- Page 1 Operating Instructions Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
-
Page 2: Introduction
Appliance Information Introduction Appliance Information Appliance name Mobile bain marie Appliance type/s SPA/K-2DW | SPA/K-3DW Manufacturer HUPFER® Metallwerke GmbH & Co. KG Dieselstraße 20 48653 Coesfeld P.O. Box 1463 D-48634 Coesfeld ' +49 2541 805-0 +49 2541 805-111 www.hupfer.de info@hupfer.de... -
Page 3: Table Of Contents
Putting into Operation Storage and Recycling Operation Arrangement and Function of the Operating Elements Operation Measures at the End of Operation Troubleshooting and Repair Safety Measures Notes on Troubleshooting Fault and Action Table Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... - Page 4 Introduction Chapter1 Page4 Table of Contents Cleaning and Care Safety Measures Hygiene Measures Cleaning and Care Special Care Instructions Spare Parts and Accessories Introduction Spare Parts and Accessories List Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
-
Page 5: List Of Abbreviations
Protection against strong water spray protection against ingress of dust Protection against ingress of water during temporary immersion Protection against pressurised water during continuous immersion Light Emitting Diode Light diode LMHV Regulation on the hygiene of foodstuffs Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... -
Page 6: Definitions Of Terms
An instructed person is a person who has been instructed on the possible risks result- ing from improper behaviour when carrying out the assigned task as well as on the necessary protective equipment and protective measures and trained for this task if necessary. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 7: Orientation Guide
"Right" refers to the right hand side when viewed from the front side (front). The On/Off switch of the cooling element is on this side. The left "Left" refers to the left hand side when viewed from the front side (front). Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... -
Page 8: Notes On Use Of Manual
Brief description of additional information Attention is pointed to special conditions or additional important information on the respective subject. INFO Short title Contains additional information on work assisting features or recommenda- tions on the respective subject. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 9: Safety Instructions
Release both total brakes before moving the appliance. Moving the appliance with the total brakes locked can damage the chassis. § Mobile bain maries should only be moved over level floors. Moving the appliance over very uneven floors can damage the chassis. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... -
Page 10: Safety Instructions For Transport
If possible, transport the appliance upright, i.e. standing on the casters. If this is not possible, the ap- pliance must be set upright for two hours before putting it into operation, so that the coolant can flow back into its initial position. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 11: Safety Instructions For Cleaning And Care
The appliances on which inspection, maintenance and troubleshooting work is performed must be disconnected from the power supply and secured against reactivation when voltage is not required for this kind of work. This must only be carried out by an electrician. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... -
Page 12: Description And Technical Data
Any other use, especially loading the mobile bain marie with other loads as specified, is not permitted. The manufacturer and suppliers are not liable for any consequential damage resulting from unintended use. No liability is assumed and no warranty claims can be submitted for damages caused by improper use. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 13: Appliance Description
Chapter 3 Appliance Description Page 13 Appliance Description 3.4.1 View of the Appliance Mobile Bain Marie Figure 1 View of the appliance SPA/K-2DW Push bars Connecting lead with mains plug On / Off switch Water drain tap Protection plates Plug park... -
Page 14: Optional Accessories
Cooling well required tem- °F 42.8 42.8 perature (˚C) Temperature regulation electronic electronic Chilling capacity 0.21 0.30 Connection value 0.15 0.22 Electrical connection 230V 1N AC 50 Hz 230V 1N AC 50 Hz Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 15: Rating Plate
SPA/K-2DW SPA/K-3DW Protection class IPX4 IPX4 Heat insulation special insulation special insulation The corresponding certification marks are available from our homepage at www.hupfer.de. Rating Plate Figure 2 Rating plate Disposal of old appliances Nominal current Certification mark Frequency Protection class... -
Page 16: Transport, Putting Into Operation And Decommissioning
Wait at least for about 2 hours before you put the appliance into operation. Remove the original packing and check, whether the appliance is complete and undamaged. Do not put a defective appliance into operation under any circumstances and inform the supplier immediately in such cases. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1... -
Page 17: Storage And Recycling
Packaging and packing material can be sent to the recycling centre by indicating the waste disposal contract ® number. If you do not have the valid waste disposal contract number, you can ask for it at HUPFER Service. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... -
Page 18: Operation
Arrangement and Function of the Operating Elements The operating elements of the mobile bain marie are attached to the side of the cooling element below the cooling well. Figure 3 Operating elements (SPA/K-2DW) Operation ATTENTION Contamination by germs Microorganisms from the air may get into the GN containers and contaminate stored food. -
Page 19: Measures At The End Of Operation
Switch off the appliance with the On / Off switch. § Pull out the mains plug and insert it into the plug park provided. § Remove the inserted Gastronorm containers. § Remove the support bars if available. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... - Page 20 Screw the male thread of the drain extension tube to the end fitting of the water drain tap. § Hold the end of the drain extension tube over a drain. § Open the water drain tap. § Drain off the water from the cooling well. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
-
Page 21: Troubleshooting And Repair
Appliance is cold, Defective indicator light Switch off the appliance at the mains, indicator light is not on have it checked and repaired by authorised specialist staff if necessary Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW... - Page 22 Coolant spills Ambient air too warm The ambient temperatures must be between 50 and 89.6 °F (+10 and +32 °C). Defective cooling conduit Switch off the appliance and call a technician Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
- Page 23 Switch off the appliance. Switch off the appliance with the On/Off switch, pull out the mains plug and insert it into the plug park provided. § Drain off the cooling well, if necessary. § Wipe the cooling well and descale if required. § Wipe the exterior panelling of the appliance. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW...
- Page 24 Acid fumes which generate during cleaning of tiles also promote the corrosion of "refined stainless steel". § Avoid damaging the surface of the stainless steel, particularly by metals other than stainless steel. Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
- Page 25 Therefore, for mechanical cleaning use exclu- sively refined steel wool or brushes with natural, plastics or refined steel bristles. Steel wool or brush- es with unalloyed steel lead to extraneous rust due to abrasion. Mobile bain marie 4330036_A1 SPA/K-2DW | SPA/K-3DW...
- Page 26 Swivel caster Polymer Rz3/125 w. total brakes 4002006 Fixing sleeve PA662/23/23 black 014002111 Protection plates 25 x 25 black set (Package contents 4 piece) 0162592 Safety push bar left + right, PP solid material Mobile bain marie SPA/K-2DW | SPA/K-3DW 4330036_A1...
