Rigel Multi-Flo Faq

Hide thumbs Also See for Multi-Flo:

How do I use Multi-Flo in Remote

Control mode on Med-eBase?

To use the remote control mode the user will need to install the Gadget

Serial V2.4 Driver. The Gadget serial driver is available at rigelmedical.com in

the download section. To install the gadget serial driver the Multi-Flo needs

to be turned on and connected to the PC using the USB serial cable.

- Multi-Flo

- PC running Med-eBase V2.4 or higher

- Gadget serial driver install files

- USB Serial cable or memory stick

1) On the Multi-Flo menu scroll down and select remote control mode. The

Multi-Flo will then try to connect with the PC.

2) The PC will attempt to download the install drivers for the gadget serial.

As the driver is located on the PC and cannot be found on the internet this

step is not required. Click on the icon when it appears as seen below.

3) Select "skip obtaining driver software" which is blue and underlined to

stop widows looking for driver as the Rigel device won't be able to connect

to the PC while the computer is performing this task. Select yes on the

driver software installation screen to skip the driver update.

Table of Contents

Need help?

Do you have a question about the Multi-Flo and is the answer not in the manual?

Page 1 - Gadget serial driver install files - USB Serial cable or memory stick 1) On the Multi-Flo menu scroll down and select remote control mode. The Multi-Flo will then try to connect with the PC. 2) The PC will attempt to download the install drivers for the gadget serial.
Page 2 9) On Med-eBase select ‘Download from Tester’ by either selecting Tools > Download or the icon. 10) Choose Multi-Flo as the instrument type and then select Gadget serial as the COM port. Note: If Med-eBase was open while installing the gadget serial driver the user may be required to close Med-eBase and reopen it or Rescan COM ports to locate the gadget serial.
