Hupfer TTW/M Operating Instructions Manual

Tray transport trolley

Advertisement

Quick Links

Operating Instructions
Tray transport trolley
TTW/M
4330080_A0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TTW/M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hupfer TTW/M

  • Page 1 Operating Instructions Tray transport trolley TTW/M 4330080_A0...
  • Page 2: Introduction

    Page 2 Appliance Information Introduction Appliance Information Appliance designation Tray transport trolley Appliance type/ -s TTW/M Manufacturer HUPFER® Metallwerke GmbH & Co. KG Dieselstraße 20 48653 Coesfeld PO 1463 48634 Coesfeld +49 2541 805-0 +49 2541 805-111 www.hupfer.de info@hupfer.de Tray transport trolley...
  • Page 3: Table Of Contents

    Setting up and putting into operation Storage and Recycling Operation Operation Measures at the End of Operation Fault Detection and Troubleshooting Notes on Troubleshooting Fault and Action Table Cleaning and Care Security Measures Hygiene Measures Tray transport trolley 4330080_A0 TTW/M...
  • Page 4 Introduction Chapter 1 Page 4 Table of Contents Cleaning and Care 7.3.1 Cleaning and care measures Special Care Instructions Spare Parts and Accessories Spare Parts and Accessories List Tray transport trolley TTW/M 4330080_A0...
  • Page 5: List Of Abbreviations

    Protection against ingress of water during temporary immersion Protection against pressurised water during continuous immersion Light Emitting Diode Light diode Residual current device (RCD) In the EU the English RCD (Residual Current Device) term is customary in standardisation matters. Tray transport trolley 4330080_A0 TTW/M...
  • Page 6: Definitions Of Terms

    An instructed person is a person who has been instructed on the possible risks resulting from improper behaviour when carrying out the assigned task as well as on the necessary protective equipment and protective measures and trained for this task if necessary. Tray transport trolley TTW/M 4330080_A0...
  • Page 7: Orientation Guide

    The side named "the right" means the side at the right hand side of the front side (the front). The left The side named "the left" means the side at the left hand side of the front side (the front). Tray transport trolley 4330080_A0 TTW/M...
  • Page 8: Notes On Use Of Manual

    Brief description of additional information Attention is pointed to special conditions or additional important information on the respective subject. INFO Short title Contains additional information on work assisting features or recommenda- tions on the respective subject. Tray transport trolley TTW/M 4330080_A0...
  • Page 9: Safety Instructions

    During train operation it is not allowed to move the tray transport trolley faster than a walking pace. It is difficult to brake and steer heavily laden appliances. Tray transport trolley 4330080_A0 TTW/M...
  • Page 10: Safety Instructions For Transport

    Carry out all the checks and inspections of the appliance on a regular basis. Remedy deficiencies, such as loose screw connections. Only authorised specialists may perform all repair work. Defective components should only be replaced with original parts. Tray transport trolley TTW/M 4330080_A0...
  • Page 11: Description And Technical Data

    The manufacturer and suppliers are not liable for any consequential damages resulting from an unintended use. No liability is assumed and no warranty claims can be submitted for damages caused by improper use. Tray transport trolley 4330080_A0 TTW/M...
  • Page 12: Appliance Description

    Swivel caster with total brake Push bar Extension for drain plug Transport safety device Fixed caster 3.4.2 View of the appliance TTW View of the appliance TTW/M with passive cooling Figure 2 Door retainer Tray beads Fixed caster Push bar Casters...
  • Page 13: Standard Equipment

    When it deviates from the standard then a fine tuning between the device and the crockery is always necessary. This fine tuning must be done by the manufacturer or the service technicians au- thorized by the manufacturer. On request, recommendations for induction crockery are made available. Isolating covers for the Tray transport trolley 4330080_A0 TTW/M...
  • Page 14: Technical Data

    41.30 41.30 41.30 41.30 41.30 (mm) (1049) (1049) (1049) (1049) (1049) Depth 27.20 27.20 27.20 27.20 27.20 (mm) (691) (691) (691) (691) (691) Height 52.44 61.50 61.50 70.56 70.56 (mm) (1332) (1562) (1562) (1792) (1792) Tray transport trolley TTW/M 4330080_A0...
  • Page 15 20.87 x 12.80 (mm) (530 x 370 mm) (530 x 325 mm) (530 x 370 mm) (530 x 325 mm) Cupboard Num- compart- ments Folding Num- doors max. speed 2.49 2.49 2.49 2.49 in train (km/h) operation Tray transport trolley 4330080_A0 TTW/M...
  • Page 16 Number doors max. speed 2.49 2.49 2.49 2.49 in train (km/h) operation Dim. TTW / M 2/24 TTW / M 2/24 TTW/M 2/32 TTW/M 2/40 L-EN-115 PK L-GN-115 PK B-EN-115 PK B-EN-115 PK Width 41.30 41.30 53.90 53.90 (mm) (1049)
  • Page 17 Description and Technical Data Chapter 3 Technical Data Page 17 Dim. TTW / M 2/24 TTW / M 2/24 TTW/M 2/32 TTW/M 2/40 L-EN-115 PK L-GN-115 PK B-EN-115 PK B-EN-115 PK Payload 264.5 264.5 352.7 (kg) (120) (120) (160) (200)
  • Page 18: Rating Plate

    Rating plate Disposal of old appliances Nominal current Test mark Frequency Protection class Nominal voltage Chilling capacity Payload Coolant Own weight Induction frequency Serial number/Order number Current serial number Item and brief description Electric power Manufacturer Tray transport trolley TTW/M 4330080_A0...
  • Page 19: Transport, Putting Into Operation And Decommissioning

    The recyclable materials must be properly separated and disposed in an environmentally compatible manner according to the local Waste Disposal Regulations. In any case, the local bodies responsible for disposal are to be involved for this purpose. Separate the reus- Tray transport trolley 4330080_A0 TTW/M...
  • Page 20 Packaging and packing material can be sent to the recycling centre by indicating the waste disposal con- ® tract number. If you do not have the valid waste disposal contract number, you can ask for it at HUPFER Service. Tray transport trolley TTW/M 4330080_A0...
  • Page 21: Operation

    NOTE Inductive operation Only appropriate induction crockery released by HUPFER with portioned meals on the intended markings of the trays may be used when the tray transport trolley is used together with the inductive docking station.
  • Page 22: Fault Detection And Troubleshooting

    Total brakes do not have any locking Locking brakes are worn Either renew the locking brakes or action replace the defective casters Running noise of casters Defective caster bearings Replace the casters Sticky surface of the casters Clean with water Tray transport trolley TTW/M 4330080_A0...
  • Page 23: Cleaning And Care

    Action Interior of the Tray transport trolley clean Interior of the Tray transport trolley disinfect Tray transport trolleys for mechanical damages Check Condensate pan at the bottom area empty (only on models with passive cooling) Tray transport trolley 4330080_A0 TTW/M...
  • Page 24: Special Care Instructions

    Therefore, for mechanical cleaning use exclusively refined steel wool or brushes with natural, plastics or refined steel bristles. Steel wool or brushes with unalloyed steel lead to extraneous rust due to abrasion. Tray transport trolley TTW/M 4330080_A0...
  • Page 25: Spare Parts And Accessories

    Stacking slide basket 530/370/108, Stainless steel, plastic- coated 0162628 card holder 107/72/44 attachable 7500895 Paper clamp Stainless steel 90/18/70 0163218 Gallery revolving, for TTW 1 0163219 Gallery revolving, for TTW 2 0162961 connection components for IAS Tray transport trolley 4330080_A0 TTW/M...
