unication G Series Manual

Hide thumbs Also See for G Series:

Advertisement

Quick Links

Provides Analog 2-Tone, P25 Conventional, P25 Trunking(Phase I, Phase II), Dual Band and Dual Protocol
For before your digital upgrade, during your digital upgrade, and after your digital upgrade. A single device with
every coverage.
Provides Fast, Efficient Dispatch
In less than
20
Seconds, dispatch can transmit voice / text / image messages and map information to all personnel.
In less than
30
Seconds, all send / receive acknowledgements will be completely collected.
In less than
40
Seconds, all personnel will have responded with their times of arrival and current status.
Provides Status Information on All Personnel
A constantly updating Duty On / Off, Power On / Off Pager Status System ensures that Dispatch always knows how
many firefighters are on hand, and firefighters always have a clear line of information back to Dispatch, guaranteeing
both efficiency and personnel safety.
Please contact us with our Toll Free phone number.:888-657-2963
or leave a message on the Unication Website : http://www.unication.com
or http://www.unicationusa.com
Thank you.
A Complete Paging Solution for all Dispatch
Systems. Dual Band, Dual Protocol.
Hydrant
Fire Area
Hydrant
1901 E Lamar Blvd, Arlington, TX
76006

Advertisement

loading
Need help?

Need help?

Do you have a question about the G Series and is the answer not in the manual?

Questions and answers

Related Manuals for unication G Series

Summary of Contents for unication G Series

  • Page 1 Dispatch, guaranteeing both efficiency and personnel safety. Please contact us with our Toll Free phone number.:888-657-2963 or leave a message on the Unication Website : http://www.unication.com or http://www.unicationusa.com Thank you.

  • Page 2: Table Of Contents

    Page Part A : Preface; Why we design the G series Voice Pager Part B : What is the special of G series Voice Pager ? Part C : G Series Voice Pager Features & Specifications Part D : G Series Voice Pager Operations...

  • Page 3: Part A

    Unication has been dedicated to developing radio systems for 25 years. In the past, we designed and made M3, M4, and M5 voice pager. We have over 20 years of experience designing voice pager’...

