page 34: Milling And Drilling With The Lpkf Protomat 93S
LPKF ProtoMat 93s Manual Milling and drilling with the LPKF ProtoMat 93s 7.1 Securing the PCB on the machine bed Make 3.0 mm alignment holes in the base material and backing material spaced the same distance as the alignment pins. This can also be done with any upright drilling machine. -
Page 35: The Mechanical Working Depth Limiter
Attention! Keep your fingers away from the movement area of the machine during operation! When milling isolation channels in PCB materials, it is extremely important to keep a constant milling depth. With the LPKF ProtoMat 93s, this done by the mechanical working depth limiter. - Page 36 2. The material is held down within certain limits by the working depth limiter. The head is lowered with a solenoid and raised with a spring. The LPKF ProtoMat 93s working depth limiter 1. Holding plate 2. Knurled nut used to set milling depth 3.
-
Page 37: Functional Elements On The Mill/Drill Head
LPKF ProtoMat 93s Manual 7.3 Functional elements on the mill/drill head Mill/drill head front view 1. Shock absorber 2. Solenoid 3. Adjustment bottom head stop (Attention! Do not move!) 4. Working depth limiter 5. Knob for manual clamping 6. Connector for high-speed spindle 7. - Page 38 LPKF ProtoMat 93s Manual Mill/drill head, view from above 1. Adjusting nut for head stop, top 2. Solenoid 3. Hole for transport safety devices and options 4. Z Axis guide 5. Shock absorber 6. High-speed spindle 7. Fixing screw for working depth limiter 8.
-
Page 39: Drilling
Attention! Before milling make sure that the PCB is positioned tightly! Switch on the vacuum system! Before milling, it must be ensured that sufficiently sharp LPKF universal milling cutters (30 mm long or 1.42 inches long) are used. The milling width is set to between 0.2 and 0.5 mm or 0.008 and 0.020 inches depending on component... - Page 40 (<0.2 mm isolation) is used, the tool wears more quickly than with deeper drilling. The LPKF micro-cutters can be used to produce even smaller isolation channels, but their service life is about 10% less than that of the above-mentioned universal cutters.
-
Page 41: Contour Milling In Pcb Material
(2mm/sec. or 0.1 inch/sec). The 2 mm contour milling cutter is substantially more robust, but does not remove as much material as the 3 mm milling cutter. Many LPKF software postprocessors are calculated for the 2 mm milling cutter (e.g. CUTTING). -
Page 42: Milling Wide Isolation Channels
For engraving, set the speed of movement as appropriate for the engraving depth and the material. Use an LPKF universal milling cutter or LPKF double chamfered cutter. Attention! Use extractor when engraving, too! Aluminum front panels can be milled through with the LPKF ProtoMat 93s circuit board plotter. -
Page 43: Milling Layout Films
LPKF ProtoMat 93s Manual 7.9 Milling layout films Secure the film base (sheet of perspex or glass) on the machine table with masking tape. Lay the film material on the base with the coated (matte) side facing upwards. Now smooth the film material firmly and level on the film support until the air has been completely expelled. -
Page 44: Coloring Milled Films
LPKF ProtoMat 93s Manual 7.9.2 Coloring milled films For milled negative films, there is Duroscal Einfärber schwarz, with which positives can be made. The fully milled gravure film is colored with Duroscal Einfärber by pouring the liquid onto a SAFIR pad and spreading it evenly over the whole film. -
Page 45: Basis Material
Special base materials with a thicker copper layer of up to 300 µm can no longer be machined with the LPKF universal milling cutter. Contour milling cutters or special tools are needed for this. In these cases, we would ask that you consult us and send sample material so that tests can be carried out if appropriate. -
Page 46: Cleaning The Pcb
If cleaning by hand, the PCB is placed on a flat support. The board is brushed in the direction of the conductor paths with wet board cleaner (e.g. LPKF board cleaner PAD). The purpose of the brushing is on the one hand to remove the layer of oxidation and on the other to remove swarf in the isolation channels. -
Page 47: Practical Tips
The solution lies in selecting the right milling direction. When isolating conductor paths with LPKF isolate, the solder side should be mirrored before isolating as the isolation algorithm itself works in a clockwise direction. The standard postprocessing is already designed for this. - Page 48 LPKF ProtoMat 93s Manual • Drill deflection occurs in particular with thin tools which are no longer absolutely sharp. However, this also depends on the surface structure of the material. If, for example the glass fiber structure of FR4 materials penetrates the copper, drill deflection cannot be avoided even with a sharp tool.
