- Page 1 EILING ECURITY OUSINGS HS9405 S ERIES N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S...
- Page 2 IMPORTANT SAFEGUARDS where they exit from the appliance. 12. Power Lines - An outdoor system should not be located in the vicinity of overhead Read Instructions - All the safety and operating instructions should be read before power lines or other electric light or power circuits or where it can fall into such the unit is operated.
- Page 3 1 UNPACKING 4 DESCRIPTION Unpack carefully. This is electro-mechanical equipment and The HS9405 series are wall or ceiling mounted security housings should be handled with care. designed for applications such as prisons, parking garages and hos- pitals. These housings are ideal for any application requiring secure Check for the following items: CCTV monitoring.
- Page 4 5 INSTALLATION 5.2 Mounting the Unit This installation should be made by qualified service Position the top panel on the ceiling or wall, horizontally or verti- personnel and conform to the National Electrical Code cally, depending on the installation requirements. See figure 3. and applicable local codes.
- Page 5 5.3 Camera/Lens Installation Secure the camera to the mount using the _-20 x _ inch but- ton-head flange screw provided in the hardware kit. See fig- If the installation requires that the camera be mounted horizontal- ly to a wall, remove the camera bracket from the mounting system ures 8, 9 and 10 and install the alternate camera bracket provided in the hardware kit.
- Page 6 5.4 Final Assembly Mount the cover by aligning the two studs near the rear of the cover with the openings of the z-shaped slots in the top panel. Slide the cover to the rear, then upward and finally to the rear again.
- Page 7 ©2002 Aigis Mechtronics 1124 Louise Road, Winston-Salem, NC 27107-5450 Tel: 336.785.7740 Fax: 336.785.7744 100 0034 001 AIG 10/02 Printed in U.S.A. Data subject to change without notice...
