Symbols Used; Intended Use - Pepperl+Fuchs F-FT-EX1.I.IEC Series Instruction Manual

1

Symbols used

This symbol indicates a warning about a possible danger.
In the event the warning is ignored, the consequences may range from
personal injury to death or from damage to equipment to destruction.
This symbol warns of a possible fault.
Failure to observe the instructions given in this warning may result in
the device and any facilities or systems connected to it developing a
fault or even failing completely.
This symbol brings important information to your attention.
2

Intended use

This instruction manual is intended to aid in installing the following fieldbus termina-
tors and placing them in service.
FP-FT-Ex1.I.IEC
FS-FT-Ex1.I.IEC
FN-FT-Ex1.I.IEC
FP-FT-Ex1.D.IEC
FS-FT-Ex1.D.IEC
FN-FT-Ex1.D.IEC
The data sheet for fieldbus terminators contains electrical data of the EC type-exami-
nation certificate and additional information. It is considered part of this instruction
manual.
The data sheet can be downloaded from www.pepperl-fuchs.com.
The fieldbus terminator is used in bus systems (PROFIBUS PA or FOUNDATION
fieldbus) based on the Fisco model. It is manufactured in a flame-
proof and intrinsically safe design and is clearly identified by the labeling on the rating
plate.
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.c
Intrinsically safe with connection threading Pg13.5
Intrinsically safe with connection threading M20 x 1.5
Intrinsically safe with connection threading ½" NPT
Flameproof enclosure with connection threading Pg13.5
Flameproof enclosure with connection threading M20 x 1.5
Flameproof enclosure with connection threading ½" NPT
Fieldbus terminator
