REFRIGERATION
5 SERIES
RM5310, RM5330, RM5380
Absorber refrigerator
EN
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic 5 Series

Summary of Contents for Dometic 5 Series

  • Page 1 REFRIGERATION 5 SERIES RM5310, RM5330, RM5380 Absorber refrigerator Installation Manual...
  • Page 2 © 2021 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.

  • Page 3: Table Of Contents

    This product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com, dometic.com. Table of contents Explanation of symbols .

  • Page 4: Explanation Of Symbols

    Explanation of symbols RM5310, RM5330, RM5380 Explanation of symbols WARNING! Safety instruction: Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUTION! Safety instruction: Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE! Indicates a situation that, if not avoided, can result in property damage.
  • Page 5 RM5310, RM5330, RM5380 Safety instructions • This device may only be repaired by qualified personnel. Inadequate repairs may cause serious hazards. Risk of asphyxiation • Dismantle all device doors for the disposal of the old device and leave the shelves in the device to prevent accidental enclosure and suffoca- tion.

  • Page 6: Scope Of Delivery

    Scope of delivery RM5310, RM5330, RM5380 • The device may not be exposed to rain. Scope of delivery • Refrigerator • Caps • Ice-cube tray • Operating manual • Installation manual Accessories Available as accessories (not included in the scope of delivery): Description Ref.

  • Page 7: Intended Use

    • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. Installing the refrigerator...
  • Page 8 Installing the refrigerator RM5310, RM5330, RM5380 15 – 25 mm > 25 mm > 25 mm • The distance between the refrigerator and the rear wall must be min. 15 mm – max. 25 mm (fig. 2, page 9).
  • Page 9 RM5310, RM5330, RM5380 Installing the refrigerator 486 mm 474 mm RM 5310 486 mm 474 mm RM 5330 118 mm 486 mm 474 mm RM 5380 • The refrigerator must be installed in a recess so that it stands firm when the vehicle is in motion.
  • Page 10 Installing the refrigerator RM5310, RM5330, RM5380 RM 5310 RM 5330 RM 5380...
  • Page 11 RM5310, RM5330, RM5380 Installing the refrigerator • The outer wall must be fitted with an air inlet vent (fig. 3 2, page 10) and an out- let vent (fig. 3 3, page 10) with ventilation grilles so that the heat generated can be easily released to the outside: –...
  • Page 12 Installing the refrigerator RM5310, RM5330, RM5380 Installing the refrigerator in a draught-proof location Gas-powered refrigerators in caravans or motorhomes must be installed in a draught-free location according to EN 1949. This means that the combustion air is not extracted from the interior and the exhaust fumes are prevented from directly entering the living space.
  • Page 13 RM5310, RM5330, RM5380 Installing the refrigerator Creating the air vents NOTE At high ambient temperatures, the refrigerator can only provide its maximum cooling capacity if the optimum ventilation has been provided. ➤ Make an air inlet vent and an air outlet vent in the outer wall with the size of 451 mm x 156 mm.
  • Page 14 Installing the refrigerator RM5310, RM5330, RM5380 Installing the ventilation grille LS100 No. in Description fig. 6 Installation frame Ventilation grille Attachment for flue duct Winter cover...
  • Page 15 RM5310, RM5330, RM5380 Installing the refrigerator LS200 No. in Description fig. 7 Installation frame Ventilation grille Winter cover...
  • Page 16 Installing the refrigerator RM5310, RM5330, RM5380 Proceed as follows: ➤ Ensure the installation frame is water resistant (A). ➤ Insert the installation frame and screw it down tightly (B). ➤ Insert the ventilation grille and lock it in place (C). For LS100 only ➤...
  • Page 17 RM5310, RM5330, RM5380 Installing the refrigerator Installing the flue duct Proceed as follows: min. 15 mm ➤ Place the T-piece (1) on the adaptor (2) and the flue pipe (3). ➤ Attach the T-piece, adaptor and flue pipe with a screw (4). ➤...
  • Page 18 Installing the refrigerator RM5310, RM5330, RM5380 Securing the refrigerator CAUTION! Only drill through the receptacles provided, otherwise foamed compo- nents, including cables, can be damaged. NOTE Attach the side walls or the attached strips so that the screws are tight, even when under increased loads (while driving).

