- Page 1 Stainless Steel Dust - Proof Housing Retaining ring Retaining ring HS9383S S ERIES Terminal Lug Cradle Rail Rear Cap Threaded Hole N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S W W W A I G I S M E C H...
- Page 2 hazards. Refer all servicing to qualified service personnel. IMPORTANT SAFEGUARDS 16. Damage Requiring Service - Unplug the unit from the outlet and refer Read Instructions - All the safety and operating instructions should servicing to qualified service personnel under the following be read before the unit is operated.
- Page 3 DESCRIPTION This label may appear on the bottom of the unit due to space limitations. The HS9383S Series of environmental housings are attractive The lightning flash with an arrowhead symbol within stainless steel enclosures designed for CCD camera an equilateral triangle is intended to alert the user installations.
- Page 4 Cable Requirements Video Transmission Cradle Removal (Coaxial) 1. Remove the cradle from the housing by first removing the rear retaining ring from the rear cap. Place a flat Cable Type: RG-59/U (Runs < 1000 ft) blade screwdriver underneath the relieved portion of the RG-11/U (Runs <...
- Page 5 2. Pull the video cable through the threaded hole in the rear cap of the cradle. 3. Connect the video cable to the camera. 4. If using a zoom lens, pull the lens cable through the conduit fitting and attach to the zoom lens pursuant to the manual supplied with that product.
- Page 6 HS9383S-6H 5.8.3 Power Connection Installing a 24-volt camera into the HS9383S-6H housing utilizes the internal transformer for the camera. Pull the wires through the conduit fitting and make sure that the threaded section of the fitting mates up with the threads in the rear cap.
- Page 7 DIMENSIONAL OUTLINES MOUNTING Determine a secure mounting location. HS9383S-6H 450.1 HS9383S-5H 17.72 Cautions: HS9383S 300.2 For a secure installation, use four 8-mm (5/16-in) HS9383S-2H 11.82 diameter fasteners (not included). Use stainless steel or zinc plated fasteners. If bolts are used, they should extend through the mounting surface and be secured with flat washers, lock washers, and nuts on the opposite side.
- Page 8 '2005 Aigis Mechtronics 1124 Louise Road Winston-Salem, NC 27107-5450 100 0132 003 AIG 01/07 Tel: 336.785.7740 Fax: 336.785.7744 Printed in U.S.A. Data subject to change without notice.
