REFRIGERATION
RMV5301, RMV5305
Absorber refrigerator
EN
Installation Manual. . . . . . . . . . . . . . . . . . . . 12
Absorber-Kühlschrank
DE
Montageanleitung. . . . . . . . . . . . . . . . . . . .27
Réfrigérateur à absorption
FR
Instructions de montage . . . . . . . . . . . . . . .42
Absorptiekoelkast
NL
Montagehandleiding . . . . . . . . . . . . . . . . .57
5 SERIES
Advertisement
Related Manuals for Dometic 5 Series
Summary of Contents for Dometic 5 Series
- Page 1 REFRIGERATION 5 SERIES RMV5301, RMV5305 Absorber refrigerator Installation Manual....12 Absorber-Kühlschrank Montageanleitung....27 Réfrigérateur à...
- Page 3 RMV5301, RMV5305 486 mm 478,5 mm...
- Page 4 RMV5301, RMV5305 15 – 25 mm > 25 mm > 25 mm 40 mm 115°...
- Page 5 RMV5301, RMV5305...
- Page 6 RMV5301, RMV5305 LS200 LS230...
- Page 7 RMV5301, RMV5305...
- Page 8 RMV5301, RMV5305...
- Page 9 RMV5301, RMV5305 SW 17 SW 14...
- Page 10 RMV5301, RMV5305 HE OUT 12 VDC HE IN (+) (-) B C D E Brown Black White Braun Schwarz Weiß Marron Rouge Noir Blanc Bruin Rood Zwart...
- Page 11 RMV5301, RMV5305...
-
Page 12: Table Of Contents
RMV5301, RMV5305 Please read this instruction manual carefully before installation and first use, and store it in a safe place. If you pass on the product to another person, hand over this instruction manual along with it. Table of contents Explanation of symbols . -
Page 13: Explanation Of Symbols
RMV5301, RMV5305 Explanation of symbols Explanation of symbols WARNING! Safety instruction: Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUTION! Safety instruction: Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE! Indicates a situation that, if not avoided, can result in property damage. - Page 14 Safety instructions RMV5301, RMV5305 Fire hazard • Ensure clean and residue-free handling if silicon sealant or similar is used. There is a risk of fire if silicone filaments come into contact with hot parts or naked flames. • Never use a naked flame to check the device for leaks. •...
-
Page 15: Scope Of Delivery
RMV5301, RMV5305 Scope of delivery • Danger of overheating! Always ensure sufficient ventilation so that the heat generated during operation can dissipate. Make sure that the device is sufficiently far away from walls and other objects so that the air can circulate. •... -
Page 16: Intended Use
Intended use RMV5301, RMV5305 Intended use The refrigerator is designed for installation in caravans or motorhomes. It is only suit- able for cooling, freezing and storing foodstuffs. The refrigerator is not intended for the proper storage of medicine. The refrigerator is designed to be operated on a DC power supply and an AC socket and can be powered by liquid gas (propane or butane). - Page 17 RMV5301, RMV5305 Installing the refrigerator • The air vents must not be covered by vehicle parts (such as an open door or by installing accessories such as bicycle racks) while operating. • There must be sufficient space at the back of the refrigerator for the air to be able to circulate around the cooling element.
- Page 18 Installing the refrigerator RMV5301, RMV5305 Creating the air vents NOTE At high ambient temperatures, the refrigerator can only provide its maximum cooling capacity if the optimum ventilation has been provided. ➤ Make an air inlet vent and an air outlet vent in the outer wall. Observe instructions when doing this, see chapter “Preparing the installation”...
- Page 19 RMV5301, RMV5305 Installing the refrigerator LS230 No. in Description fig. 8, page 5 Installation frame Ventilation grille Winter cover Proceed as follows (fig. 9, page 6): ➤ Ensure the installation frame is water resistant (A). ➤ Insert the installation frame and screw it down tightly (B). ➤...
-
Page 20: Reversing The Door
Reversing the door RMV5301, RMV5305 Reversing the door Rotary door lock ➤ Replace the door as shown (fig. a, page 7). 2-button door lock ➤ Replace the door as shown (fig. b, page 8). Put on the door panel NOTICE! Beware of damage Only ever lay the refrigerator on its side and never on its back.