  • Page 19: Reversing The Door

    RM5310, RM5330, RM5380 Reversing the door Reversing the door Rotary door lock ➤ Replace the door as shown:...
  • Page 20 Reversing the door RM5310, RM5330, RM5380 2-button door lock ➤ Replace the door as shown:...
  • Page 21 RM5310, RM5330, RM5380 Reversing the door...

  • Page 22: Put On The Door Panel

    Put on the door panel RM5310, RM5330, RM5380 Put on the door panel NOTICE! Beware of damage Only ever lay the refrigerator on its side and never on its back. Otherwise the unit may be damaged. The door panel must have the following dimensions: •...

  • Page 23: Connecting The Refrigerator

    RM5310, RM5330, RM5380 Connecting the refrigerator Connecting the refrigerator Connecting to the gas supply NOTICE! • This refrigerator may only be connected to the gas supply by a spe- cialist in accordance with the applicable guidelines and standards. • Only use cylinders of propane or butane gas (not natural gas or city gas) with an approved pressure reduction valve and suitable head.
  • Page 24 Connecting the refrigerator RM5310, RM5330, RM5380 SW 17 SW 14 ➤ Connect the refrigerator to the gas supply securely and without any voltage according to fig. f. The following applies for Europe: Use a cutting ring fitting in accordance with EN 1949.
  • Page 25 RM5310, RM5330, RM5380 Connecting the refrigerator Connecting to 12 Vg and 230 Vw NOTICE! • The electrical installation and repairs may only be performed by a specialist in accordance with the applicable regulations and standards. • According to EN 1648-1, the respective negative and positive cables of the DC connections for heating and lighting may not be joined with one another in a caravan.
  • Page 26 Connecting the refrigerator RM5310, RM5330, RM5380 – ge/gn Blue Brown Yellow Green Black...
  • Page 27 RM5310, RM5330, RM5380 Connecting the refrigerator – – – ge/gn Blue Brown Yellow Green Black White Item in fig. g, Description fig. h DC heating element DC connection cable...
  • Page 28 Connecting the refrigerator RM5310, RM5330, RM5380 Item in fig. g, Description fig. h Terminal strip for the DC power supply of the heating element Positive cable of the heating element Earth cable of the heating element Positive cable of the lighting Reed contact switch (sensor switch) Galvanometer LED lighting...

  • Page 29: Cleaning And Maintenance

    RM5310, RM5330, RM5380 Cleaning and maintenance RM 5310 RM 5330 RM 5380 RM 5385 ➤ Run the cable to the heating element (connections 3 and 4) via a relay controlled by an ignition socket to prevent the vehicle battery from completely discharging if the engine is switched off accidentally (fig.

  • Page 30: Warranty

    RM5310, RM5330, RM5380 Warranty If the product does not work as it should, please contact your retailer or the manufacturer's branch in your country (see dometic.com/dealer). For repair and warranty processing, please include the following documents when you send in the device: •...

  • Page 31: Technical Data

    RM5310, RM5330, RM5380 Technical data Technical data RM5310 RM5330 RM5380 Voltage: 230 Vw 12 Vg Gross capacity: 60 l 70 l 80 l Net capacity: 55 l 65 l 75 l Connection value: 125 W (230 Vw) 120 W (12 Vg) 18.3 g/h (gas) Ice compartment: Power consumption:...
  • Page 32 YOUR LOCAL YOUR LOCAL YOUR LOCAL DEALER SUPPORT SALES OFFICE dometic.com/dealer dometic.com/contact dometic DOMETIC GROUP AB...
