Summary of Contents for Aigis Mechtronics MT9208SS
- Page 1 13.77 13.77 9.77 2.00 MT9208SS, MT9212SS MT9215SS N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S...
- Page 2 These indoor/outdoor mounts are designed for camera SECURITE housing installations up to 11.3 kg (25 lb) rated load for the MT9208SS and the MT9212SS and 22.68kg (50 lbs) for the Le point d'exclamation à l'intérieur d'un triangle MT9215SS.These models are made of Stainless Steel and équilatéral avertit l'utilisateur de la présence d'in-...
- Page 3 SPECIFICATIONS 5.1 MT9208SS 20-cm (8-in) Indoor/Outdoor Mount Maximum Load: 11.3 kg (25 lb). Mounting Head: Adjustable. 360° pan, 180° tilt. Finish: Polished. Approx.Weight: 0.5 kg (1.0 lb). WARNING: All mounts must be mounted as shown. 5.2 MT9212SS 30-cm (12-in) Figure 1 Indoor/Outdoor Mount Maximum Load: 11.3 kg (25 lb).
- Page 4 ø MT9208SS MT9208SS 9.77 8.00 MT9212SS 13.77 MT9212SS 12.00 MT9208SS 8” & MT9212SS 12” Dimensional Outline 5.02 6.77 15.06 MT9215SS Dimensional Outline ©2005 Aigis Mechtronics 1124 Louise Road,Winston-Salem, NC 27107-5450 Tel: 336.785.7740 Fax: 336.785.7744 100 0153 002 AIG 01/08 Data subject to change without notice...
