The manufacturer is not responsible for any
other manipulations that the user may perform.
CAUTION periods of non-use
!
When periods of non-use are foreseen,
disconnect the current plug from the base.
DANGER supply cable
Position the supply cable so that it cannot be
stepped on, perforated or damaged by any
object located.
CAUTION cleaning
!
Always clean with a damp cloth and a neutral
soap solution. Do not use products that contain
solvents or acids.
CAUTION heat
!
Install the equipment away from all sources of
heat, such as radiators or other appliances
generating heat.

1.2 PRELIMINARY INSPECTION

On delivery of the goods, check that the packaging is not
damaged. If it is damaged, remove the product from the
packaging and carry out a visual check that it has not
been damaged during transport. If the product is
damaged, inform our distributor within 8 days of delivery.
The product is supplied on a wooden pallet. During
transport and storage, protect the product from humidity,
heat sources and possible mechanical damage (impact,
falls, etc...)
Lift and handle the product with care, using the
appropiate lifting devices.
2. General
2.1 INTRODUCTION
The instructions supplied are intended to ensure correct
installation and excellent performance of our
DRAINBOX FL drainage station.
Make reference to the specific manuals for
information regarding electric pumps .
The instructions and specifications below refer to the
standard version. Refer to the contractual sales
documentation for variations and features of the special
versions.
If it is necessary to request technical information or
2
replacement parts from our customer service
department, please give the exact name of the model,
together with the serial number.
For instructions, situations and events which are not
covered in this manual or in the sales documentation
contact, our nearest customer service point.
The range comprises devices for collecting and
pumping wastewater from 1 to 3 accommodation units
(grey water) to resolve the problem of getting
wastewater into the sewers if gravity feed is not
possible. This occurs when the wastewater collection
point is located at a lower level than the public or private
drainage system pipe to which the connexion is to be
made.
All models have an internal pump, with or without
macerator, automated with a level sensor or float. As an
option, an internal non-return valve and flapvalve can be
installed. Height and capacity can also be increased by
installing an extension.
The device allows multiple wastewater intake
connections (Ø110) depending on the installation,
together with the possibility of vertical or horizontal
delivery outlet.
Delivery is via PVC pipe (Ø63, Ø50, Ø40) depending on
the model.
All models have a ventilation pipe connector Ø63.
As an option, an audible alarm can be installed in case of
a breakdown in the discharge system.
Compliance with specific legislation EN 12050-2.

2.2 TECHNICAL FEATURES

Make reference to the specific manuals for
information regarding electric pumps.
The product must not be used in the presence
!
of dust, acids, corrosive and/or inflammable
gases.
The electric pump must not be used to pump
dangerous or inflammable liquids.
The equipment has IP 55 protection.
Nevertheless we recommend installing the
electrical cabinets in a dry, protected place.