  • Page 4: Part B

    Unication values the safety and contribution of firefighters nationwide, and we have designed the G Series Voice Pager to make up for the product lacking and offer a solution to volunteer firefighters nationwide.
  • Page 5 ▀ Unication G Series Voice Pager solves all Volunteer Dispatch equipments Current Fire Volunteer Communication System Dispatch System Suggested types of Unication Pager In the following In the following 3 years 3 years Analog 2 Tones Not change Analog 2 Tones...
  • Page 6 Unication's ALT lab, Unication pager can endure the falling from 1.8 m high. B2-2. More ristric water-proof design ( IP 67 ) G Series is able to work in the Dust Environmental Test Chamber for 8 hours under the decompression of maximum 2kPa (20mbar). B2-3.
  • Page 7 B3. Multi-functional receiving table is for users to set up the own receiving mode B3-1. G Series Voice Pager provides 8 Zones by software settings and 8 channels corresponding to Channel knobs, which means 64 channels for selecting. (Unication can modify the provided channels to 256 channels) B3-2.
  • Page 8 ▀ Every Receiving Table can be set with the following parameters by PPS in accordance with the users' requirements to satisfy the users' needs. System Settings Conventional ● There are 4 kinds of settings System Receiving Mode Settings by the Multi-frequency Priority Scan Multi-frequency Priority Scan Single Frequency...
  • Page 9 P25 Trunking P25 Trunking Free Scan Phase 1 System Phase 2 System (AS Scanner) Base on system Base on system Frequency Scan and TGID Scan Set up the code of every site in the Trunking Set up the code of every site in the Trunking Auto Detection system (Note: i.e.
  • Page 10 ▀ Every Receiving Table can be set with the following parameters by PPS in accordance with the users' requirements to satisfy the users' needs. Pager Status operate on customer's radio system Pager operate on different system Receiving Table Single frequency Multi-frequency priority Multi-frequency priority Setting...
  • Page 11 Pager Setting operate on Trunking system Pager Setting as Scanner P25 / Phase # 1 P25 / Phase # 2 Free Scan 1. The way of Ending Code is commonly 1. The way of Ending Code is commonly Not Support used in the Trunking System.
  • Page 12 ▀ Every Receiving Table can be set with the following parameters by PPS in accordance with the users' requirements to satisfy the users' needs. Pager Status operate on customer's radio system Pager operate on different system Receiving Table Single frequency Multi-frequency priority Multi-frequency priority Setting...
  • Page 13 Pager Setting operate on Trunking system Pager Setting as Scanner P25 / Phase # 1 P25 / Phase # 2 Free Scan Set up by each channel and Set up by each channel and Auto Detection protocols. protocols. (Each channel is allowed to (Each channel is allowed to set Multi-protocol and each set Multi-protocol and each...
  • Page 14 When Dispatch Center is dispatching, Voice Pager react to Dispatch Center that this pager receives messages (excluding Off Duty message) Dispatch Center can utilize Unication PS&DRT to see the statistics of all reaction and status of pagers. The status of each pager can be observed as well.