-
Page 49: Appendix
LPKF ProtoMat 93s Manual Appendix 8.1 Maintenance Keep spindles clean. In rooms with a high air humidity, wipe down with a lightly oiled cloth from time to time. Keep transport spindles oiled and clean. Important! Do not oil bearings! Strip and clean working depth limiters at regular intervals. To do this, first switch the device off, then proceed as follows: 1. -
Page 50: Serial Port Serial 1
LPKF ProtoMat 93s Manual 9. Check the correct insertion depth of the spindle before setting it into operation. The distance between the drill tip and the machine plate must be 0.5 mm when the head is in its lower position. -
Page 51: Serial Port Serial 2
LPKF ProtoMat 93s Manual SERIAL 1 settings: Signal Meaning Transmit data Receive data Request to send Clear to send GND-I Ground (isolated) Data carrier detect Data terminal ready All signals are electrically decoupled; all contacts not mentioned are not used. -
Page 52: Motor Connection
8.5 Mill head connection The mill/drill head is connected to the control unit with a 15-pole socket. The socket position is described in the section entitled "LPKF ProtoMat 93s displays and connections". Important: never confuse the stepper motor and the mill/drill head cables!!! 8.6 EPROMs... -
Page 53: Fuses, Commuting The Device Voltage
1, 2, 3 and 4 and the M4 screws 5 and 6 at the bottom of the device and then remove the cable connections between the mechanical part and the control unit. Position of screws for removing the electronics from the mechanical part of an LPKF ProtoMat 93s CAUTION! Be sure the power cable is removed! - Page 54 LPKF ProtoMat 93s Manual Remove the cover with the x limit switches. The control unit thus released is constructed as follows: View of the PCB of the LPKF ProtoMat 93s PCB 1. Power filter 2. Transformer 3. Transformer connection 4. Power pack for mill/drill head 5.
- Page 55 LPKF ProtoMat 93s Manual Type Power circuit Fuse F701 3.15 A Power high level F703 3.15 A +24 V at I/O-interface F704 2.00 A +5V and VREF F705 0.50 A RS 232 C/SER 1 The units are mounted in the opposite sequence to that described above for dismantling.
-
Page 56: Inventory Of Available Tools
LPKF ProtoMat 93s Manual 8.8 Inventory of available tools Tools shaded gray cannot be used for the LPKF ProtoMat 93s. Name Diameter Length Delivery in mm 30 mm 32 mm L = in stock Universal milling cutter 0.2 - 0.4 micro milling cutter 0.1 - 0.2... - Page 57 LPKF ProtoMat 93s Manual 1.85 1.95 2.05 2.15 2.25 2.35 2.45 2.55 2.65 2.75 2.85 2.95 3.05...
-
Page 58: Spare Parts For The Lpkf Protomat 93S
LPKF ProtoMat 93s Manual 8.9 Spare parts for the LPKF ProtoMat 93s Spare part Machine Order number SMCU complete with casing for ProtoMat 3039500008 SMCU board: SMCU941 for: 3019500009 Spindle controller: HFAMP943 3039500010 Transformer for ProtoMat 3039500001 Mains filter 3009500001... -
Page 59: Concluding Remarks
Furthermore, we hereby point out to remaining risks unknown to the manufacturer which might occur due to inexpert handling of the machine. LPKF is not responsible for damage following the operation and handling of the LPKF ProtoMat 93s. This also applies to the case of these damage having been referred... -
Page 60: Index
LPKF ProtoMat 93s Manual 9 Index —A— adjustment 37 alignment pin 6; 10; 18; 19; 20; 29; 34; 35 asynchronous interface 13 —B— base material 13 Baud rate 51 BoardMaster 5; 10; 13; 14; 15; 17; 29; 30 —C— circuit board plotter 5; 8; 13; 21; 31; 32; 42; 61 —D—... - Page 61 LPKF ProtoMat 93s Manual tool change position 15; 20; 29; 30 transport safety devices 8; 9 Two-pin slide 10 two-pin system 16 —V— vacuum 7; 29; 33; 35; 39 Vacuum system 6 —W— working depth limiter 29; 30; 33; 35; 36; 37; 49 —X—...
-
Page 62: Declaration Of Conformity For Lpkf Protomat 93S
D-30827 Garbsen Germany 2. The machine designated as LPKF ProtoMat 93s is a circuit board plotter, suitable for the production of circuit boards-prototypes and engraving films, as well as for the engraving of aluminum or plastics. The series number of the above-mentioned machine is 1C.......