  • Page 15 Unication's Fire Fighting Solution (Two Way Radio System) provides more sufficient function. B5-1. G series pager provides the function of receiving text messages and photos (this function is for analog, digital such as DMR/P25C and P25 Trunking system) (P.S Unication's unique E&TC equipment can also transit Text and Image data in the P25 Trunking Radio...
  • Page 16 B6. Provide multiple and clear reminders of messages B6-1. Provide four kinds of reminders for each Dispatch Alert Tone (a1) Alert tone can be assigned to different message group Vibration (b1) Vibration can be assigned to different message group Alert tone and vibration (c1) Alert tone and vibration can be assigned to different message group Several backlight colors alert (d1) Different backlight color can be assigned to different message group...
  • Page 17 Unication's Fire Fighting Solution (Two Way Radio System) provides more sufficient function. B5-1. G series pager provides the function of receiving text messages and photos (this function is for analog, digital such as DMR/P25C and P25 Trunking system) (P.S Unication's unique E&TC equipment can also transit Text and Image data in the P25 Trunking Radio...

  • Page 18: Part C

    (2) either 2-Tones or 5-Tones PPS selectable (3) CSQ ( Carrier Squelch ) (4) Unication DVOA ( Digital Voice Over Analog ) (5) MDC 1200 (6) Pager Auto Detection (1) (2) (3) (4) Digital only (Available Protocol) :either P25 or...
  • Page 19 Features G2 Single Band Support VHF / UHF G3 Dual Bamd Support UHF + VHF / VHF + UHF G4 Single Band Support 700/800 MHz G5 Dual Band Support 700/800 MHz + VHF System Spec. and Feature Details System Spec. and Feature Details 700/800 MHz + UHF G＊...
  • Page 20 Features G2 Single Band Support G2 Single Band Support VHF / UHF VHF / UHF G3 Dual Bamd Support UHF + VHF / VHF + UHF G3 Dual Bamd Support UHF + VHF / VHF + UHF G4 Single Band Support 700/800 MHz G4 Single Band Support 700/800 MHz...
  • Page 21 Features G2 Single Band Support VHF / UHF G2 Single Band Support VHF / UHF G3 Dual Bamd Support UHF + VHF / VHF + UHF G3 Dual Bamd Support UHF + VHF / VHF + UHF G4 Single Band Support 700/800 MHz G4 Single Band Support 700/800 MHz...
  • Page 22 Features Hardware Spec. and Certification G2 - A G3 - A G4 - A G5 - A Product Available Usage Environment Storage Temperature -30°C ~ +60°C Operating Temperature -10°C ~ +60°C Humidity 5 ~ 95% Product Hardware Description Height : 102 mm Dimension (with Clip and ANT) Width : 61 mm...
  • Page 23 Specification Spec. RF Spec. G2 - A G3 - A G4 - A G5 G5 - A (Narrow Band / Wide Band) j. RF Characteristic Performance (Rx only) Sensitivity Digital 5% BER 7.98 μV/m (Free Space with External Analog 7.98 μV/m Monopole (12 dB SINAD) Antenna)
  • Page 24 Specification Spec. RF Spec. G2 - A G3 - A G4 - A G5 G5 - A (Narrow Band / Wide Band) j. RF Characteristic Performance (Rx only) Adjacent Digital Channel ≧ 60 dB Analog Rejection Digital ≧ 60 dB Analog 700-800 MHz Digital...
  • Page 25 Specification Spec. RF Spec. G2 - A G3 - A G4 - A G5 G5 - A (Narrow Band / Wide Band) j. RF Characteristic Performance (Rx only) Blocking Digital ≧ 80 dB Rejection Analog Digital Analog 700-800 MHz Digital ≧...
  • Page 26 G-Series Voice Pager Available Frequency Band Single Band - G2 Voice Pager Frequency Model External Antenna Band Split G2C66AB - VSXX VHF (136 - 174 MHz, 150 - 162 MHz enhanced) G2C66AB - VLXX VHF (136 - 174 MHz, 136 - 145 MHz enhanced) G2C66AB - UCXX UHF - C Band (400 - 470 MHz)

  • Page 27: Part D

    Part D : G Series Voice Pager Operations Apperance & Accessories Main Menu a-10 a-11 a-12 Voice Memo Key (S1) a-13 a-14 a-15 a-16...
  • Page 28 Pressure Vent Warning: Do not block. Warranty will be void if seal is broken. The G-Series Pager has its own custom- After the battery is installed, turn the ized Lithium Polymer battery, and it can volume knob clockwise to power on the be charged by a micro USB cable ( 5V / G-Series Pager.
  • Page 29 Standby Screen On the standby screen, the G-Series Pager displays information on the current receiving mode. Zone Name Channel Name Receive Message The G-Series Pager displays the information of the incoming call when receiving a message. Title To ID From ID Record Icon / Call Duration / Speaker Status...
  • Page 30 Status Bar Icon Item Icon Description Trunking Status Trunking Status Indicator: Site Trunking Trunking Status Trunking Status Indicator (Blinking): Out Of Range Trunking Status Trunking Status Indicator: In Range Trunking Status Indicator (Blinking): Control Channel Hunting Trunking Status Trunking Status Indicator: Control Channel Scanned The battery gauge indictator is located on the status bar and keeps you informed of the battery level.
  • Page 31 Main Menu In Standby Mode, press the Menu hard key to enter the Main Menu. Press the "Back" key to return to Standby Mode. Pager Message Box View and Manage Text Message Records in Message Box. Enter Message Box (No Message): No Messages Displayed No Soft Key.
  • Page 32 Enter Message Box Voice Call Message) List of Voice Messages Press the "K1" Key to read (Play) highlighted messages. Press the "K2" Key to Lock/Unclock highlighted message. A Lock icon appears on a locked message. Press the "K3" Key to delete (Del) highlighted messages.
  • Page 33 Read Message (Voice Call Message) Voice Call Message: Press the "K1" Key to read (Play) highlighted message. Press the "K1" Key to Pause Press the "K4" Key to Stop. to Pause Read Message (Text Message) Text Call Message: Press the "K1" Key to read (View) highlighted message.
  • Page 34 Note. A locked item cannot be deleted. A locked item cannot be deleted. Function Status Enter Function Status: Use the Navigation Key to select Function Status in the Main Meun Basic Operations: Use the Navigation Key to select features to set. Select Zone Press the"K1"...
  • Page 35 On Off Duty On Off Duty Press the"K1" Key to enter setting screen. On Off Duty-Duty ON On Off Duty-Duty ON Press the"K1" Key to Switch On/Off/Auto Press the"K4" Key to Save. On Off Duty-Duty Off On Off Duty-Duty Off Press the"K1"...
  • Page 36 On Off Duty-Duty Auto On Off Duty-Duty Off Press the"K1" Key to Switch On/Off/Auto Press the"K2" Key to Set ON Duty Time /Off Duty Time Press the"K4" Key to Save. Press the"K2" Key to Set Edit Start Edit Stop Switch BT Device (Off) Bluetooth Status BT Device (Off):...
  • Page 37 BT Device (On): BT Device (On): Press the “K1” Key to deactivate the Bluetooth function. Press the “K2” Key to enter Bluetooth function settings. Set BT Device Visible...
  • Page 38 Earphone Earphone : Press the"K1" Key to turn On-Off. Press the"K2" Key to Set Earphone. Set Earphone BT-Earphone (On/Earphone Set to Search) BT-Earphone : Press the"K4" Key to Stop. Stop...
  • Page 39 Voice Memo Box Enter Voice Record Box Use the Navigation Key to select the Voice Memo Box in the Main Menu Record a New Voice Memo If there is no voice memo, press the "K1" key to start recording. Press the "K1" key to pause. Press the "K4"...
  • Page 40 Set Alarm Press the "K1" Key to set highlighted Date D/M/Y. Press the "K1" Key to set highlighted military time. Press the "K4" Key to Save. All Band Scan Enter All Band Scan Set a range to scan, or view the scanned channel list.
  • Page 41 Active Frequency List Features page 1: Use the Navigation Key to move. Press the “K1” Key to monitor the highlighted channel. Press the “K2” Key to lock the highlighted channel. Press the "K3" Key to scan locked channels. Press the "K4" Key to switch to features page 2. Features page 2 Press the "K1"...
  • Page 42 2. Receive Alert Mode Press the "K1" Key to set highlighted alert mode. Press the "K4" Key to save alert mode. Operation Failed: Message receiving failed. Message Arrived: Text message received. Alarm: Alarm volume 3. LCD Brightness Use the “K1” Key to adjust backlight mode. Press the "K1"...
  • Page 43 Date Format Use the Navigation key to move. Press the “K1” Key to select. Press the “K4” Key to save. Hour Format Use the Navigation key to move. Press the “K1” Key to select. Press the “K4” Key to save. Alarm setting 1: Set up to 2 sets of Alarms.
  • Page 44 Audio squelch Press the “K1” Key to switch. Press the “K4” Key to save. Image Setting Press the “K1” Key to switch. Press the “K4” Key to save. Voice Memo Setting Press the “K1” Key to switch. Press the “K4” Key to save. Receive Alert Mode Select Alert Mode.
  • Page 45 Information Enter Information Use the Navigation key to select Information in the Main Menu. Read Information Firmware Version: Display firmware version. MSN: Lang: Display language. Band Type: Display main band and second band frequency type. Battery: Display battery voltage.
  • Page 46 Diagnostic Enter Diagnostic: Use the Navigation Key to select Diagnostics in the Main Menu. Read Diagnostic: Protocol: Using the Protocol the of current channel. RSSI(dBm): Radio Signal Strength Indicator. Others: Refer to channel setting.
  • Page 47 Quick Call II Message Receiving 2-Tone Messages When the G Series Voice Pager receives a 2-Tone Sub-Group Message, it will display the following screen, and will act accordingly to the 2-Tone ID Alert setting in the PPS. Note : The “To: 1, 2” on the screen displays the Tone names, in this case, “Tone 1”...
  • Page 48 Sub-Group Text Message When the G Series Voice Pager receives a text message from the Dispatch Console with a Uni Header ID Sub-Group Text Message (for example), the name will display the screen below. The pager will act accordingly to the Sub-Group ID setting in the PPS.
  • Page 49 GS-EN-brochure-F-V0.16...
